Page 1
This guide explains how you can use Bluetooth MIDI over Low Energy to ® wirelessly pair (connect) the EV-1-WL to the WAZA Tube Amp Expander Core. “Pairing” means registering a MIDI device with the EV-1-WL (making the two devices recognize each other).
Page 2
Turn on the WAZA Tube Amp Expander Core to which the Bluetooth Audio MIDI Dual Adaptor ® (model: BT-DUAL) is connected and the EV-1-WL, and place them near each other. Long-press the pairing button on the BT-DUAL until the Bluetooth indicator blinks rapidly.
Page 3
Press the EV-1-WL’s [Bluetooth] button. The Bluetooth indicator on the EV-1-WL rapidly blinks white, and pairing begins. The Bluetooth indicator on the EV-1-WL stops blinking and remains lit white when pairing is finished. The WAZA Tube Amp Expander Core and EV-1-WL are now connected.
Page 4
WAZA Tube Amp Expander Core Editor (iOS/Android) Turn on the WAZA Tube Amp Expander Core (to which the BT-DUAL is attached) and the EV-1-WL, and place them near each other. Long-press the pairing button on the BT-DUAL until the Bluetooth indicator blinks rapidly.
Page 5
The Bluetooth indicator on the EV-1-WL stops blinking and remains lit white when pairing is finished, and the WAZA Tube Amp Expander Core and EV-1-WL are now connected. Rapidly press the [Bluetooth] button on the EV-1-WL twice to make the Bluetooth indicator blink blue.
Page 6
EV-1-WL rapidly blinks blue. Select “EV-1-WL+” from the WAZA Tube Amp Expander Core Editor app. The Bluetooth indicator on the EV-1-WL stops blinking and remains lit when pairing is finished. When the devices are correctly connected, their respective statuses are as follows.
Page 7
WAZA Tube Amp Expander Core, if you’ve turned off the unit with the Bluetooth indicator blinking white (disconnected), or if you performed a factory reset of the EV-1-WL, the device does not pair automatically. In this case, you must start from step 1 to configure the settings.
Page 8
In the WAZA Tube Amp Expander Core Editor’s MIDI SETTING, assign the CC number corresponding to the EV-1-WL setting value of the parameter you want to control. The default CC numbers set for the EV-1-WL are as shown below. Parameter MIDI CC#...
