User Interface (Example METRISO TECH)
Exit
menu
Activate instrument
from standby
LCD panel
state
Start measurement
Parameters transfer
Continuous
measurement
for Riso/Rins,
R & R
LO
Guide for
carrying strap
4
Scroll up:
– SETUP: parameter selection
– V: voltage type selection
– Rlo: polarity reversal
Rlo>10%
MAN STORE
DC
AC
TRMS
DATA M G T V 2500V
k k
ISO
ZERO 1000 V
Scroll down:
– SETUP: parameter selection
– V: voltage type selection
– Rlo: polarity reversal
Red LED: limit value exceeded
Green LED: limit value adhered to
Red LED:
– External voltage with device switched off *
– Test/Measuring voltage with device switched on
– Discharge voltage for Riso/Rins
Setup menu SEt
* not
METRISO INTRO
Function
selector switch
Guide for
carrying strap
