- Page 1 Product Manual BRW1H 3B7295-B...
-
Page 2: Table Of Contents
Model Numbering Convention Introduction The BRW1H models are a range python temperature cooling units with various control options of variable mechanical, digital and energy saving digital thermostats. The individual modules are detailed later on in this guide, but in summary they comprise the following: •... -
Page 3: Removal, Transport & Disposal
It is illegal to simply scrap a refrigeration unit. Before a unit can be scrapped it must first have the gas removed by a specialist using specialist equipment. Please contact Booth Dispensers Ltd, who will be happy to provide a quotation for disposal. -
Page 4: Specification
Specifications Dimensions 451mm(W) Huyai (Cubigel) 371mm(D) Compressor NLY45RA 730mm(H) Dry Weight Nominal 28.8Kg This product contains Propane Refrigerant gas with a GWP of 3 in a hermetically sealed system. Wet Weight Nominal 40Kg Supply R290 230Vac/50Hz Refrigerant Rated Input SN (+10°C to Climate Class 485W +32°C) -
Page 5: Installation
Installation Installation The unit must be installed by a competent person. If unit is to be free standing, it must be placed on a firm level surface capable of supporting the weight of the machine when the bath is filled. It is important that the ventilation openings in the machine are not blocked to allow the free movement of air. -
Page 6: Model Numbering Convention
Model Numbering Convention Unit number ( BRW17H ) ( X ) ( Y ) ( Z ) Key: (BRW17H) Base Type Module Type Pump Type Reference Part # Description Base Type BRW18H Badse Unit Reference (X) Part # Description 1A6384 Digital Eliwell 1A6385 1A6424... -
Page 7: Schematics
Schematics BRW1H Base Wiring Schematic 3B7295-B... - Page 8 Schematics BRW1H - Eliwell Module Wiring Schematics 3B7295-B...
- Page 9 Schematics BRW1H - Mechanical Module Wiring Schematics 3B7295-B...
- Page 10 Schematics BRW17H - DXF Module Wiring Schematics 3B7295-B...
-
Page 11: Fault Finding
Fault Finding Prior to any fault finding, please ensure all connections to the chiller are sound and that the incoming supply is turned on. Ensure that all electrical connections to the chiller and in the chiller are secure and in good condition, the power is on and that the chiller has had adequate time to reach operating temperature. -
Page 12: Replacment Parts
Replacement Parts 3B7295-B... -
Page 13: Notes
Notes 3B7295-B... - Page 14 Notes 3B7295-B...
- Page 15 Page Left Intentionally Blank 3B7295-B...
- Page 16 Booth Dispensers Limited, 101 Moor Park Avenue, Blackpool, Lancashire, FY2 0LZ, UK. +44 1253 501800 Website: www.booth-dispensers.co.uk/...
