CelloTrack Nano
Product Overview
Proprietary and Confidential
Version 1.4
Revised and Updated: September 17, 2018
Copyright © 2016 by Pointer Telocation, Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cellocator CelloTrack Nano and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pointer Cellocator CelloTrack Nano

Summary of Contents for Pointer Cellocator CelloTrack Nano

  • Page 1 CelloTrack Nano Product Overview Proprietary and Confidential Version 1.4 Revised and Updated: September 17, 2018 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 2: Legal Notices

    Customers of Pointer Telocation Ltd. Using, integrating, and/or selling the product for use in such applications do so at their own risk and agree to fully indemnify Pointer Telocation Ltd. For any resulting loss or damages.

  • Page 3: Intellectual Property

    Product Overview Intellectual Property Copyright in and to this document is owned solely by Pointer Telocation Ltd. Nothing in this document shall be construed as granting you any license to any intellectual property rights subsisting in or related to the subject matter of this document including, without limitation, patents, patent applications, trademarks, copyrights or other intellectual property rights, all of which remain the sole property of Pointer Telocation Ltd.

  • Page 4: Table Of Contents

    3.2.2 MultiSense Devices ...................... 29 CelloTrack Nano 20 Hardware Components..............30 The CelloTrack Nano 20 Hub ................... 33 MMI: Buzzer, LEDs and Button Functionality ..............33 CelloTrack Nano 20 Product Overview Page 4 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 5 Evaluation Suite Manual ....................46 Cellocator Programmer Manual ..................46 Integration Manual ...................... 46 6.10 Training Presentation ....................46 Appendix A: FCC Compliance Statement ................47 CelloTrack Nano 20 Product Overview Page 5 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 6 Table 13: Cellular / GPS Indications ..........................37 Table 14: CelloTrack Nano 20 Buttons ........................38 Table 15: CelloTrack Nano 20 Specifications ......................43 CelloTrack Nano 20 Product Overview Page 6 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 7: Introduction

    Bluetooth Low Energy (BT Smart) Printed Circuit Board Over The Air Ambient Light Sensor FOTA Firmware Update Over The Air Table 1: Definitions, Acronyms and Abbreviations CelloTrack Nano 20 Product Overview Page 7 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 8: References And Bibliography

    January 5, 2017 Add SAR to certifications list June 22, 2017 Add warning at Nano Power Harness September, 17, section 2018 Table 3: List of Changes CelloTrack Nano 20 Product Overview Page 8 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 9: Cellotrack Nano 20 At A Glance

    BT SIG certification is currently in the product evolution process CelloTrack Nano 20 Product Overview Page 9 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 10 Secures against Tampering and Theft: CelloTrack Nano 20 prevents losses due to theft, loss and misplacement using proximity, tampering and location sensing throughout the entire transport chain. CelloTrack Nano 20 Product Overview Page 10 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 11: Cellotrack Nano 20 System Communications

    Devices with the Nano 20 Hub section. The following diagram illustrates how the CelloTrack Nano 20 works. Figure 2: CelloTrack Nano 20 System Communications CelloTrack Nano 20 Product Overview Page 11 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 12: Main Features And Benefits

    Designed to meet EN12830 standards (temperature recorders for the transport, storage and distribution of chilled, frozen, deep-frozen/quick-frozen food and ice cream). Compliance with GDP – Good Distribution Practice (Europe, US). CelloTrack Nano 20 Product Overview Page 12 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 13: Intended Markets

    This helps to ensure adequate shelf-life time, guarantee compliance with shipment regulations, and even enables a real-time response in exceptional cases. Figure 3: Cold Chain Solution CelloTrack Nano 20 Product Overview Page 13 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 14: Rental Equipment Usage

    Figure 4: Rental Equipment Solution CelloTrack Nano 20 Product Overview Page 14 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 15: Employee Safety

    RF from reader Battery Required signal Medium Very low Very high strength to unit Range Up to 100m Up to 3-5 meters Up to 100m CelloTrack Nano 20 Product Overview Page 15 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 16 Monitoring capabilities Communicate with external No compliant sensors richness sensors in a wireless sensor availability. network mode (suitable for various scenarios, like CelloTrack Nano 20 Product Overview Page 16 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 17 Table 5: Lone Worker – CelloTrack Nano vs. Smartphone app CelloTrack Nano 20 Product Overview Page 17 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 18: Cellotrack Nano 20 Features And Capabilities

    USB Charging √ Memory Log √ System Modes √ Long life battery √ SIM card and MIM (SIM on chip) √ Communication Message Type √ CelloTrack Nano 20 Product Overview Page 18 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 19: Internal Sensors

    When movement amplitude crosses the hardcoded accelerations threshold, the device is considered as being in motion. After a period of time without any significant movement sensed, the device moves to a "Stationary" state. CelloTrack Nano 20 Product Overview Page 19 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 20 PL and only calls from the listed numbers are allowed to create a voice call. Up to 10 numbers can be defined in the whitelist. 3.1.1.7 Tampering Detection There are two ways in which the CelloTrack Nano can detect tampering: CelloTrack Nano 20 Product Overview Page 20 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 21: Prevent The Switching Off Of Nano Units

    As a result, in transparent mode the CelloTrack Nano 20 can be used as a gateway to unlimited MultiSense devices. BT SIG certification is currently in the product evolution process CelloTrack Nano 20 Product Overview Page 21 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 22: Gnss Module (Sirfstar V)

    Type-11 messages are with varying length and thus cannot be defined with the actual capacity for logged messages. These messages should use the entire log memory size actually allocated. CelloTrack Nano 20 Product Overview Page 22 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 23: Operational States

    All operation times stated in this section refer to operation at room temperature with an optimal cellular network and GNSS coverage and Max Tx power of the MultiSense device (+8dBm). CelloTrack Nano 20 Product Overview Page 23 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 24 Location is logged every 1 minute Location is logged every 5 minutes Location is logged every 10 minutes Table 8: Power Consumption – Offline Tracking CelloTrack Nano 20 Product Overview Page 24 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 25: Sim Card And Mim (Sim On Chip)

    SIM card with a temperature resistance range of -35°C to +85°C. The Nano unit also supports the SIM-on-chip option. Please contact your account manager for more information about this option. CelloTrack Nano 20 Product Overview Page 25 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 26: Communication Message Types

    Employee safety (lone worker) Parameters lay on type 0 only Flight mode templates added (with or without BLE shutdown) Low/High duty cycle BLE scanning CelloTrack Nano 20 Product Overview Page 26 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 27: Work Id

    The Work ID method is aligned with the backend need to track and report locations, events, exceptions and other supply chain attributes, separately for each shipment task. CelloTrack Nano 20 Product Overview Page 27 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 28: External Interface

    (which can be inserted into the relevant holes in the cradle), and a special clip add-on for belts (especially for lone worker scenarios). CelloTrack Nano 20 Product Overview Page 28 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 29: Multisense Devices

    WSN system. For a detailed description of the MultiSense device, refer to the CelloTrack MultiSense Product Overview. Figure 9: CelloTrack MultiSense device CelloTrack Nano 20 Product Overview Page 29 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 30: Cellotrack Nano 20 Hardware Components

    CelloTrack Nano Charger White charger with micro USB connector for US market. PN: 711-20082 CelloTrack Nano USB USB Data Cable data cable PN: 711-00326 CelloTrack Nano 20 Product Overview Page 30 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 31 20, Cradle kit, Magnetic kit, accessories, belt clip, modem PN: K091-001 (EU) recorder cable, recording K091-002 (US) adaptor, USB charger (EU or US), and MultiSense-TH. CelloTrack Nano 20 Product Overview Page 31 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 32 CelloTrack Nano Product Overview Name/Part Number Description Picture CelloTrack Nano Power Harness PN: 715-50400 Table 10: HW Components CelloTrack Nano 20 Product Overview Page 32 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 33: The Cellotrack Nano 20 Hub

    The full list of buzzer audio feedback is as follows: Event Description Buzzer sequence Power up Upon power-up (turning Short beep of 200mS Reset System reset (for any Short beep of 200mS reason) CelloTrack Nano 20 Product Overview Page 33 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 34 “window” is open. Once the Nano pairs with each MultiSense device, a long beep of two seconds is heard. Table 11: Buzzer Audio Feedback CelloTrack Nano 20 Product Overview Page 34 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 35: Cellotrack Nano 20 Leds

    (AC wall adaptor) or PC, the left LED will act as described below: These indications have the highest priority and they override all other indications on this LED. Table 12: Battery Indications CelloTrack Nano 20 Product Overview Page 35 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 36 Each pulse is 500mS ON and 500mS OFF. Cellular Status GNSS module Indications after power The indications look like the examples below for the first 5-10 seconds up (Built-In Self-Test) only: CelloTrack Nano 20 Product Overview Page 36 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 37: Cellotrack Nano 20 Buttons

    The two buttons are also used for pairing the MultiSense devices with the CelloTrack Nano 20, as described on page 38. Pressing Duration Left button Right button Both simultaneously T < 200mS Ignored CelloTrack Nano 20 Product Overview Page 37 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 38 5 Sec > T > 2 Sec Panic event Check-in event T > 5 Sec Power OFF Panic event MultiSense pairing window unit open Table 14: CelloTrack Nano 20 Buttons CelloTrack Nano 20 Product Overview Page 38 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 39: Pairing Multisense Devices With The Nano 20 Hub

    Micro USB connector, via which the unit can perform programming / configuration / charging / log download operations. GNSS module with an 18x18mm antenna. Reliable battery status report (%). IP66. CelloTrack Nano 20 Product Overview Page 39 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 40: Technical Specifications

    Packet Data TCP/IP, UDP/IP PDU mode Technology CSR SiRFstarV™ engine supporting Hybrid GNSS Sensitivity (tracking) -165dBm Acquisition (normal) Cold <35Sec, Hot<1Sec, Warm <9 Sec CelloTrack Nano 20 Product Overview Page 40 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 41 CAUTION: Risk of explosion if batteries are replaced by an incorrect type. Dispose of used batteries according to instructions. If the Nano is charging, the temperature sensor value is irrelevant. CelloTrack Nano 20 Product Overview Page 41 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 42 Unit passes all relevant UL regulation tests IEC 60529 – IP66 Unit passes all relevant IEC 60529 – IP66 regulation tests FCC Compliance Statement – see Appendix A CelloTrack Nano 20 Product Overview Page 42 of 47 Copyright © 2016 by Pointer Telocation, Ltd.
  • Page 43 According to IEC 62209-2, 2.5 cm from the body Dimensions and Weight Dimensions 86.2x59.1x22.7 mm Weight 94 gr Table 15: CelloTrack Nano 20 Specifications CelloTrack Nano 20 Product Overview Page 43 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 44: Cellotrack Nano 20 Release Package

    Sensors configuration tab Write to PL Dashboard / Sensors status tabs Download parameters File open File save Dashboard direct link Figure 11: Operation Flow CelloTrack Nano 20 Product Overview Page 44 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 45: Integration Package (Cellocator Gw)

    This document explains the unit’s serial communication structure. It describes every byte of the incoming /outgoing packets, which can be sent or received by the unit via the serial interface. CelloTrack Nano 20 Product Overview Page 45 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 46: Cellocator Integration Package

    This document provides the software integrator with information and hints on how to integrate an application with the CelloTrack Nano 20. 6.10 Training Presentation This documentation provides preliminary Integration Manual information through the beta phase. CelloTrack Nano 20 Product Overview Page 46 of 47 Copyright © 2016 by Pointer Telocation, Ltd.

  • Page 47: Cellotrack Nano 20 Product Overview
