- Page 1 Neverdark CHALET-I (EX) Smart fireplace TECHNICAL DOCUMENTATION...
-
Page 3: Table Of Contents
CONTENT CONFIGURATION INTERFACES Standard configuration Optional Extra THERMOBOXES INTERFACES General Fireplace DIMENSIONS Fireplace NICHE PREPARATION INSTALLATION Niche for the fireplace Niche requirements Niche for Standard ARS Niche for Standard ARS (with fuel canister) Niche for Mini ARS INSTALLATION Laying of communications for Standard ARS Laying of communications for S-ARS (with fuel canister) Laying of communications for Mini ARS Connecting communications to ARS... - Page 4 ATTENTION! This document, along with the User Manual, is a part of the device and is being delivered along with the fireplace (hereinafter collectively referred to as «Instructions»). If one or both of these documents weren't delivered with your fireplace, please contact the manufacturer prior to the installation and/or use of the fireplace.
-
Page 5: Standard Configuration
CONFIGURATION Standard configuration Smart fireplace (Standard top panel Black matte) Decorative elements: decorative stones, 1 pc ceramic firewood, fiber for glow effect Power cable: Euro Plug — WAGO (fireplace length + 0.1m) 1 set 1 set Communications for connecting ARS Documentation (length 2,5m) 1 set... -
Page 6: Optional Extra
Optional extra You can add any option listed below: Glass Border Remote Control code code Smart Home Custom Top сonnection (RAL Matte) module code code CT (RM) ARS (the external control and refuelling module) is available in three configurations. Mini ARS (down) code Standard ARS M-ARS(down) -
Page 7: Thermoboxes
THERMOBOXES You can also choose the Neverdark Thermobox for your fireplace. The Thermobox can withstand temperatures up to 200°C, allowing you to choose any material for lining the niche. Chalet-I Box Chalet-I Box Standard Installation Hidden Installation code code F-C1-B-650... -
Page 8: Interfaces
INTERFACES General Fireplace Communications ARS-Fireplace (length 2,5m) АRS 07 | general... -
Page 9: Fireplace
Fireplace Flame sensor ATTENTION! Do not cover! Glow plug (candle) ATTENTION! Do not cover! ATTENTION! Do not cover! Air ventilation grids Burner Tray for decorative elements Fuel line connector ARS connection port Power cable 220V Fuel drainage unit (service only) fireplace interfaces | 08... -
Page 10: Ars
Standard ARS Touch display Power button Fuel hose Fuel line connector ARS connection port 09 | ARS interfaces... - Page 11 Mini ARS (up) Fuel hose Touch display connector Power button Magnetic frame ARS connection port Fuel line connector Mini ARS (down) Magnetic frame Touch display Fuel hose connector Power button Fuel line connector ARS connection port ARS interfaces | 10...
-
Page 12: Dimensions
DIMENSIONS Fireplace Standard range Length, Depth, Height, Weight, Model Code Chalet-I 650 (ex) C1-650-ex 11 | fireplace dimensions... -
Page 13: Ars
Standard ARS Mini ARS (Up and Down) ARS dimensions | 12... -
Page 14: Niche Preparation
NICHE PREPARATION Niche for the fireplace Communications min 40x40 Power outlet or connection point in a niche WARNING! For correct Cable 3x2.5 operation of the Fireplace, it must be installed 100% horizontally according to the level! Clearance 6 Communications 40 mm² supply supply min 20... -
Page 15: Niche Requirements
Min 1000 mm to which withstands 150°C flammable objects from at least. any exposed side of the niche. Alternatively, a non heat-resistant material + Min 500 mm to flammable Neverdark Thermobox objects from any closed side of the niche. niche requirements | 14... -
Page 16: Niche For Standard Ars
Niche for Standard ARS To correctly mark the Tunnel must be mounting holes in applicable for 2,5 m the wall, temporarily communications cable insert the ARS min 120 Opening for communications 15 | niche for Standard ARS... -
Page 17: Niche For Standard Ars (With Fuel Canister)
Niche for Standard ARS (with fuel canister) To correctly mark the Tunnel must be mounting holes in applicable for 2,5 m the wall, temporarily communications cable insert the ARS Opening for communications niche for Standard ARS | 16... -
Page 18: 17 | Niche For Mini Ars
Niche for Mini ARS (Up and Down) Tunnel must be applicable for 2,5 m To correctly mark the communications cable mounting holes in the wall, temporarily insert the ARS Opening for communications 17 | niche for Mini ARS... -
Page 19: Installation
INSTALLATION Laying of communications for Standard ARS laying of communications | 18... -
Page 20: Laying Of Communications For Standard Ars
Laying of communications for Standard ARS (with fuel canister) 19 | laying of communications... -
Page 21: Laying Of Communications For Mini Ars
Laying of communications for Mini ARS (Up and Down) laying of communications | 20... -
Page 22: Connecting Communications To Ars
Connecting communications to ARS Standard ARS Fireplace Fuel line connector ARS connection port Mini ARS Fireplace Fuel line connector ARS connection port 21 | connecting communications to ARS... -
Page 23: Installation Of Standard Ars | 22
Installation of Standard ARS Screw 6 pc, 3x20 installation of Standard ARS | 22... -
Page 24: Installation Of Standard Ars (With Fuel Canister)
Installation of Standard ARS (with fuel canister) Screw 6 pc, 3x20 23 | installation of Standard ARS... -
Page 25: Installation Of Mini Ars | 24
Installation of Mini ARS (Up and Down) Screw 4 pc, 3x20 Magnetize installation of Mini ARS | 24... -
Page 26: Connecting Communications To The Fireplace
Connecting communications to the fireplace Standard ARS Fireplace Fuel line connector ARS connection port Mini ARS Fireplace Fuel line connector ARS connection port 25 | connecting communications to the fireplace... -
Page 27: Installation Of The Fireplace
Installation of the fireplace WARNING! 220V cable connection must be carried out by a qualified electrician. Plug 220V (option 1) Cable 220V 3x2.5mm (option 2) installation of the fireplace | 26... -
Page 28: Features
FEATURES Technical information Fireplace model Parameters Chalet-I (Ex) Tank volume, l System volume, l Consumption, I/h 0,4 | 1,0 (min | max) Average consumption, I/h (min | max) Burning time, h 4,4 | 11,0 (min | max) Room size, m 27 | 68 (with I without ventilation system) Max power consumption, kW... - Page 29 fireplace. ATTENTION! Kindly follow next rules while using the Neverdark fireplace: Keep away from children; Ensure that the wall/table/floor on which you place the appliance can withstand its weight;...
