3idee hp-27cr Assembly Instructions Manual

Vesa adapter (v2)
Hide thumbs Also See for hp-27cr:

Advertisement

Table of Contents

hp-27cr VESA adapter (V2)
Assembly
instructions
The VESA adapter is compatible with the following All-in-One PCs from
hp
(hp.com):
24-cr0000ng, 24-cr0001I, 24-cr0002ng, 24-cr0005ng, 24-cr0006ng,
24-cr0007ng, 24-cr0101ng, 24-cr0102ng, 24-cr0103ng, 24-cr0107ng,
24-cr0205ng, 24-cr0400ng, 24-cr0401ng, 24-cr0701ng, 24-cr0703ng,
24-cr0706ng, 27-cr0001ng, 27-cr0005ng, 27-cr0006ng, 27-cr0007ng,
27-cr0008nf, 27-cr0008ng, 27-cr0009ng, 27-cr0034nf, 27-cr0047nf,
27-cr0106ng, 27-cr0108ng, 27-cr0109ng, 27-cr0301ng, 27-cr0402ng,
27-cr0455ng, 27-cr0456ng, 27-cr0701ng, 27-cr0702ng, 27-cr0703ng,
27-cr1201ng, 27-cr1750ng, 27-cr1755ng, 27-cr1770ng, 884P9EA,
884Q1EA, 884Q2EA, 8T3M4ES, ProOne 420 G10
⚠ WARNING
To minimize the risk of injury, it is important to read all instructions
carefully before installation. We accept no liability for personal injury or
damage to property caused by improper use of this product.
It is also essential to observe the technical specifications of the product.
1. Read all instructions carefully.
2. Incorrect installation can lead to damage or serious injury. Make sure that the
product and the monitor are securely mounted before using it. 3.
3. Make sure that the bracket to which the product is attached can easily support
the total weight of the monitor, computer and adapter.
support@3idee.eu | +352 661 26 72 76 | help.3idee.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the hp-27cr and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 3idee hp-27cr

Summary of Contents for 3idee hp-27cr

  • Page 1 3. 3. Make sure that the bracket to which the product is attached can easily support the total weight of the monitor, computer and adapter. support@3idee.eu | +352 661 26 72 76 | help.3idee.eu...
  • Page 2 Assembly instructions...

  • Page 3: Technical Specifications

    Assembly instructions Technical Specifications Maximum load capacity: 7 kg / 15.4 lbs VESA standard compatibility: 75x75 mm Material: Plastic Pivot angle: 90° Maximum operating temperature: 35°C / 95°F Maximum ambient temperature: 35°C / 95°F ⚠ WARNING Exceeding the maximum load capacity, operating temperature or ambient temperature can lead to serious injury or damage.

  • Page 4: Important Safeguards

    Assembly instructions Important Safeguards Please read this manual carefully and keep it for future reference. If you pass the product on to third parties, this manual should always be included. Ignoring these instructions may result in injuries or damage to people and products, for which we cannot accept any liability.
  • Page 5 For the disposal of this product we recommend to contact the responsible local authorities or disposal services. They can provide you with detailed information on available disposal options and recycling centers in your area. 4. Manufacturer Information 3idee S.à r.l. 19 Rue de Bitbourg L-1273 Luxembourg Luxembourg mail: info@3idee.eu...

  • Page 6: Scope Of Delivery Accessories

    Assembly instructions Scope of Delivery Accessories 4x M4x14 Screw with cross 2x M3x30 Screw with cross 2x M3x20 Screw with cross recess (SP2) recess (SP44) recess (SP11) ⚠ NOTE: Please check that all parts of the accessories are complete before assembly. If anything is missing, please contact our customer service team immediately by email or phone.

  • Page 7: Horizontal Mounting

    Assembly instructions Horizontal / Vertical Alignment ⚠ NOTE: Not all VESA adapters and monitors are designed for a vertical (portrait) orientation. This limitation is often due to the specific geometry of the adapter or monitor. Do not ignore this information, as the load limit of the adapter can be quickly exceeded if not mounted properly.
  • Page 8 Assembly instructions Video assembly instructions...

  • Page 9: Assembly Instruction

    Assembly instructions Assembly Instruction Step 1 (Preparations before assembly) Place your All-in-One PC on a safe, soft surface. Remove the monitor stand if it is already attached. Step 2 (Preparations before assembly) Loosen the 2 screws that secure the black clip. (Figure 1) Figure 1 Step 3 (Preparations before assembly) First pull the latching mechanism forward and remove the...
  • Page 10 Assembly instructions Step 5 Depending on which All-in-One PC you have, you may need to use different screws. Variant A: (24-cr and 27-cr models) Now attach the VESA adapter using the supplied 2x M3x20 screws from the screw bag (SP11). (Figure 4) Variant B: (ProOne 420 G10 models) Now attach the VESA adapter using the supplied 2x Figure 4...
  • Page 11 Assembly instructions remaining screws easily. ⚠ NOTE: Make sure you use the right screws! (Figure 7) Step 9 Now check that you have tightened all screws properly. (Figure 8) Figure 8...
