- Page 1 Air conditioner User manual AR60F19D1*** • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Display Remote Control Overview Replacing the remote control batteries Remote Control Operation Selecting an operation mode To set the temperature • To adjust the fan speed • To adjust the airflow direction Smart Features Power Smart Features WindFree Cooling function... - Page 3 This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For more information on safe disposal and recycling, visit our website www.samsung.com/in/support or contact our Helpline numbers - 1800 40 7267864 (1800 40 SAMSUNG) 1800 5 7267864 (1800 5 SAMSUNG).
-
Page 4: Safety Information
Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest version, visit www.samsung.com. Because the instructions in this manual cover various models, the characteristics of your air conditioner may differ slightly from those described. - Page 5 WARNING: Low burning velocity material (This appliance is filled with R-32.) The user and installer guides should be read carefully. The user and installer guides should be read carefully. The service guide should be read carefully. FOR GENERAL This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 Safety Information Fix the outdoor unit firmly so that the electric part of the outdoor unit is not exposed. • Failing to do so may result in electric shock, fire, explosion, or problems with the product. Do not install this appliance near a heater, or flammable material. Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (or rain).
- Page 7 FOR POWER SUPPLY WARNING When the circuit breaker is damaged, contact your nearest service centre. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 8 • Since this may be dangerous due to a lack of oxygen, open a window at least once an hour. Do not use means to accelerate the defrost operation or to clean, other than those recommended by Samsung. Do not pierce or burn.
- Page 9 CAUTION Do not place objects or devices under the indoor unit. • Water dripping from the indoor unit may result in fire or property damage. Check that the installation frame of the outdoor unit is not broken at least once a year. •...
- Page 10 Safety Information Do not touch the pipes connected with the product. • This may result in burns or injury. Do not cut or burn the refrigerant container or pipings. Do not point the air direction to the fireplace or heater. Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or for any other unusual purposes.
-
Page 11: At A Glance
Indoor Unit Overview The appearance of the actual product may differ slightly from the image below. 01 Air intake 05 Airflow blade (left and right) 02 Air filter 06 Power button/Remote control receiver 03 WindFree panel 07 Room temperature sensor 04 Airflow blade (up and down) 08 Display English... -
Page 12: Display
Indoor Unit Overview Display 01 Temperature indicator (numeric) / Filter reset indicator ( Electricity consumption indicator (numeric) / Auto clean indicator ( 02 AI Energy indicator 03 AI Auto indicator 04 Timer indicator / Good Sleep indicator 03 04 05 05 Wi-Fi indicator NOTE •... -
Page 13: Remote Control Overview
Remote Control Overview Most operating instructions in this manual require using the remote control. 01 Set temperature indicator 02 Timer option indicator 03 Operation mode indicator 04 Options indicator 05 Low battery indicator 06 Transmit indicator 07 Fan speed indicator 08 WindFree indicator 09 Vertical air swing indicator 10 Horizontal air swing indicator... -
Page 14: Remote Control Operation
Remote Control Operation You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan speed, and air direction. Selecting an operation mode To change the current mode between Auto, Cool, Dry, and Fan, press (Mode) button. -
Page 15: To Set The Temperature • To Adjust The Fan Speed • To Adjust The Airflow Direction
To set the temperature To control the temperature in each mode, press the (Temperature) button: Mode Temperature control AI Auto/Auto/Cool Adjust by 1 ℃ from 16 ℃ to 30 ℃. Adjust by 1 ℃ from 18 ℃ to 30 ℃. No temperature control. To adjust the fan speed Select from the following fan speeds in each mode: Mode... -
Page 16: Smart Features
Power Smart Features WindFree Cooling function Use the WindFree Cooling function to enjoy a mild breeze coming through fine holes in the WindFree panel instead of air coming directly through the airflow blades. In Cool/Dry/Fan mode ▶ NOTE • To cancel this function, press the (WindFree) button again. -
Page 17: Ai Auto Mode • Ai Energy Mode
AI Auto mode Use AI Auto mode to automatically operate any of Cool, Dry, and WindFree Cooling modes depending on the learned user patterns gathered from an external server via Wi-Fi module. The favourite temperature and operation mode are also set based on the current temperatures (indoor/outdoor) and the gathered user patterns. -
Page 18: Auto Mode • Cool Mode
Power Smart Features Auto mode Use Auto mode to perform the powerful cooling function to automatically reach the desired temperature. When the difference between the room temperature and the set temperature decreases, the air conditioner controls the fan speed and airflow direction. ▶... -
Page 19: Dry Mode • Fan Mode
Dry mode Use Dry mode in rainy or humid weather. ▶ ▶ Select Dry. NOTE • The proper set temperature range for dehumidifying operation is 24 to 26 ℃. If you feel that the current humidity seems high, use a lower set temperature. -
Page 20: Variety Smart Features
Variety Smart Features Fast function Use the Fast function to quickly cool your room. This function is the most powerful cooling function provided by the air conditioner. You can select this function in Cool mode. In Cool mode ▶ ▶ Press and hold for 3 or more seconds. NOTE •... -
Page 21: Step Cooling Function
5 Step Cooling function Use the 5 Step Cooling function to adjust the cooling speed by changing the operation rate of the outdoor unit. In Cool mode ▶ NOTE • Each time you press the button in Cool mode, you can adjust the operation rate of the outdoor unit in 5 steps. -
Page 22: Quiet Function
Variety Smart Features Quiet function Use the Quiet function to reduce the unit’s operating noise. You can select this function in Cool mode. In Cool mode ▶ ▶ ▶ Select Quiet. ▶ NOTE • You can change the set temperature and the airflow direction, but you cannot change the fan speed. -
Page 23: Electricity Consumption Check • Beep Function
Electricity consumption check Use the Usage function to check the amount of electricity consumed by using the air conditioner. The amount consumed is displayed on the indoor unit display for a few seconds, and the set temperature appears. In operation ▶ ▶... -
Page 24: Auto Clean Function
Variety Smart Features Auto clean function Use the Auto clean function if the indoor unit produces odors. Activating Auto clean To activate Auto clean, press the (Options) button for at least 3 seconds. The indoor unit display shows: If the air conditioner is off, Auto clean starts immediately. If the air conditioner is running, Auto clean starts as soon as the air conditioner turns off. - Page 25 Canceling Auto clean To cancel Auto clean while it is running, follow the procedure below: ▶ Press and hold for 3 or more seconds. ▶ ▶ Select Clean. ▶ NOTE • Canceling Auto clean does not deactivate it. Deactivating Auto clean To deactivate Auto clean, follow the procedure below while the air conditioner is in operation: ▶...
-
Page 26: Freeze Wash Function
Variety Smart Features Freeze Wash function Use the Freeze Wash function to wash away microorganisms or dust on the surface of the indoor heat exchanger by freezing and thawing operation. In operation stop condition, ▶ ▶ Select Wash. ▶ NOTE •... -
Page 27: Display Lighting Function • Wi-Fi Function (Smartthings App)
Display lighting function Use the Display lighting function to turn on or off the lighting of the indoor unit display. ▶ ▶ Select Display. ▶ NOTE • If you change the current mode or function when the Display lighting function is on, the display lighting turns on for 5 seconds and then turns off again. -
Page 28: Time Scheduling
Time Scheduling Timed on/ Timed off function Use the Timed on/off function to turn the air conditioner on or off after a duration. Scheduling durations before the air conditioner turns on or off helps use the air conditioner economically. ▶ Select On or Off ▶ ▶... -
Page 29: Good Sleep Function
Good Sleep function Use the Good Sleep function to save energy while you are sleeping. You can select this function in Cool mode. In Cool ▶ ▶ ▶ mode (Set the duration.) (Select NOTE • To cancel the Good Sleep function, set the duration to 0.0. •... - Page 30 Schedule Task How often By whom Instruction "Auto clean function" on page Run the Auto clean function. As needed Owner "Freeze Wash function" on Run the Freeze Wash function. Once every two weeks Owner page 26. "Cleaning the filter" on page Clean the filter.
- Page 31 Cleaning Cleaning the outside of the indoor unit 1 Turn off the air conditioner and wait until the fan stops. 2 Disconnect the power supply. 3 Use a soft brush or lukewarm damp cloth to clean the exterior. WARNING Soft brush •...
-
Page 32: Cleaning The Filter
Cleaning Cleaning the filter Clean the air filter every two weeks or when the (filter-cleaning reminder) appears on the indoor unit display. The time between cleanings may vary, depending on the usage and environmental conditions. Vacuum cleaner Soft brush 30 minutes Mild detergent 1 Slide the filter off of the unit. - Page 33 Cleaning the WindFree panel Clean the WindFree panel at least once a month. 1 Pull the airflow blade open. 2 Hold and pull both sides of the WindFree panel until it comes free from the air conditioner. 3 Use a soft brush or vacuum cleaner to remove any dust. 4 Hang the WindFree panel in the grooves at the bottom left and right.
-
Page 34: Troubleshooting
Troubleshooting If the air conditioner is not operating normally, refer to the troubleshooting guide below. Problem Solution • Make sure the unit is receiving power. • Check the circuit breaker. If it is flipped off, flip it on again and restart The air conditioner stops the unit. - Page 35 Problem Solution • Replace the batteries in the remote control. • Make sure the remote control can send an unobstructed signal to The remote control does not the unit. work. • Keep bright lights away from the unit. Light from fluorescent bulbs or neon signs may interrupt the signal from the remote control.
- Page 36 Troubleshooting Problem Solution Water drips from the pipe • Condensation may develop when the ambient temperature or connections on the outdoor unit. humidity changes significantly. This is normal. • If the humidity is higher in the room in Cool mode, or the difference Condensation forms on the between the desired temperature and indoor temperature is great, surface of the indoor unit.
- Page 37 • If you have enquiries regarding the items mentioned 3 Tap Sign In. above, please contact us on st.service@samsung. com. 4 If you have no Samsung account, tap Add account to create your Samsung account. Step 2. Connecting your 5 Log in to your Samsung account.
-
Page 38: Specifications
To notify that registration of the selected air after the last shipment of this product by sending an conditioner to your Samsung account is in progress, email to mailto:oss.request@samsung.com. (Transmit) indicator blinks for several seconds It is also possible to obtain the complete appears on the remote control display. - Page 39 Memo English...
- Page 40 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 1800 40 7267864 (1800 40 SAMSUNG) INDIA www.samsung.com/in/support 1800 5 7267864 (1800 5 SAMSUNG) This product is RoHS compliant...
