- Page 1 Air conditioner User manual AR60F**D1*** / AR70F**D1*** • Thank you for purchasing this Samsung air conditioner. • Before operating this unit, please read this manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Display Remote Control Overview Replacing the remote control batteries Remote Control Operation Selecting an operation mode To set the temperature • To adjust the fan speed • To adjust the airflow direction Smart Features Power Smart Features WindFree Cooling function... - Page 3 Cleaning and Maintenance Schedule Cleaning Appendix Troubleshooting SmartThings app Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
-
Page 4: Safety Information
Incorrect installation, use, or maintenance of this appliance can result in death, serious injury, or property damage. Keep these instructions with this appliance. This manual is subject to change. For the latest version, visit www.samsung.com. Because the instructions in this manual cover various models, the characteristics of your air conditioner may differ slightly from those described. - Page 5 Symbol Meaning WARNING: Low burning velocity material (This appliance is filled with R-32.) The user and installer guides should be read carefully. The user and installer guides should be read carefully. The service guide should be read carefully. FOR GENERAL This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, without supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 Safety Information FOR INSTALLATION WARNING Use a power cord with this product's power specifications or higher and use the power cord for this appliance only. In addition, do not use an extension cord. • Extending the power cord may result in electric shock or fire. •...
- Page 7 CAUTION Install your appliance on a level and hard floor that can support its weight. • Failing to do so may result in abnormal vibrations, noise, or problems with the product. Install the drain hose properly so that water drains correctly. •...
- Page 8 Safety Information FOR USING WARNING If the appliance is flooded, please contact your nearest service centre. • Failing to do so may result in electric shock or fire. If the appliance generates a strange noise, a burning smell or smoke, cut off the power supply immediately and contact the nearest service centre.
- Page 9 Do not use this air conditioner for long periods of time in badly ventilated locations or near infirm people. • Since this may be dangerous due to a lack of oxygen, open a window at least once an hour. If any foreign substance such as water has entered the appliance, cut off the power supply and contact the nearest service centre.
- Page 10 Safety Information Do not use this air conditioner to preserve precision equipment, food, animals, plants or cosmetics, or for any other unusual purposes. • This may result in property damage. Avoid directly exposing humans, animals or plants to the air flow from the air conditioner for long periods of time.
- Page 11 Then consult the authorized service personnel. Do not use means to accelerate the defrost operation or to clean, other than those recommended by Samsung. Do not pierce or burn. Be aware that refrigerants may not contain an odour.
-
Page 12: At A Glance
Indoor Unit Overview The appearance of the actual product may differ slightly from the image below. 01 Air intake 06 Airflow blade (left and right) 02 Air filter 07 Power button/Remote control receiver 03 4-in-1 Care filter (For AR70F**D1*** models) 08 Room temperature sensor 04 WindFree panel 09 Display... -
Page 13: Display
Display 01 Temperature indicator (numeric) / Filter reset indicator ( Electricity consumption indicator (numeric) / Auto clean indicator ( 02 AI Energy indicator 03 AI Auto indicator 04 Timer indicator / Good Sleep indicator 02 03 04 05 05 Wi-Fi indicator NOTE •... -
Page 14: Remote Control Overview
Remote Control Overview Most operating instructions in this manual require using the remote control. 01 Set temperature indicator 02 Timer option indicator 03 Operation mode indicator 04 Options indicator 05 Low battery indicator 06 Transmit indicator 07 Fan speed indicator 08 Dry Comfort indicator 09 WindFree indicator 10 Vertical air swing indicator... -
Page 15: Remote Control Operation
Remote Control Operation You can use the air conditioner easily by selecting a mode and then by controlling the temperature, fan speed, and air direction. Selecting an operation mode To change the current mode between Auto, Cool, Dry, and Fan, press (Mode) button. -
Page 16: To Set The Temperature • To Adjust The Fan Speed • To Adjust The Airflow Direction
Remote Control Operation To set the temperature To control the temperature in each mode, press the (Temperature) button: Mode Temperature control AI Auto/Auto/Cool Adjust by 1 ℃ from 16 ℃ to 30 ℃. Adjust by 1 ℃ from 18 ℃ to 30 ℃. No temperature control. -
Page 17: Smart Features
Power Smart Features WindFree Cooling function Use the WindFree Cooling function to enjoy a mild breeze coming through fine holes in the WindFree panel instead of air coming directly through the airflow blades. In Cool/Dry/Fan mode ▶ NOTE • To cancel this function, press the (WindFree) button again. -
Page 18: Dry Comfort Function
Power Smart Features Dry Comfort function This dehumidification feature maintains comfortable humidity levels and saves energy by adjusting humidity according to the set temperature. In operation ▶ NOTE • The set temperature can be adjusted by 1 ℃ within the range of 18 ℃... -
Page 19: Ai Auto Mode • Ai Energy Mode
AI Auto mode Use AI Auto mode to automatically operate any of Cool, Dry, and WindFree Cooling modes depending on the learned user patterns gathered from an external server via Wi-Fi module. The favourite temperature and operation mode are also set based on the current temperatures (indoor/outdoor) and the gathered user patterns. -
Page 20: Auto Mode • Cool Mode
Power Smart Features Auto mode Use Auto mode to perform the powerful cooling function to automatically reach the desired temperature. When the difference between the room temperature and the set temperature decreases, the air conditioner controls the fan speed and airflow direction. ▶... -
Page 21: Dry Mode • Fan Mode
Dry mode Use Dry mode in rainy or humid weather. ▶ ▶ Select Dry. NOTE • The proper set temperature range for dehumidifying operation is 24 to 26 ℃. If you feel that the current humidity seems high, use a lower set temperature. -
Page 22: Variety Smart Features
Variety Smart Features Fast function Use the Fast function to quickly cool your room. This function is the most powerful cooling function provided by the air conditioner. You can select this function in Cool mode. Press and hold for In Cool mode ▶ ▶... -
Page 23: Eco Function
Eco function Use the Eco function to reduce electricity consumption while staying cool. You can select this function in Cool mode. In Cool mode ▶ ▶ ▶ Select Eco. ▶ NOTE • When the Eco function starts, the pattern appears on the remote control for a few seconds and vertical air swing begins. -
Page 24: Quiet Function
Variety Smart Features Quiet function Use the Quiet function to reduce the unit’s operating noise. You can select this function in Cool mode. In Cool mode ▶ ▶ ▶ Select Quiet. ▶ NOTE • You can change the set temperature and the airflow direction, but you cannot change the fan speed. -
Page 25: Electricity Consumption Check • Beep Function
Electricity consumption check Use the Usage function to check the amount of electricity consumed by using the air conditioner. The amount consumed is displayed on the indoor unit display for a few seconds, and the set temperature appears. In operation ▶ ▶... -
Page 26: Auto Clean Function
Variety Smart Features Auto clean function Use the Auto clean function if the indoor unit produces odors. Activating Auto clean To activate Auto clean, press the (Options) button for at least 3 seconds. The indoor unit display shows: If the air conditioner is off, Auto clean starts immediately. If the air conditioner is running, Auto clean starts as soon as the air conditioner turns off. - Page 27 Canceling Auto clean To cancel Auto clean while it is running, follow the procedure below: ▶ Press and hold for 3 or more seconds. ▶ ▶ Select Clean. ▶ NOTE • Canceling Auto clean does not deactivate it. Deactivating Auto clean To deactivate Auto clean, follow the procedure below while the air conditioner is in operation : ▶...
-
Page 28: Freeze Wash Function
Variety Smart Features Freeze Wash function Use the Freeze Wash function to wash away microorganisms or dust on the surface of the indoor heat exchanger by freezing and thawing operation. In operation stop condition, ▶ ▶ Select Wash. ▶ NOTE •... -
Page 29: Display Lighting Function • Wi-Fi Function (Smartthings App)
Display lighting function Use the Display lighting function to turn on or off the lighting of the indoor unit display. ▶ ▶ Select Display. ▶ NOTE • If you change the current mode or function when the Display lighting function is on, the display lighting turns on for 5 seconds and then turns off again. -
Page 30: Time Scheduling
Time Scheduling Timed on/ Timed off function Use the Timed on/off function to turn the air conditioner on or off after a duration. Scheduling durations before the air conditioner turns on or off helps use the air conditioner economically. Select ▶... -
Page 31: Good Sleep Function
Good Sleep function Use the Good Sleep function to save energy while you are sleeping. You can select this function in Cool mode. In Cool mode ▶ ▶ ▶ (Set the duration.) (Select NOTE • To cancel the Good Sleep function, set the duration to 0.0. •... - Page 32 Schedule Task How often By whom Instruction Run the Auto clean "Auto clean function" on page As needed Owner function. Run the Freeze Wash "Freeze Wash function" on page Once every two weeks Owner function. "Cleaning the filter" on page Clean the filter.
-
Page 33: Cleaning The Outside Of The Indoor Unit
Cleaning Cleaning the outside of the indoor unit 1 Turn off the air conditioner and wait until the fan stops. 2 Disconnect the power supply. 3 Use a soft brush or lukewarm damp cloth to clean the exterior. WARNING Soft brush •... -
Page 34: Cleaning The Filter
Cleaning Cleaning the filter Clean the air filter every two weeks or when the (filter-cleaning reminder) appears on the indoor unit display. The time between cleanings may vary, depending on the usage and environmental conditions. Vacuum cleaner Soft brush 30 minutes Mild detergent 1 Slide the filter off of the unit. - Page 35 Replacing the 4-in-1 Care filter (For AR70F**D1*** models) Slide a new 4-in-1 care filter in the direction of arrow 2. Replace 4-in-1 Care filters once every three years. Replacement cycle may differ depending on the environment and usage time. 4-in-1 Care filter CAUTION •...
- Page 36 Cleaning Cleaning the WindFree panel Clean the WindFree panel at least once a month. 1 Pull the airflow blade open. 2 Hold and pull both sides of the WindFree panel until it comes free from the air conditioner. 3 Use a soft brush or vacuum cleaner to remove any dust. 4 Hang the WindFree panel in the grooves at the bottom left and right.
-
Page 37: Troubleshooting
Troubleshooting If the air conditioner is not operating normally, refer to the troubleshooting guide below. Problem Solution • Make sure the unit is receiving power. • Check the circuit breaker. If it is flipped off, flip it on again and restart The air conditioner stops the unit. - Page 38 Troubleshooting Problem Solution • Replace the batteries in the remote control. • Make sure the remote control can send an unobstructed signal to the The remote control does not unit. work. • Keep bright lights away from the unit. Light from fluorescent bulbs or neon signs may interrupt the signal from the remote control.
- Page 39 Wi-Fi, Bluetooth permissions, tap Start. 3 Tap Log In. 1 Turn on the Wi-Fi access point. 4 If you have no Samsung account, tap Add account 2 Tap Settings → Wi-Fi on your smartphone. to create your Samsung account.
-
Page 40: Specifications
To notify that registration of the selected air mailto:oss.request@samsung.com. conditioner to your Samsung account is in progress, It is also possible to obtain the complete corresponding (Transmit) indicator blinks for several seconds source code in a physical medium such as a CD-ROM;... - Page 41 Memo English...
- Page 42 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT www.samsung.com/latin/support (Spanish) ECUADOR 1-800-72-6786 www.samsung.com/latin_en/support (English) www.samsung.com/latin/support (Spanish) PANAMA 800-0101 www.samsung.com/latin_en/support (English) URUGUAY 0800-SAMS(7267) www.samsung.com/uy Bogotá en el 600 12 72 COLOMBIA Sin costo en todo el pais 01 8000 112 112 www.samsung.com/co/support...
