OpenEye OE-C9518 Quick Start Manual

8mp (4k) box ip camera
Hide thumbs Also See for OE-C9518:

Advertisement

Quick Links

CONNECTIONS

PRODUCT FEATURES

Camera
Maximum Resolution
4k/2k (8MP) 3840 x 2160
Frame Rate at
H.264 4k/2k @ 25/30 IPS
Maximum Resolution
Total Streams
Quad Streaming
ONVIF Profile S
ONVIF
Compliant
Day/Night
True Day / Night
Wide Dynamic Range
Digital WDR on / off
Auto Back Focus
Yes
23221 E Knox Ave
Liberty Lake, WA 99019
509.232.5261
ww.openeye.net
BNC
1
For analog video output
Insert the microSD card
microSD Card
2
into the card slot to store
Slot
video and snapshots
Reset the camera to
Reset Button
3
factory default
Auto Iris
4
Auto iris lens connection
5a
Line Out
Audio I/O
5b
Line In / Line Out
Alarm I/O
6
Alarm I/O block
Alternate power supply
Power
7
to camera for non-PoE
(DC12V)
networks
For network and PoE
RJ-45
8
connections
Environmental and Power
Power
8.5 W maximum
Consumption
Input Voltage
DC12V / PoE
Operating
-40°C ~ 50°C (-40°F~122°F)
Temperature
Copyright ©2015 OpenEye.
All Rights Reserved. Information contained in this document is
subject to change without prior notice. OpenEye does its best to
provide accurate information but cannot be held responsible for
typos or mistakes.
QUICK START GUIDE
OE-C9518 | 8MP (4K) Box IP Camera
This quick start guide is a reference for users to install and operate your
OpenEye camera and only provides basic information on the camera's settings
and operation. Before attempting to connect, configure and operate your
OpenEye camera, please read the user manual thoroughly.
33476AA
www.openeye.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OE-C9518 and is the answer not in the manual?

Questions and answers

Summary of Contents for OpenEye OE-C9518

  • Page 1: Product Features

    OE-C9518 | 8MP (4K) Box IP Camera This quick start guide is a reference for users to install and operate your OpenEye camera and only provides basic information on the camera’s settings and operation. Before attempting to connect, configure and operate your OpenEye camera, please read the user manual thoroughly.
  • Page 2 192.168.0.250 after four minutes. To connecting 12vDC power, verify the polarity of the power connection. If you modify the IP address, use the OpenEye Network Camera Manager. are using PoE+, make sure the Power Sourcing Equipment (PSE) is in use in Static IP is the recommended default.
