Roland EV-1-WL Using Manual
Editor
Hide thumbs
Also See for EV-1-WL:
- Connection manual (81 pages) ,
- Connection manual (20 pages) ,
- Connection manual (5 pages)
Subscribe to Our Youtube Channel
Related Manuals for Roland EV-1-WL
Summary of Contents for Roland EV-1-WL
- Page 1 Using the EV-1-WL Editor © 2021 Roland Corporation This manual explains how to connect the EV-1-WL unit and EV-1-WL Editor app wirelessly via Bluetooth, and how to operate the EV-1-WL Editor.
- Page 2 Disconnect from the device that’s already Lit blue connected, or long-press the [Bluetooth] button on the EV-1-WL. In your mobile device’s settings, turn Bluetooth switch on. NOTE Even if the devices list on the mobile device shows “EV-1-WL” or “EV-1-WL+, ” don’t tap these.
- Page 3 * “EV-1-WL+” appears if the unit is already paired to another device. * If “EV-1-WL” is not shown, tap “SCAN” at the very bottom of the Bluetooth Devices screen to scan again. * If the Bluetooth indicator on the EV-1-WL is not rapidly blinking blue, press the [Bluetooth] button once more to make it do so.
- Page 4 Tap the back button on your mobile device to return to the previous screen. Verify that “EV-1-WL” is shown for “CONNECT” on the app. Tap [OK] to start communication.
- Page 5 [Bluetooth] button again to make it rapidly blink blue. The EV-1-WL is in the wrong Bluetooth mode. Is the Bluetooth indicator on the When blinking white, rapidly...
- Page 6 Follow the instructions in “Turn the Turn the power mobile device and the EV-1-WL off and off and on again then on again” (p. 8) to try pairing again. * If you’ve tried all of the above and still can’t connect, contact your dealer or a Roland customer service center.
- Page 7 Use the method that’s appropriate for your device to close the apps. Tap the gear icon for EV-1-WL in “Paired devices,” and tap “Unpair.” Turn the Bluetooth switch off. * The procedure for unpairing described in step 2–3 may differ depending on your mobile...
- Page 8 Turn the mobile device and the EV-1-WL off and then on again Turn off the mobile device and the EV-1-WL. Wait for about 10 seconds and turn the power on again. Start pairing again by following the steps in “Connecting the EV-1-WL to EV-1-WL Editor (Android)”...
- Page 9 Disconnect from the device that’s already Lit blue connected, or long-press the [Bluetooth] button on the EV-1-WL. In your mobile device’s settings, turn Bluetooth switch on. NOTE Even if the devices list on the mobile device shows “EV-1-WL” or “EV-1-WL+, ” don’t tap these.
- Page 10 EV-1-WL stops blinking and remains lit when pairing is finished. * “EV-1-WL+” appears if the unit is already paired to another device. * If the Bluetooth indicator on the EV-1-WL is not blinking blue, press the [Bluetooth] button once more to make it do so.
- Page 11 If “Bluetooth Pairing Request” appears, tap “Pair.” Tap [ÍBack] to return to the previous screen. Verify that “EV-1-WL” is shown for “CONNECT” on the app. Tap [OK] to start communication.
- Page 12 [Bluetooth] button again to make it rapidly blink blue. The EV-1-WL is in the wrong Bluetooth mode. Is the Bluetooth indicator on the When blinking white, rapidly...
- Page 13 Follow the instructions in “Turn the Turn the power mobile device and the EV-1-WL off and off and on again then on again” (p. 15) to try pairing again. * If you’ve tried all of the above and still can’t connect, contact your dealer or a Roland customer service center.
- Page 14 12, the procedure for closing an app is different. Use the method that’s appropriate for your device to close the apps. With the Bluetooth indicator on the EV-1-WL lit up blue, hold down the [Bluetooth] button to make the indicator blink blue. Turn the Bluetooth switch off.
- Page 15 Roland customer service center. Unpairing With the Bluetooth indicator on the EV-1-WL lit up blue, hold down the [Bluetooth] button to make the indicator blink blue. Turn the Bluetooth switch off.
- Page 16 Using EV-1-WL Editor Editor Top Screen Shows the MIDI settings screen for messages output to the device connected via Bluetooth. Shows the MIDI settings screen for messages output to USB. Shows the MIDI settings screen for messages output to MIDI OUT.
- Page 17 To edit values Slide up or down to edit a parameter. Long-press to enter a numeric value or choose from a list. Bluetooth / USB / MIDI OUT SETTING Parameter Value Explanation Sets the MIDI CC number OFF, CC#1– that is output when CC#31, EXP OFF CC# operating the pedal while...
- Page 18 Parameter Value Explanation Selects the maximum value EXP ON MAX 0–127 of the transmitted CC# message. OFF, CC#1– Sets the MIDI CC number CC#31, EXP SW CC# that is output when CC#64– operating the EXP switch. CC#95 Selects the minimum value EXP SW OFF 0–126 of the transmitted CC#...
- Page 19 Parameter Value Explanation Selects the maximum value CTL2 ON 1–127 of the transmitted CC# VALUE message. TOTAL SETTING Parameter Value Explanation Sets the MIDI channel MIDI CH 1–16 used for transmitting MIDI messages. RED, BLUE, LIGHT BLUE, Sets what LED color EXP SW LED GREEN, lights up when the EXP...
- Page 20 Parameter Value Explanation Adjusts how easily the EXP switch can be switched on. Smaller numbers make the switch turn on EXP SW SENS 1–16 when pressed only lightly. Larger numbers make the switch turn on when pressed harder. Selects the operating mode of the EXP switch.
- Page 21 Parameter Value Explanation Selects the operating mode for CTL1. LATCH: The setting is toggled off (minimum value) or on (maximum value) with each press of the LATCH, CTL1 MODE footswitch. MOMENTARY MOMENTARY: The normal state is off (minimum value), and the switch turns on (maximum value) only while the footswitch is...
-
Page 22: Bluetooth Setting
Here you can view the owner’s manual for the EV-1-WL unit or pages of this manual. * Your mobile device must be connected to the internet. VERSION Here you can view version information for the EV-1-WL, as well as software version and license information for EV-1-WL Editor.
