Booth BRW3 Product Manual

Hydrocarbon series remote beer coolers

Hide thumbs

Table Of Contents

Quick Links

Download this manual

Product Manual

BRW3 Hydrocarbon Series

Remote Beer Coolers

3B6517-C

Table of Contents

Need help?

Do you have a question about the BRW3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Booth BRW3

Page 1 Product Manual BRW3 Hydrocarbon Series Remote Beer Coolers 3B6517-C...
Page 2: Table Of Contents
Eliwell Control - Setting adjustment Introduction The BRW3 Hydrocarbon range of remote coolers is designed in a modular fashion to cover a large range of options which can be specified at time of order. The individual modules are detailed towards the end of this guide, but in summary they comprise the following: •...
Page 3: Removal, Transport & Disposal
It is illegal to simply scrap a refrigeration unit. Before a unit can be scrapped it must first have the gas removed by a specialist using specialist equipment. Please contact Booth Dispensers Ltd, who will be happy to provide a quotation for disposal.
Page 4: Specification
Specifications Dimensions Cubigel NPY12RA 580mm(W) (BRW35H/36H) 660mm(D) Compressor Cubigel NPT16RA 900mm(H) (BRW38H) Dry Weight BRW35H 65Kg BRW36H 70Kg BRW38H 65Kg This product contains Propane Refrigerant gas with a GWP of 3 in a hermetically sealed system. Wet Weight BRW35H 125Kg BRW36H 135Kg BRW38H 125Kg Supply...
Page 5: Model Numbering Convention
Model Numbering Convention Unit number ( Z Z ) ( Y ) ( X ) ( W ) ( V ) - - - Key: (ZZ) Base Type Module Type Lid Type Coil Type or Special Version Code Number of coils - - - Coil type and number of coils repeated as necessary Reference...
Page 6 Model Numbering Convention Continued Reference Part # Description LIDS 1A5123 1 piece lid, SPC43 pump 1A5125 1 piece lid, March May pump 1A5124 1 piece lid, SPC44 pump 1A5731 1 piece lid, SPC18 pump 1A5308 2 piece lid, SPC43 pump 1A5315 2 piece lid, March May pump 1A5309...
Page 7: Eliwell Control - Setting Adjustment
Disclaimer Booth Dispensers Ltd do not cover control settings under warranty and will not accept liability for any loss or damage caused by the incorrect setting of the control...
Page 8 Eliwell Control - Setting adjustment Please read all of these instructions carefully. Ensure that the cooler has been successfully PAT tested before use. Please note that the controller will wait for a time before starting up. When in ‘energy saving’ mode ‘EnS’ will be displayed on the screen. Current Ice Bath Temperature The default value displayed on the screen is the temperature that is currently being measured by the probe within the ice bath.
Page 9: Schematics
Schematics BRW35H & BRW38H Base (Integral) Wiring Schematic 3B6517-C...
Page 10 Schematics BRW36H Base (Split) Wiring Schematics 3B6517-C...
Page 11 Schematics BRW3 - Module ‘B’ Wiring Schematics 3B6517-C...
Page 12 Schematics BRW3 - Module ‘G’, ‘I’ & ‘T’ Wiring Schematics 3B6517-C...
Page 13 Schematics BRW3 - Module ‘E’ & ‘M’ Wiring Schematics 3B6517-C...
Page 14 Schematics BRW3 - Module ‘X’ Wiring Schematics 3B6517-C...
Page 15 Schematics BRW3 - Module ‘Z’ Wiring Schematics 3B6517-C...
Page 16: Fault Finding
Fault Finding 3B6517-C...
Page 17 Replacement Parts - BRW35H/38H Base 3B6517-C...
Page 18: Replacment Parts
Replacement Parts - BRW36HD Base 3B6517-C...
Page 19 Notes 3B6517-C...
