User Manual ► FEISOL CT-3301, CT-3401 and CT-3402

Mount and Center Column Installation

For exchanging Mounts (flat Ball Head Mount / Center Column Mount / Leveling Base) on

the Tripod, unscrew the three set screws at the side of the mainframe using the included

hex key (see picture), insert desired Mount and re-tighten the three set screws. To avoid

possible damage to the screws or Tripod, do not over-tighten them.

B. Leg Tension Adjustment

Insert the two hexagonal wrenches (included) into the two screws at the base of the leg

(see picture) and tighten or loosen them to the desired friction, by turning the wrenches in

opposite directions.

WWW.FEISOL.NET

Page 1 of 4

Need help?

Do you have a question about the CT-3301 and is the answer not in the manual?

Page 1 User Manual ► FEISOL CT-3301, CT-3401 and CT-3402 Mount and Center Column Installation For exchanging Mounts (flat Ball Head Mount / Center Column Mount / Leveling Base) on the Tripod, unscrew the three set screws at the side of the mainframe using the included hex key (see picture), insert desired Mount and re-tighten the three set screws.
Page 2 (e.g. backpack, weight bags) to be attached to the tripod. The Hook can be screwed into the bottom side of the Mounting Plate, and is pre-installed on optional Center Column Kits (see picture). WWW.FEISOL.NET © FEISOL INC, USA Page 2 of 4...
Page 3 Head is in the locked position and that the Twist Lock of the Center Column is securely locked, screw the Ball Head onto the mounting screw by turning the Ball Head clockwise (see picture). Do not over-tighten. WWW.FEISOL.NET © FEISOL INC, USA Page 3 of 4...
Page 4 Note: Damage to your Tripod’s Carbon Tubes or Aluminum parts can occur if they are dropped, squeezed, overloaded, or forced downward (e.g. into sand dunes or snowbanks). Exercise caution to avoid such conditions. WWW.FEISOL.NET © FEISOL INC, USA Page 4 of 4...
