- Page 1 Neverdark CHALET-II (IN) Smart fireplace TECHNICAL DOCUMENTATION...
-
Page 3: Table Of Contents
CONTENT CONFIGURATION FIREPLACE Standard configuration Optional Extra THERMOBOXES FIREPLACE INTERFACES DIMENSIONS NICHE PREPARATION INSTALLATION Niche dimensions Niche requirements INSTALLATION FEATURES TECHNICAL INFORMATION Technical information Warnings... - Page 4 ATTENTION! This document, along with the User Manual, is a part of the device and is being delivered along with the fireplace (hereinafter collectively referred to as «Instructions»). If one or both of these documents weren't delivered with your fireplace, please contact the manufacturer prior to the installation and/or use of the fireplace.
-
Page 5: Standard Configuration
CONFIGURATION Standard configuration Smart fireplace Documentation (Standard top panel Black matte) 1 pc 1 set Power cable: Packaging Euro Plug — WAGO (fireplace length + 0.1m) 1 set 1 pc Fuel hose Decorative elements: decorative stones, 1 pc ceramic firewood, fiber for glow effect Mounting... -
Page 6: Optional Extra
Optional extra You can add any option listed below: Glass Border Remote Control (one or two ) code code GB (1, 2) Smart Home Custom Top сonnection (RAL Matte) module code code CT (RM) Enlarged Fuel Tank code 05 | optional extra... -
Page 7: Thermoboxes
THERMOBOXES You can also choose the Neverdark Thermobox for your fireplace. The Thermobox can withstand temperatures up to 200°C, allowing you to choose any material for lining the niche. Single-Sided Three-Sided code code Right Corner Room Divider code code Left Corner... -
Page 8: Fireplace Interfaces
FIREPLACE INTERFACES Flame sensor ATTENTION! Do not cover! Glow plug (candle) ATTENTION! Tray for decorative Do not cover! elements Air ventilation grids Fuel drainage unit (service only) Control panel cover Burner Power cable 220V 07 | fireplace interfaces... -
Page 9: Dimensions
DIMENSIONS Standard range Length, Depth, Height, Weight, Model Code С2-700-in Chalet-II 700 (in) C2-700-in.EFT С2-950-in Chalet-II 950 (in) C2-950-in.EFT С2-1200-in Chalet-II 1200 (in) 1200 C2-1200-in.EFT dimensions | 08... -
Page 10: Niche Preparation
NICHE PREPARATION Niche dimensions for the fireplace with standard fuel tank Power outlet or connection point in a niche Cable 3x2.5 Clearance 6 Clearance 6 WARNING! For correct Air supply operation of the 100 cm² Fireplace, it must be installed 100% min 20 horizontally according to the level! - Page 11 Niche dimensions for the fireplace with enlarged fuel tank Power outlet or connection point in a niche Cable 3x2.5 Clearance 6 Clearance 6 WARNING! For correct Air supply operation of the 100 cm² Fireplace, it must be installed 100% min 20 horizontally according to the level! Clearance 6...
-
Page 12: Niche Requirements
Alternatively, a non heat-resistant material + Min 500 mm to flammable Neverdark Thermobox objects from any closed side of the niche. WARNING! For safe and correct operation of the fireplace it is mandatory to provide an air supply opening (100 cm² at least) in the lower part of the niche. -
Page 13: Installation
INSTALLATION WARNING! 220V cable connection must be carried out by a qualified electrician. Mounting handles Cable 220V 3x2.5mm (option 2) Plug 220V (option 1) installation | 12... -
Page 14: Safety Instruction
FEATURES Technical information Fireplace model Parameters Chalet-II (In) Chalet-II (In) Chalet-II (In) 1200 Standard tank Tank volume, l Enlarged Fuel 12,4 15,0 Tank (EFT) Standard tank System volume, l Enlarged Fuel 13,6 17,2 Tank (EFT) Standard tank 2,9 | 6,3... - Page 15 fireplace. ATTENTION! Kindly follow next rules while using the Neverdark fireplace: Keep away from children; Ensure that the wall/table/floor on which you place the appliance can withstand its weight;...
- Page 16 NEVERDARK LLC 11 Kopernika St. Kyiv, Ukraine neverdark.one...
