22Y S -Box Installation Manual
SBB -CX4B
Model Name :
LED Signage Box for XHB Series Cabinet
Model Code: SBB - CX4BPES/**
Ver 1.3
Innovative Product R&D Lab.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 22Y SBox and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung 22Y SBox

Summary of Contents for Samsung 22Y SBox

  • Page 1 22Y S -Box Installation Manual SBB -CX4B Model Name : LED Signage Box for XHB Series Cabinet Model Code: SBB - CX4BPES/** Ver 1.3 Innovative Product R&D Lab.

  • Page 2: Revision History

    Revision History Version Date (Y/M/D) Description 2022/05/27 New Release Delete Z-Case introduction, delete model description other than Outdoor (4page), add reminder related to remote control, add optical module and optical cable specifications 2023/05/25 Add SW update contents 2023/06/14 Add IG Power case 2023/08/29 Device Care Innovative Product R&D Lab.
  • Page 3 Index 1. Product’s Description 2. S -Box Install preparations 3. S -BOX Installation and Connection 4. Setting and guide 5. SW Update Innovative Product R&D Lab.

  • Page 4: Product's Description

    1.Product’s Description Innovative Product R&D Lab.
  • Page 5 Product’s Description Product Appearance & Information Model SBB-CX4BPES/** Remarks Innovative Product R&D Lab.
  • Page 6 Product’s Description CX4B (Outdoor) Support Model XHB, XLB Maximum resolutions 4K UHD (3840 x 2160) Frame Rate 50/60㎐ DP 1.4a 1 (DP 1.2a) HDMI 2.1 Input USB 2.0 12G-SDI Output Optic (QSFP+) 4 (LR4) Service port (DVI type) Others RS232C In AI Processing, HDR10, HDR10+ Function Gen-lock, Frame-lock, Phase Offset...
  • Page 7 Product’s Description ITEM SBB -CX4B Support Model XHB,XLB Pontus-M SCALER FPGA KU060, K200T Screen Resolution Input HDMI(2), DP(1), USB(2) Connectivity Audio Out Optical (2CH, PCM only) Video Out QSFP+ x4EA Bit-depth (bit) 10bit (RGB 4:4:4) Power 78W, DC 19V, 4.1A TIZEN 6.5 Magic Info MagicINFOS10...
  • Page 8 Product’s Description Type CX4B Set Size [WxDxH][mm] 440.0 x 340.1 x 60.5 (without Foot) Weight 3.95kg Description ASSY COVER-TOP PCB MAIN PCB FPGA BRACKET-SUPPORT ASSY BRACKET P-GUIDE ASSY BRACKET-PCB 항목 S-BOX Width (A, mm) 440.0 Length (B, mm) 340.1 Depth (C, mm) 60.5 Weight (kg) 3.83...
  • Page 9 Install preparations 2. S -Box Innovative Product R&D Lab.
  • Page 10 2. S -Box Install preparations ① Remove the tape of the top packing BOX and open the box. Check the following accessory list list while taking out the accessory components loaded in the Top–Cushion. Power cord by region POWER CODE After removing the top-cushion, take out the S-BOX inside the PE BAG and open it.
  • Page 11 3. S -BOX - Installation and connection Innovative Product R&D Lab.
  • Page 12 3. S -BOX Installation and Connection  CX4B Front/Back Designation Front DVI-OUT IR Rx / Power Btn USB 2.0 (monitoring) ※ Remote control receiver *The DVI-out is used only for service purposes, so be careful not to use it when connecting the actual cabinet. Rear HDMI HDMI...
  • Page 13 3. S -BOX Installation and Connection  S -BOX Installation Order (①S -BOX Installation) ① It is recommended to install on the 19inch server rack. Install the vents so that they are open, and do not turn sideways or upside down. If you block the vent, the product may overheat, so be careful.
  • Page 14 3. S -BOX Installation and Connection  S -BOX Installation Order (①S -BOX Installation) ① In Source, enter the video signal into S-BOX as HDMI or DP. (※ HDMI cable should support 2.1 / DP cable should support 1.4 specifications) * Convert to the PORT connected by the source button of the remote control and use it.
  • Page 15 3. S -BOX Installation and Connection  Optical cable connection ① Optical cable connection Connect the optical module to the optical module terminal of the S-Box and the optical module terminal of the Z-Case. ※ When connecting the optical module, push it until it clicks. 광모듈...
  • Page 16 3. S -BOX Installation and Connection  Optical cable connection ① Optical Module Connection - Notes The SPEC specification of the optical module is QSFP+40GBASE-LR4 specification. The optical module available for CX4B is connected by referring to the LR4 specification in the following optical module list. Parameter Min.
  • Page 17 3. S -BOX Installation and Connection  Optical cable connection ② Cable connection -In case of Duplex type, unlock the locking structure and connect one by one like Simplex. - Special attention is required when connecting the connector because it is a common cause of malfunction. Duplex 2 Connector Simplex...
  • Page 18 3. S -BOX Installation and Connection  Optical cable connection ② Cable connection (installation example) Z-Case S-BOX When connecting to the LC type cable, the transmission/reception unit of the S-BOX and Z- Case optical modules must be checked and connected. TRANSMISSION UNIT OF S-BOX OPTICAL MODULE ->...
  • Page 19 3. S -BOX Installation and Connection  Optical cable connection ③ Handling and Installing Optical Cables  For stability, when using SMF, single mode cable of LC/ UPC to LC/ UPC connector type should be used. Single Mode  When using MMF, you should use Multi Mode cable. Multi Mode ...
  • Page 20 3. S -BOX Installation and Connection  Optical cable connection ④ Handling and Installing Optical Cables  Install the cable so that the minimum force is applied to the optical fiber in consideration of the pulling force.  * For tensile characteristics, refer to the cable specifications used ...
  • Page 21 3. S -BOX Installation and Connection  Optical cable connection ⑤ Handling and Installing Optical Cables  When you want to fix it to Tray, etc., gently fix it so that it is not pressed directly on the optical cable. Torsion Tighten it with Tighten it properly with...
  • Page 22 3. S -BOX Installation and Connection  CabinetConnection ① Z-card ↔ Cabinet connection map Open the Z-case and check the LAN port. Using the Lan Cable of the XHB Accessory Kit. Connect the Lan cable. Accessory List Item/Qty Role Photo ※...
  • Page 23 3. S -BOX Installation and Connection  CabinetConnection ② Z-card ↔ Cabinet connection map  Connect the waterproof connector on the opposite side of the data cable to the XHB cabinet. ※Please refer to the XHB manual for detailed installation specifications. Accessory List Item/Qty Role...
  • Page 24 3. S -BOX Installation and Connection  CabinetConnection ① Overall system configuration diagram (Full redundancy)  CX4B – The Redundancy specification of XHB can be implemented using Z-Card.  In the case of full redundancy, separate it into Z-Case for S-BOX Forward and Z-Case for redundancy. Control Room Forward Pilar 1...
  • Page 25 3. S -BOX Installation and Connection  CabinetConnection ② Overall system configuration diagram ( M ixed redundancy)  CX4B – The Redundancy specification of XHB can be implemented using Z-Card.  For Mixed Redundancy, connect one S-BOX to the Z-Card for Forward and the Z-Card for Backward. Control Room Control Pilar 1...
  • Page 26 3. S -BOX Installation and Connection  Note) DVI output function for service - The DVI - OUT on the front of the product is a port used for service purposes. - The resolution of the port is FHD (1920*1080 @ 60Hz) and screen blinking and breaking may occur when entering the source of U HD resolution into S-BOX, This is a phenomenon in which the port output is fixed down scaling without a specific scaling algorithm and has nothing to d o with the actual LED...
  • Page 27 Setting and guide Innovative Product R&D Lab.
  • Page 28 4. Setting and guide  Setting order - Set 1 S -BOX setting 2 Control PC setting (LSM) in order to use S -BOX. - Connect using Lan Cable (Shield) between S -BOX ↔ Control PCs. Control PC Setting (LSM) ①...
  • Page 29 4. Setting and guide  Precautions Before Setting • S-Box Default Quality Setting is optimized for XHB Cabinet and shipped to the factory. • The installed LED display model and optimized image quality setting are automatically set after installation. • For optimal image quality setting, please make sure to connect / register S - Box and LED display with LSM SW. •...
  • Page 30 4. Setting and guide  ① S -BOX Settings – Network Settings - Enter the Home key → Device ID using the remote controller. - Change the device ID to “1” and the PC Connection Cable to “RJ -45 (LAN) Cable”. For the SBB model, the device ID is always 1.
  • Page 31 4. Setting and guide  ① S -BOX Settings – Network Settings - Use Remote Controller to enter Home key → Network Status.You can set up automatic IP or manual IP through IP Setting. -Set the IP according to the control PC and network environment you use. ※...
  • Page 32 4. Setting and guide  ① S -BOX Settings – Picture Setting - You can set Menu → Picture specifications using Remote Controller. - You can set the screen size to display as Cabinet through “LED Picture Size Settings”. <LED Picture Size Settings> Output Resolution Select UHD/FHD to match the resolution of the source entered by the Control PC.
  • Page 33 4. Setting and guide  ① S -BOX Settings – Picture Setting(Exceptions) - Picture Size of S -BOX does not provide overscan/ crop function by default. - If the LED Picture Size is Original or Fit to Screen is Off, the original ratio is maintained. If it is Fit to Screen On, it is adjusted to the LED Picture Size.
  • Page 34 4. Setting and guide  ① S -BOX Settings – Grouping setting - You can configure a single screen using multiple S -BOXs using the grouping function of S -BOX. - To use the grouping function, change the image quality settings of multiple S -BOXs to OFF except for “Picture Mode” – “Calibration” as follows. ※...
  • Page 35 4. Setting and guide  ① S -BOX Settings – Grouping setting - Select Home → Video Wall mode using Remote Controller. - Select Video Wall Mode as “ON”. Innovative Product R&D Lab.
  • Page 36 4. Guide for settings  ① S -BOX – Device care - Check device condition of S -BOX and optimization can be performed with "Device Care“ - Menu  Support  Device Care ① ② ① Start Device Care : Check device condition of S -BOX automatically ②...
  • Page 37 4. Setting and guide  ② Video Source Settings – Change Output Frequency (PC ) - Change the output frequency of the PC as follows. • Right-click desktop mouse → Select screen resolution → Click advanced settings → Click display adapter attribute display •...
  • Page 38 4. Setting and guide  ② Video Source Settings – Change Output Frequency (1/3) - Support frequency of CX4B is as follows. Change the output frequency of the video source to match the corresponding support frequency. Horizontal Frequency S-BOX Grouping S Resolution Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V)
  • Page 39 4. Setting and guide  ② Video Source Settings – Change Output Frequency (2/3) - Support frequency of CX4B is as follows. Change the output frequency of the video source to match the corresponding support frequency. Horizontal Frequency S-BOX Grouping S Resolution Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V)
  • Page 40 4. Setting and guide  ② Video Source Settings – Change Output Frequency (3/3) - Support frequency of CX4B is as follows. Change the output frequency of the video source to match the corresponding support frequency. Horizontal Frequency S-BOX Grouping S Resolution Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (H/V)
  • Page 41  ② Control PC Settings – LSM • LSM: Windows Application Software for remotely adjusting the layout of LED cabinets • LSM download path: Samsung Display Solutions (https://displaysolutions.samsung.com/support/resources/product -support) Search support > Enter LED Signage Manager> Click DOWNLOAD • ※ Partner login is required to download the program.
  • Page 42 4. Setting and guide  ② Control PC Settings – LSM When LSM is executed for the first time, a page that sets the password appears. To set the password, the user must enter the same password twice and click the Start button. If you don't want to use password, check Don't use password option.
  • Page 43 4. Setting and guide  ② Control PC Settings – Connect LSM To add connection information, you can enter Search or IP address directly. When you click the Search button, the IP address of the connectable S-BOX on the same network appears. If you know the IP address of S -BOX, you can also enter it directly.
  • Page 44 Caution!] Fixed IP settings are recommended when setting up an LED cabinet network. 4. Setting and guide If IP is changed when using DHCP, LSM connection may be disconnected. 192.168.10. the x band is used for internal communication of LED cabinet. Please use IP except for the band.
  • Page 45 4. Setting and guide [★ Caution!]  ② Control PC Settings – LSM HOME Screen For internal communication between S -BOX and LED Cabinet, use ports 1515, 48484, 48485, and 58585. During firewall/security network use, the port must be enabled between S-BOX and LED.
  • Page 46 4. Setting and guide  ② Control PC Settings – Edit Connection Connection layout: Adjust the location and layout of each LED cabinet in the output source area of the S -BOX. Feature View: Provides an Edit button to modify connection information and automatic alignment of LED cabinets.
  • Page 47 4. Setting and guide  ② Control PC Settings – Diagnostic Status Change View Mode to “Diagnostic Status” to check the diagnostic function of LSM. Innovative Product R&D Lab.
  • Page 48 4. Setting and guide  ② Control PC Settings – Diagnostic Status (S - BOX) Signal In: Check if the input video signal is received normally. Temperature (°C): Shows the current temperature of S - BOX. FAN: Check if Fan is operating normally. Displays “Normal” when normal and “Error”...
  • Page 49 4. Setting and guide  ② Control PC Settings – Diagnostic Status (Cabinet) T-CON: Shows whether the T - CON of the cabinet works normally. SMPS: Shows whether the SMPS of cabinet is ON/OFF. Module: Shows whether the module works normally. Temperature: The current temperature of the cabinet is shown in a picture.
  • Page 50 4. Setting and guide  ② Control PC Settings – 1. Basic : . On / Off, change input source, Screen Mute / Freeze 2. Picture . Picture Mode change, Brightness / Contrast / Sharpness, Color, Tint(G/R), Color Temp(K), Gamma, White Balance adjustment, etc. 3.
  • Page 51 4. Setting and guide  ② Control PC Settings – 6. Cabinet Settings . Pixel RGB Data Reload / Request . OnScreenDisplay On / Off . Adjust LED Brightness . VP HDR Mode On / Off . Software Update function 7.
  • Page 52 4. Setting and guide  ② Control PC Settings – 8. Light Sensor Setting - On Brightness Optimization for Illuminance Sensor On or On Adaptive Picture * Both can't be turned on. Innovative Product R&D Lab.
  • Page 53 4. Setting and guide  ② Control PC Settings – Monitor Window: MDC communication log and connection device information can be checked Extractable as a file LED Signage Cabinet: IC information and power information of LED cabinet F/W information of IG LED Signage Box: IP address, MAC address, ID range of LED cabinet, Number of LED cabinets (full / connected /...
  • Page 54 4. Setting and guide  ② Control PC Settings – Options Command retry count Error status check interval Temperature warning notification S-Box Clock sync Support Program language Log data management Notification of device error through mail Password Configuration Options About Software Current version and update function of Innovative Product R&D Lab.
  • Page 55 5. SW Update Innovative Product R&D Lab.
  • Page 56 5. SW Update  Software Update - Check software update version ※ Contact Samsung Entry: MENU -> Support -> Contact Samsung Pontus-m (Main Micom) Version Pontus-m (Sub Micom) Version KU060 (FPGA) Version 7A200T (FPGA) Version Innovative Product R&D Lab.
  • Page 57 ① Pontus -M Main Micom Software Upgrade • USBDownload " https://displaysolutions.samsung .com/support/resources/product-support " Upgradefirmware downloaded from the website 1. Connectthe USBdrive where the file is stored to the set. (Pleasebe careful not to disconnect the power or USBdrive during the upgrade.) 2.
  • Page 58 5. SW Update  Software Update – Update using USB ① Main SWUpgrade Save the “SB -PTMWWC” folder to the USB root. Connect the USB. Click the “MENU” key on the remote control. Select the “Customer Support” menu. Select the “Update Software” menu. Select the “Update Now”...
  • Page 59 5. SW Update Software Update – Update Using LSM (S -BOX) 1. Prepare the update SW File. (Files selected when updating files marked in red) 2. After connecting LSM and CX4BPGS , click the Software update button under the S-Box Settings > System menu . 3.
  • Page 60 5. SW Update Software Update – Update Using LSM (S -BOX) 1. Prepare the update SW File. (Files selected when updating files marked in red) 2. After connecting LSM and CX4BPGS , click the Software update button under the S-Box Settings > System menu . 3.
  • Page 61 Thank you End of Document Innovative Product R&D Lab.
