- Page 1 Neverdark CHALET-I (IN) Smart fireplace TECHNICAL DOCUMENTATION...
- Page 3 CONTENT CONFIGURATION FIREPLACE Standard configuration Optional Extra THERMOBOXES FIREPLACE INTERFACES DIMENSIONS NICHE PREPARATION INSTALLATION Niche dimensions Niche requirements INSTALLATION FEATURES TECHNICAL INFORMATION Technical information Warnings...
- Page 4 ATTENTION! This document, along with the User Manual, is part of the device and is being delivered along with the fireplace (hereinafter collectively referred to as «Instructions»). If one or both of these documents weren't delivered with your fireplace, please contact the manufacturer prior to the installation and / or use of the fireplace.
- Page 5 CONFIGURATION Standard configuration Smart fireplace Fuel hose (Standard top panel Black matte) 1 pc 1 pc Power cable: Packaging Euro Plug — WAGO (fireplace length + 0.1m) 1 set 1 pc Documentation Decorative elements: decorative stones, 1 set ceramic firewood, fiber for glow effect 1 set...
- Page 6 Optional extra You can add any option listed below: Glass Border Remote Control code code Smart Home Custom Top сonnection (RAL Matte) module code code CT (RM) 05 | optional extra...
- Page 7 THERMOBOXES You can also choose the Neverdark Thermobox for your fireplace. The Thermobox can withstand temperatures up to 200°C, allowing you to choose any material for lining the niche. Chalet-I Box Chalet-I Box Standard Installation Hidden Installation code code F-C1-B-650...
- Page 8 FIREPLACE INTERFACES Fire sensor ATTENTION! Do not cover! Glow plug (candle) ATTENTION! Do not cover! Control panel cover ATTENTION! Do not cover! Air ventilation grids Burner Tray for decorative elements Fuel drainage unit Power cable 220V (service only) 07 | fireplace interfaces...
- Page 9 DIMENSIONS Standard range Length, Depth, Height, Weight, Model Code Chalet-I 650 (in) C1-650-in dimensions | 08...
- Page 10 NICHE PREPARATION Niche dimensions WARNING! For correct Power outlet operation of the smart or connection point in a niche fireplace, it must be Cable 3x2.5 installed 100% horizontally according to the level! Clearance 6 supply supply min 20 100 cm² 100 cm²...
- Page 11 Min 1000 mm to which withstands 150°C flammable objects from at least. any exposed side of the niche. Alternatively, a non heat-resistant material + Min 500 mm to flammable Neverdark Thermobox objects from any closed side of the niche. niche requirements | 10...
- Page 12 INSTALLATION WARNING! 220V cable connection must be carried out by a qualified electrician. Plug 220V (option 1) Cable 220V 3x2.5mm (option 2) 11 | installation...
- Page 13 FEATURES Technical information Fireplace model Parameters Chalet-I (In) Tank volume, l System volume, l Consumption, I/h 0,4 | 1 (min | max) Average consumption, I/h (min | max) Burning time, h 3,0 | 7,5 (min | max) Room size, m 27 | 68 (with I without ventilation system) Max power consumption, kW...
- Page 14 fireplace. ATTENTION! Kindly follow next rules while using the Neverdark fireplace: Keep away from children; Ensure that the wall/table/floor on which you place the appliance can withstand its weight;...
- Page 16 NEVERDARK LLC 11 Kopernika St. Kyiv, Ukraine neverdark.one...
