Operating Instructions
Spindle Moulder
TF 170 E - 230 V
TF 170 E - 400 V
TF 170 E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TF 170 E-230V and is the answer not in the manual?

Questions and answers

Related Manuals for Holzstar TF 170 E-230V

Summary of Contents for Holzstar TF 170 E-230V

  • Page 1 Operating Instructions Spindle Moulder TF 170 E - 230 V TF 170 E - 400 V TF 170 E...

  • Page 2: Table Of Contents

    5.1 Delivery and Transport ........8 Fax: 0049 (0) 951 96555-55 5.2 Packaging ............9 5.3 Storage ............... 9 E-Mail: info@holzstar.de 6 Description of the device ..... 10 URL: www.holzstar.de 6.1 Scope of delivery ..........10 7 Setting up and connection ....10 7.1 Requirements for the place of operation...

  • Page 3: Introduction

    You have made an excellent choice in purchasing a 1.3 Disclaimer HOLZSTAR spindle moulder. Carefully read the operating instructions prior to All data in this operation manual has been compiled on commissioning.

  • Page 4: Operator Responsibility

    Safety - Operators shall obtain information about valid oc- cupational safety regulations and determine addi- ATTENTION! tional hazards as part of a risk assessment which This combination of symbol and signal term indica- result from the specific operating conditions at the tes a potentially hazardous situation which may machine's installation location.

  • Page 5: Personal Protective Equipment

    Safety Operating staff: Protective gloves Operating staff has undergone an induction by the ope- rator about the entrusted tasks and potential hazards re- The protective gloves provide protection for the sulting from improper behaviour. Tasks which go beyond hands against sharp-edged components, as well as normal operation may only be carried out by the operator against friction, abrasions or deeper injuries.

  • Page 6: General Safety Instruction

    Safety 2.6 General safety instruction - Do not use tools in a damp or wet environment. - Ensure that the work area is well lit. This machine is equipped with various safety devices de- - Do not use tools in the presence of flammable li- signed to protect both the operator and the machine.

  • Page 7: Intended Use

    Intended Use Intended Use Technical Data The TF 170 E table router is used for routing boards and TF 170 E 230 V 400 V strips of wood with versatile adjustable angles. It is pos- Length (Product) [mm] 1000 1000 sible to process solid wood, chipboard, panels and profi- les.

  • Page 8: Type Plate

    Transport, packaging, storage Transport, packaging, storage Specifications concerning noise of the device 5.1 Delivery and Transport Level of noise without load LpAeq =81.7 A in the place dB(A) During transport or storage of the machine, measures of operation with load LpAeq =89.5 must be taken to protect the machine from excessive (LpAeq)

  • Page 9: Packaging

    Transport, packaging, storage General risks during internal transport Step 1: Prepare a high-lift truck (Pos. D, Fig. 3) or a ma- nual lifting carriage (Pos. F, Fig. 3) with sufficient lifting capacity, WARNING: DANGER OF TIPPING Step 2: Put the forks (Pos. G) below the machine, as shown in the illustration 3.

  • Page 10: Description Of The Device

    Description of the device Description of the device - The underground must be even, solid and vibration- free. - The underground must not allow any lubricants to The illustrations in these operating instructions pass through. serve the general comprehension and may deviate from the actual type.
  • Page 11 Setting up and connection Step 2: Assemble the stand board with the bolts and Step 6: Place the machine on the base with the help of a screws. second person Fig. 6: Assembly the stand board Step 3: Attach all four side panels as shown in Fig.7. Fig.

  • Page 12: Connection Of The Exhaustion System

    Operation 7.4 Connection of the exhaustion sy- stem ATTENTION! In order to ensure sufficient stability of the machine, it should be fixed to the ground with screws. ATTENTION! The spindle moulder is delivered in a wooden box and is already largely assembled. Only a few parts have to be Work on the machine only with the exhaustion system assembled after delivery.

  • Page 13: Adjusting The Height Of The Milling Spindle

    Operation - Check regularly that safety covers are mounted properly and that they are not damaged. Repair Use protective goggles! damaged covers immediately or replace with other ones by a qualified person. - Do not put the machine into operation with the Wear safety boots! cover removed.

  • Page 14: Workflow

    Operation Step 2: Loosen the lock handle (Pos. A, Fig. 15) and pi- Never set the rulers while the machine is being operated! vot the motor assembly toward the spindle. Step 1: Perform the lateral adjustment of the fence plates. Step 3: Reposition the belt to the desired speed and ten- Step 2: Keep the opening for the tool to a minimum.
  • Page 15 Operation Verschlussknauf Druckblock Druckblock Abführanschlag Fig. 16: Description of the limit stop device Use protective goggles! Moulding of workpieces with small cross-section Tools: Wear safety boots! Choose the tool suitable for manual feeding. Working cycle: Wear protective clothes! Adjust the moulding machine and put both halves of the ruler close to the tool.

  • Page 16: Milling With Collars

    Operation Fräser Keine ausreichende Schnittktreis Lagerfläche Anlaufring Werkstück Vorderer Anschlag Hinterer Anschlag Fräser Schnitttiefe Zuführrichtung Tisch falsch Fig. 18: Milling When the shaping operation removes the entire edge of Fig. 21: Milling with collars without sufficient starting surface the work (i.e. jointing or making a full bead), the shaped Figure 22 illustrates sufficient bearing surface.

  • Page 17: Replacement Of Moulding Tools

    Care, maintenance and repair Using the collar above the cutter (Fig. 25) offers the ad- Step 2: Before mounting tool (Pos. A, Fig. 28) make sure vantage of the cut not being affected by slight variations in that spacing rings (Pos. E, Fig. 28) are clean and the stock's thickness.

  • Page 18: Care After Work

    Care, maintenance and repair - Even if the machine is stopped, the power supply is Step 7: Check the machine regularly: not interrupted. Always remove the plug from the - Appropriate tension of the drive belt. socket. - Loose bolts and nuts. - Keep your fingers away from belts and pulleys.

  • Page 19: Troubleshooting

    Troubleshooting 9.2.5 Change of the drive belt The drive belt must not come into contact with oil or grease. It must be checked regularly for wear, cracks or brittleness. Replace the drive belt if necessary (at least once a year). Step 1: Switch off the machine and disconnect the power plug from the socket.
  • Page 20 Troubleshooting Fault Possible cause Solution The edge splinters off at a cross 1. The properties of this cut type. Perform the crossfiber cuts first, and then fiber cut. finish the fiber cut. Use a metal block to support the end of the cut.

  • Page 21: Disposal, Recycling Of Used Devices

    Disposal, recycling of used devices 11 Disposal, recycling of used 12.1 Ordering spare parts devices The spare parts may be purchased with the authorised dealer. Please take care in your own interest and in the interest of the environment that all component parts of the machine Indicate the following basic information for requests or are only disposed of in the intended and permitted way.

  • Page 22: Spare Parts Drawings Tf 170 E

    Spare parts 12.2 Spare parts drawings TF 170 E The following drawings are intended to identify the required spare parts in the event of service. If applicable, submit a copy of the parts drawing including the highlighted components to your authorised retailer. Spare parts drawing 1 Fig.
  • Page 23 Spare parts Spare parts drawing 2 Fig. 31: Spare parts drawing 2 - Spindle Moulder TF 170 E (230 V and 400 V) TF 170 E | Version 1.07...
  • Page 24 Spare parts Spare parts drawing 3 Fig. 32: Spare parts drawing 3 - Spindle Moulder TF 170 E (230 V und 400 V) TF 170 E | Version 1.07...
  • Page 25 Spare parts Spare parts drawing 4 Fig. 33: Spare parts drawing 4 - Spindle Moulder TF 170 E (230 V and 400 V) TF 170 E | Version 1.07...

  • Page 26: Electrical Circuit Diagram

    Electrical circuit diagram 13 Electrical circuit diagram 230 V Model 400 V Model Fig. 34: Electrical circuit diagramm TF 170 E (top: 230 V; bottom: 400 V) TF 170 E | Version 1.07...

  • Page 27: Ec Declaration Of Conformity

    According to machine directive 2006/42/EC Annex II 1.A Manufacturer/distributing company: Stürmer Maschinen GmbH Dr.-Robert-Pfleger-Str. 26 D-96103 Hallstadt herewith declares that the following product Product group: Holzstar® Woodworking machines Maschine type: Spindle Moulder Designation of the machine*: Item number *: TF 170 E 230V 5901917...
  • Page 28 www.holzstar.de...

This manual is also suitable for:

Tf 170 e-400v59019175901918
