Pointer Cellocator CelloTrack Nano Installation Manual

Hide thumbs Also See for Cellocator CelloTrack Nano:

Advertisement

Quick Links

CelloTrack Nano
Installation Guide
Proprietary and Confidential
Version 1.3
Revised and Updated: July 4, 2019
Copyright © 2018 by Pointer Telocation, Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cellocator CelloTrack Nano and is the answer not in the manual?

Questions and answers

Summary of Contents for Pointer Cellocator CelloTrack Nano

  • Page 1 CelloTrack Nano Installation Guide Proprietary and Confidential Version 1.3 Revised and Updated: July 4, 2019 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 2 Customers of Pointer Telocation Ltd. using, integrating, and/or selling the product for use in such applications do so at their own risk and agree to fully indemnify Pointer Telocation Ltd. for any resulting loss or damages.
  • Page 3 Installation Guide Intellectual Property Copyright in and to this document is owned solely by Pointer Telocation Ltd. Nothing in this document shall be construed as granting you any license to any intellectual property rights subsisting in or related to the subject matter of this document including, without limitation, patents, patent applications, trademarks, copyrights or other intellectual property rights, all of which remain the sole property of Pointer Telocation Ltd.
  • Page 4: Table Of Contents

    Installing the CelloTrack Nano in a cabin ............... 34 10.3 Installing the MultiSense device in a cargo box .............. 35 10.4 Installing the MultiSense and magnet at an entry point ........... 35 CelloTrack Nano Installation Guide Page 4 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 5: Introduction

    3 Dimensions Light Emitted Diode References Reference Cello Family Hardware Installation Guide CelloTrack T Family Overview CelloTrack T Introduction Battery Handling Procedure for Cellocator Units CelloTrack Nano Installation Guide Page 5 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 6: Cellotrack Nano Hardware Elements

    PN: 711-20083 CelloTrack Nano White charger with micro Charger US USB connector for US market. PN: 711-20082 CelloTrack Nano MicroUSB- USB data cable USB data cable CelloTrack Nano Installation Guide Page 6 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 7 Belt clip for Nano cradle. Belt Clip PN: 705-60904 CelloTrack Nano Includes 2 Nano double- Accessories sided adhesive sticker, 3 screws, 1 cable micro USB- PN: 712-00007 USB. CelloTrack Nano Installation Guide Page 7 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 8 PN: K091-001 (EU) recorder cable, recording K091-002 (US) adaptor, USB charger (EU or US), and MultiSense-TH. Table 1: CelloTrack Nano Hardware Elements CelloTrack Nano Installation Guide Page 8 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 9: Cellotrack Nano Interface

    CelloTrack Nano LEDs Buttons CelloTrack MultiSense Brand-able Label Humidity Sensor (MultiSense TH) Power Button Attachment Holes CelloTrack Nano Installation Guide Page 9 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 10: Preparing For Installation

    This section describes how to install the SIM card in the CelloTrack Nano.  To install the SIM card: 1. Using a Philips screwdriver, unscrew the screw on the back of the CelloTrack Nano, as indicated below. CelloTrack Nano Installation Guide Page 10 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 11 2. Slide the two sections of the CelloTrack Nano apart, to expose the PCB and SIM card holder, as shown below. 3. Insert the SIM card, as indicated below. CelloTrack Nano Installation Guide Page 11 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 12 2. Place the battery inside the device in the allotted slot, making sure that the battery’s positive (+) side faces in front of you (see below). CelloTrack Nano Installation Guide Page 12 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 13 3. Close the MultiSense device by screwing the two sections of the MultiSense device together in a clockwise direction. The two arrows on the side of the device’s casing should be aligned, as indicated below. CelloTrack Nano Installation Guide Page 13 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 14: Installation Instructions

    There are two ways in which the CelloTrack Nano can be mounted or attached to the relevant surface; either with the cradle (as described in the procedure below), or without the cradle. CelloTrack Nano Installation Guide Page 14 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 15 A, and screw them into the coin magnets, making sure the magnets are facing out, as shown in picture B. CelloTrack Nano Installation Guide Page 15 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 16 CelloTrack Nano Installation Guide CelloTrack Nano Installation Guide Page 16 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 17 CelloTrack Nano Installation Guide 2. Place the Nano unit in the cradle and attach to the required metallic surface. CelloTrack Nano Installation Guide Page 17 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 18 2. Screw into place (on a non-metallic surface). 3. Place the Nano unit in the cradle. CelloTrack Nano Installation Guide Page 18 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 19 2. Place the Nano unit in the cradle and attach to the required surface. CelloTrack Nano Installation Guide Page 19 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 20 2. Attach to the required surface by fastening the nylon strips to a suitable mounting point. 3. Place the Nano unit in the cradle. CelloTrack Nano Installation Guide Page 20 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 21 3. Place the Nano unit in the cradle and attach to the required belt (especially suitable for lone workers). CelloTrack Nano Installation Guide Page 21 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 22 1. Insert the two screws into the two round holes on each side of the MultiSense device, as indicated below. 2. Screw into place on the relevant surface. CelloTrack Nano Installation Guide Page 22 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 23 See below for an illustration. 2. Attach to the required surface by fastening the nylon strip to a suitable mounting point. CelloTrack Nano Installation Guide Page 23 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 24 File menu, select Open to choose the relevant Nano PL file. 7. For initial communications, the Nano COM port number should be set. Click display the Configuration dialog, as shown below. CelloTrack Nano Installation Guide Page 24 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 25 All MultiSense settings are defined in the Nano Editor, accessed by clicking then selecting the Sensors Configuration tab. Refer to Working with the Nano Editor section for more details. CelloTrack Nano Installation Guide Page 25 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 26: Charging The Battery

    The faster speed is automatically chosen when the source is recognized to be able to supply enough current. The charging current in this case is ~330mA so a complete charge will take less than 5 hours. CelloTrack Nano Installation Guide Page 26 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 27: Pairing The Nano Hub With Multisense Devices

    6. Once the pairing and resetting of the Nano device have been completed, reconnect the USB cable and click 7. Click to update the Programmer with the newly paired MultiSense units. CelloTrack Nano Installation Guide Page 27 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 28: Working With The Nano Editor

    Properties pane on the right. Note that MultiSense configuration can be performed only in the Nano Editor and not from the main Programmer window. CelloTrack Nano Installation Guide Page 28 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 29 3. Click the Legacy events type-11 configuration tab to set each legacy (type-0) event, meaning whether the events should also be sent in an “encapsulated” way over type-11 message or not. CelloTrack Nano Installation Guide Page 29 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 30: Updating The Nano Fw

    7. Upon completion, the COM port is reconnected by the Serial CSF STK Flasher tool. 8. Close the Serial CSF STK Flasher or disconnect and connect to another unit as required. CelloTrack Nano Installation Guide Page 30 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 31: Post-Installation

    Date of installation Results of installation test/issues found Results of communication test to the server/issues found Picture(s) of the installed device, as installed Other comments CelloTrack Nano Installation Guide Page 31 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 32: Installation Use Cases

    GPS signal is likely to be received. This kind of installation is required for metal environments (e.g. truck interiors), where the metal surface blocks the GPS signal. CelloTrack Nano Installation Guide Page 32 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 33 CelloTrack Nano Installation Guide CelloTrack Nano Cradle MultiSense CelloTrack Nano Cradle CelloTrack Nano Installation Guide Page 33 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 34: Installing The Cellotrack Nano In A Cabin

    GPS signal is likely with no interference in communications with the MultiSense devices located in the truck (in the two side-by-side images below). CelloTrack Nano Installation Guide Page 34 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 35: Installing The Multisense Device In A Cargo Box

    (with the magnet placed behind a black sticker to hold it in place), and standard door entrance (with the magnet attached to the door frame alongside the MultiSense). CelloTrack Nano Installation Guide Page 35 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
  • Page 36 CelloTrack Nano Installation Guide CelloTrack Nano Installation Guide Page 36 of 36 Copyright © 2018 by Pointer Telocation, Ltd.
