OE-C9912M20 Hardware Manual - Features and Contents
OE-C9912M20 Hardware Manual - Features and Contents
User Manual
Important Safeguards
Warranty
Camera Dimensions
Connections
Features
Box Contents
RTSP
Important Safeguards
View
Important Safeguards
before installing the camera.
Warranty
View the
Product Warranty
for the camera.
Copyright © OpenEye 2023
1
Advertisement
Related Manuals for OpenEye OE-C9912M20
Summary of Contents for OpenEye OE-C9912M20
- Page 1 OE-C9912M20 Hardware Manual - Features and Contents OE-C9912M20 Hardware Manual - Features and Contents User Manual Important Safeguards Warranty Camera Dimensions Connections Features Box Contents RTSP Important Safeguards View Important Safeguards before installing the camera. Warranty View the Product Warranty for the camera.
- Page 2 Camera Dimensions Connections Camera Cables 24vDC + Power (12vDC) White GND - Audio Out + Audio I/O Black Audio Out - Audio + Audio I/O Black Audio - Alarm Out + Alarm I/O Purple Alarm Out - Copyright © OpenEye 2023...
-
Page 3: Alarm Connections
Orange Alarm In + Black Alarm In - Alarm Connections NOTE: An external power source is required for alarm in and alarm out. Alarm In 3.3V - 12V Max Alarm Out 30V Max Camera Connections Copyright © OpenEye 2023... - Page 4 For an adequate power connection, use a 12vDC or 24vAC adaptor. Alternatively, you can power the camera by PoE++ using the PoE power injector provided with the camera, or if a Power Sourcing Equipment (PSE) switch is available. NOTE: OpenEye recommends against using more than one power source at a time. Installation...
-
Page 5: Box Contents
• NDAA Compliant Box Contents OE-C9912M20 cameras come with a mounting accessory kit, grommets, mounting template, and PoE Injector. Identify the following components to make sure everything has been properly included with your new recorder. If any of the following items are missing, contact the dealer to arrange a replacement. - Page 6 Stream 1 to Stream 3 - Enables or disables RTSP unicast for stream 1 to stream 3. The RTSP port number and pathname for each stream can be configured here. NOTE: Enabling/Disabling affects these streams on all Lenses. Default URL Path of Stream 1 to Stream 3 Stream 1: rtsp://cameraIP/stream1 Stream 2: rtsp://cameraIP/stream2 Stream 3: rtsp://cameraIP/stream3 Copyright © OpenEye 2023...
- Page 7 TTL - Configures the time-to-live threshold of the multicast datagram before it is discarded by the router. Save - Save configuration. Reset - Reset button to discard all the settings and revert to the previous settings. Related Links OE-C9912M20 OE-C9912M20 Quick Start Guide OE-C9912M20 Quick Installation Guide Copyright © OpenEye 2023...
- Page 8 Updating the Firmware on the OE-C9912M20 Multisensor Camera Network Camera Manager Copyright © OpenEye 2023...
