Users' Guide
SELECTION OF WASH PROCESS
Full-Automatic Program
Wash Wash Time Time of
Program (min.) Rinse
Cotton 15 2
Synthetics 15 2
Mixed 15 2
Wool 6 2
*
Quick 6 1
• Double Power Wash will be applied on Cotton or Mixed Program.
• The washing time and drain+spin time based on Mid water level in this table.
• Softener can be added to dispenser for programs with 2 rinse cycles.
The wool wash cycle of this machine has been tested and approved by The Woolmark Company for the washing of
*
Woolmark garments labelled as "machine wash" provided that the garments are washed according to the instructions
on the garment label and those issued by the manufacturer of this washing machine. M0605
Wash Process Selection and Display
Display
Soaking
Process
Wash Process
Full Program
Wash Only
Spin Only
Wash + Rinse
Rinse + Spin
• Mode indicated by display light:
( flashing ) , indicates the on-going process
( flashing ) + buzzer alarm, indicates failure of operation due to faults.
METHOD OF PROGRAM SELECTION
(1) Press the buttons on the left hand side of the control panel to set the wash program
" " " V "
other than pre-set wash program.
(2) Press the Process button to select your own combinations of wash process other than the
" "
full-automatic process.
Drain + Spin
Scope of Application
Time (min.)
Heavily soiled bed sheets, tablecloths,
5
towels, underwear, other cotton fabrics
Normally soiled blouses, shirts made of
5 polyester ( Diolen, Trevira ) , Polyamide
( Perlon, Nylan ) or blends with cotton.
Lightly or normally soiled cotton or mixed
5
fabrics
Machine washable wool with woolmark
4
label
Shortly worn outer clothing made of
5 cotton, Polyester, Polyamide and blends
with cotton.
(with six combinations of wash programs for selection)
Wash Rinse
WASH PROCEDURES AND PRODUCT
SPECIFICATIONS
Wash Procedures
1. Put drain hose in place.
2. Connect water inlet pipe properly and turn on water tap.
3. Connect to the Power source and press the
4. Press the
the wash program or use the preset wash program.
5. Press Process
"
processes other than the full automatic process.
6. Press Water Level
"
7. Press Function
"
8. Press Function
"
9. Press the
spin time and rinse cycle.
10. Choose "
11. Empty the laundry of all coins, banknotes and other foreign objects before
loading it evenly into the drum.
12. Place in detergent. Softener and bleach agent may also be added according
to needs.
13. Close the machine lid.
14. Press " Start/Pause
Spin
* The machine will be in delay time mode if the delay timer is selected.
* When washing is finished, the buzzer will be on. The machine will shut off
automatically in three minutes.
PRODUCT SPECIFICATIONS
Rated Voltage
Rated Frequency
Rated Input Power
Washing Capacity
Weight
Dimensions
Cabinet Size
Water Pressure
JS855FP
" ON/OFF
V buttons on the left hand side of the control panel to set
" " " "
button to select your own required combination of wash
"
button for desired water level.
"
button to select Mini Wash for small laundry load.
" " "
button to select Eco Wash for energy saving.
" " "
" + " " - " and " " " V " buttons to change the preset washing time,
Delay Timer " button to decide when to start washing.
" button and the machine will begin water intake.
220V~
50Hz
360W
5.0kg
38kg
504mm x 511mm x 913mm
500mm x 500mm
0.02-0.78MPa
" button.
