Cellocator Cello Family –
Squarell 8000
Integration Manual
Proprietary and Confidential
Version
1.0
Revised and Updated: May 22, 2013
Copyright © 2013 by Pointer Telocation, Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cellocator Cello Squarell 8000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pointer Cellocator Cello Squarell 8000

Summary of Contents for Pointer Cellocator Cello Squarell 8000

  • Page 1 Cellocator Cello Family – Squarell 8000 Integration Manual Proprietary and Confidential Version Revised and Updated: May 22, 2013 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 2: Legal Notices

    Customers of Pointer Telocation Ltd. using, integrating, and/or selling the product for use in such applications do so at their own risk and agree to fully indemnify Pointer Telocation Ltd. for any resulting loss or damages.
  • Page 3 Integration Manual Intellectual Property Copyright in and to this document is owned solely by Pointer Telocation Ltd. Nothing in this document shall be construed as granting you any license to any intellectual property rights subsisting in or related to the subject matter of this document including, without limitation, patents, patent applications, trademarks, copyrights or other intellectual property rights, all of which remain the sole property of Pointer Telocation Ltd.

  • Page 4: Table Of Contents

    Changing the Threshold setting using iConfigure ............. 30 Changing the Threshold setting using a RS232 message ..........30 DCF Initialization Routine ..................32 Digital Tachograph Initialization ..................32 Cellocator Cello – Squarell 8000 Integration Manual Page 4 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 5: Introduction

    --------------------------------------------------------------------------------------------- Revision History Version Date Description 121026 26-10-2013 Pointer Cellocator Protocol described 130411 11-04-2013 Screenshots and configuration added Cellocator Cello – Squarell 8000 Integration Manual Page 5 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 6: Integration Steps

    The Squarell 8000 series Device translates the internal CANbus (J1939 or proprietary), J1708 (J1922 or J1587) and K-Line (DTCO) protocols into RS232 messages with following port settings. These settings should be also used by Cellocator Cello device: The RS232 port set-up for ASCII with the Pointer Cellocator: Bits per second 9600...

  • Page 7: Connect Cellocator Cello Family With Squarell Devices

    RS232 interface (pins 12 and 13). The RJ45 connector is illustrated in the following figure: Serial Port Adaptor Connector – Front View Cellocator Cello – Squarell 8000 Integration Manual Page 7 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 8 Dsub9 Pin2 (RS232 TX) to Cello RJ45 Pin 3 Dsub9 Pin3 (RS232 RX) to Cello RJ45 Pin 4 Dsub9 Pin5 (Ground) to Cello RJ45 Pin 1 Cellocator Cello – Squarell 8000 Integration Manual Page 8 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 9: Setting Up The Cellocator Cello Using The Communication Center

    Cellocator protocol data forwarding packets (only type 7 is discussed in this manual), containing the data as it was received, without further processing or filtering. Cellocator Cello – Squarell 8000 Integration Manual Page 9 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 10 The indication bit of report Forwarded Message Code byte in this case will contain ‘0’. 2.4.3 Programming bit name: "Enable Data forwarding through log" Address: 285 bit 7. Cellocator Cello – Squarell 8000 Integration Manual Page 10 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 11 Requires acknowledge from the server (Message type 4) in order to erase the specific message from the log. The message 7 utilizes the same retransmission algorithms as other logged message types. Cellocator Cello – Squarell 8000 Integration Manual Page 11 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 12: Functionality Validation

    ‘Forward Data’ screen. To access this screen, select the Forward Data/MDT checkbox on the Forward Data tab. Forward Data Tab The Forward Data window is displayed, as shown below. Cellocator Cello – Squarell 8000 Integration Manual Page 12 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 13 After clicking the Send button, the unit should respond with the message above (including device type, serial number, DCF version, firmware version, etc). Cellocator Cello – Squarell 8000 Integration Manual Page 13 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 14: Server Side Routines For Handling Squarell Data And Data Requests To The Squarell Unit

    (1) / Simple payload – 0 Bit 7 Bit 6 Bit 6 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Cellocator Cello – Squarell 8000 Integration Manual Page 14 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 15 Current GSM Operator (4th and 5th nibble) (same as byte 25 of Msg type 0) Unit’s mode of operation (same as byte 20 of Msg type 0) Cellocator Cello – Squarell 8000 Integration Manual Page 15 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 16 Mode 2 (from GPS) Number of satellites used (from GPS) 30+X Longitude 31+X 32+X 33+X 34+X Latitude 35+X 36+X 37+X 38+X Altitude 39+X 40+X 41+X Cellocator Cello – Squarell 8000 Integration Manual Page 16 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 17 Detailed Per-Field Specifications Message header Identical to Message header of Command type 0, except the Message type field is sent as 5 (five). Cellocator Cello – Squarell 8000 Integration Manual Page 17 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 18 Note: There is an option to implement a server side application to upload Squarell firmware, as described in the “Upload protocol CORE devices XXXXXX.pdf”. Cellocator Cello – Squarell 8000 Integration Manual Page 18 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 19: Squarell's 8000 Series Rs232 Protocol

    FMS3,1<CR><LF> - To request the $FMS3 data REset4,0,0,0,0,0,0,0,0,0,0,0,0,0,0<CR><LF> - To reset the $FMS4 data SetKM,<value1><CR><LF> - To set the odometer SqTFU,<value1><CR><LF> - To set the total fuel used Cellocator Cello – Squarell 8000 Integration Manual Page 19 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 20 Real time <Engine Temperature> 1/1 & offset -40 Celsius Real time <Turbo Pressure> 2/100 Real time <Axle Weight 0> ½ kg Real time Cellocator Cello – Squarell 8000 Integration Manual Page 20 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 21 0=no 1=yes Real time <Tacho Driver 1 Card Present> 0=no 1=yes Real time <Tacho Driver 2 Card Present> 0=no 1=yes Real time Cellocator Cello – Squarell 8000 Integration Manual Page 21 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 22 Detailed description of the REset4 message This message can be used to Set/Reset all the Parameters in the $FMS4 message. The format of the message is: REset4,<value1>,…,<value14><CR><LF> Cellocator Cello – Squarell 8000 Integration Manual Page 22 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 23 This message can be used to Set/Reset the Total Fuel. The format of the message is: SetTEH,<value1><CR><LF> <Engine Hours> 1/20 hours Set value Cellocator Cello – Squarell 8000 Integration Manual Page 23 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 24 Calculating a Calibration Factor section for information on how to calculate a factor. To request the Calibration Factors the following message must be sent: Calibration, 1<CR><LF> Cellocator Cello – Squarell 8000 Integration Manual Page 24 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 25 This message is sent after receiving the following request message: SqTFUALL,1<CR><LF> $TFUALL,<value1>…<value4><CR><LF> < Squarell TFU 1 > total fuel used (litres) Count up Cellocator Cello – Squarell 8000 Integration Manual Page 25 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 26 19. <Future Use> 20. <Future Use> To configure the frequency time of the $FMS messages the following message must be sent: SetFMS,<value1>,…,<value20><CR><LF> Cellocator Cello – Squarell 8000 Integration Manual Page 26 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 27 To reset the fields the following message must be sent: ReSetDiag1,<value1>,…,<value20><CR><LF> Example: If you want to reset all the parameters send the following message to the Squarell device: ReSetDiag1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0<CR><LF> Cellocator Cello – Squarell 8000 Integration Manual Page 27 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 28: Calculating A Calibration Factor

    The Calibration factors can be checked on a Squarell Device by sending: Calibration, 1<CR><LF> The Squarell Device will reply with: $Calibration,<Speed Calibration Factor>,<Fuel Calibration Factor><CR><LF> Cellocator Cello – Squarell 8000 Integration Manual Page 28 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 29 The Calibration factors can be set on a Squarell Device by sending: SqCalib,<Speed Calibration Factor>,<Fuel Calibration Factor><CR><LF> The Squarell Device will reply with: $Calibration,<Speed Calibration Factor>,<Fuel Calibration Factor><CR><LF> Cellocator Cello – Squarell 8000 Integration Manual Page 29 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 30: Thresholds

    <THR Speed 4> value Integer Set value <THR RPM 4> value Integer Set value <THR Harsh Acceleration > value Integer Set value Cellocator Cello – Squarell 8000 Integration Manual Page 30 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
  • Page 31 13. <Future Use> 14. <Future Use> 15. <Future Use> 16. <Future Use> 17. <Future Use> 18. <Future Use> 19. <Future Use> 20. <Future Use> Cellocator Cello – Squarell 8000 Integration Manual Page 31 of 32 Copyright © 2013 by Pointer Telocation, Ltd.

  • Page 32: Dcf Initialization Routine

    During ignition on, press the brake pedal 12 times in 10 seconds. You will then see that the green LED of the device will flash on and off. Cellocator Cello – Squarell 8000 Integration Manual Page 32 of 32 Copyright © 2013 by Pointer Telocation, Ltd.
