3idee hp27-o Assembly Instructions Manual

Vesa adapter (v2)
Hide thumbs Also See for hp27-o:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

hp27-o VESA adapter (V2)
Assembly
instructions
The VESA adapter is compatible with the following products from
hp
(hp.com):
OMEN 27 (Z4D33AA), OMEN X27 (6FN07AA)
With the VESA adapter, you can easily attach your HP monitor to a monitor arm
with a VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this.
Direct wall mounting is NOT possible, as the VESA adapter already contains metric
threads through which no screws can be inserted for mounting to the wall.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the hp27-o and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 3idee hp27-o

Summary of Contents for 3idee hp27-o

  • Page 1 VESA hole pattern (75 x 75mm). Use the supplied screws and nuts for this. Direct wall mounting is NOT possible, as the VESA adapter already contains metric threads through which no screws can be inserted for mounting to the wall. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...

  • Page 2: Important Safeguards

    Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.
  • Page 3 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...

  • Page 4: Scope Of Delivery Accessories

    Assembly instructions Scope of Delivery Accessories 4x M4x14 Screw with cross 1x M4x20 Countersunk head recess (SP2) screw with cross recess (SP9)

  • Page 5: Horizontal Mounting

    Assembly instructions Horizontal / Vertical Alignment Please note: Not all VESA adapters and monitors are designed for vertical (upright) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can quickly be exceeded if not installed properly. We are continuously working on developing monitors and adapters that are also suitable for vertical orientation.
  • Page 6 Assembly instructions Video assembly instructions...

  • Page 7: Assembly Instruction

    Assembly instructions Assembly Instruction Step 1 (Preparations before assembly) Before actually installing the VESA adapter, we need to prepare the mounting of the Omen monitor. To do this, place your Omen on a safe and soft surface and loosen the stand of your monitor if it is still attached.
  • Page 8 Assembly instructions Step 5 Insert the VESA adapter into the mounting of the monitor as shown. Make sure that the label "Up" points to the top edge of the monitor. (Figure 4) Figure 4 Step 6 Now attach the VESA adapter using the M4x20 countersunk screw included in the scope of delivery.
  • Page 9 Assembly instructions Step 8 Now check that you have tightened all screws properly. (Figure 7) Figure 7...
