- Page 1 MFH-WS9 Workstand for MicroFine Handpieces User Guide MFH-WS9 Workstand for MicroFine Handpieces...
- Page 2 MFH-WS9 Workstand for MicroFine Handpieces User Guide Welcome! The MFH-WS9 Workstand is a soldering handpiece holder and multifunction tool, compatible with Metcal MX-H9-MFH and CV-H9-MFH MicroFine Handpieces and cartridges. Features Soldering Cartridge Storage Adjustable Cradle Hands-Free Soldering Cartridge Removal Easy-Empty...
- Page 3 MFH-WS9 Workstand for MicroFine Handpieces User Guide Assembly Upon unboxing, insert the brass brush and holder into the workstand base as shown. Adjustable-Angle Cradle The angle of the cradle for the tweezer handpiece can easily be adjusted. Loosen the cradle adjustment knobs on both sides of the workstand until you are able to move the cradle.
- Page 4 MFH-WS9 Workstand for MicroFine Handpieces User Guide Hands-Free Tip Removal Tool Line up the cartridge rings with the notches in the tip removal tool. Gently press downward to insert the cartridge into the tool. Carefully pull the handpiece backward, leaving the cartridge safely in the removal tool. You may...
-
Page 5: Brush Replacement
MFH-WS9 Workstand for MicroFine Handpieces User Guide Brush Replacement To replace the brass tip-cleaning brush, remove the brush and holder from the workstand base. Pull up on the peg in the back of the holder and slide out the brush tray. - Page 6 As you use the brass solder tip cleaning brush, solder debris will be cast off your tip and collect around the base of the brush. Metcal has designed the MFH-WS9 to make it easy to contain, collect, and dispose of this potential mess.
