- Page 1 MFT-WS10 Workstand for MicroFine Tweezers User Guide MFT-WS10 Workstand for MicroFine Tweezers...
- Page 2 MFT-WS10 Workstand for MicroFine Tweezers User Guide Welcome! The MFT-WS10 Workstand is a soldering tweezer holder and multifunction tool, compatible with Metcal MX-H10-MFT and CV-H10-MFT MicroFine Tweezers and cartridges. Features Soldering Cartridge Storage Adjustable Cradle Hands-Free Soldering Cartridge Removal Easy-Empty Debris...
- Page 3 MFT-WS10 Workstand for MicroFine Tweezers User Guide Assembly Upon unboxing, insert the brass brush and holder into the workstand base as shown. Adjustable-Angle Cradle The angle of the cradle for the tweezer can easily be adjusted. Loosen the cradle adjustment knobs on both sides of the workstand until you are able to move the cradle.
- Page 4 MFT-WS10 Workstand for MicroFine Tweezers User Guide Hands-Free Tip Removal Tool Line up the cartridge rings with the notches in the tip removal tool. Gently press downward to insert the cartridges into the tool. Carefully pull the tweezer backward, leaving cartridges safely in the removal tool. You may need to...
- Page 5 MFT-WS10 Workstand for MicroFine Tweezers User Guide Hands-Free Tip Alignment Approach the workstand with the tweezer level and at the same height as the opening in the tip alignment tool. Rotate the tweezer until the alignment ring on the tip you would like to adjust is in the horizontal position.
- Page 6 MFT-WS10 Workstand for MicroFine Tweezers User Guide Insert the cartridge into the alignment tool until the ring is fully inserted. With the tip securely in the alignment tool, rotate the tweezer slowly in the required direction until the tip is in the desired position.
-
Page 7: Brush Replacement
MFT-WS10 Workstand for MicroFine Tweezers User Guide Brush Replacement To replace the brass tip cleaning brush, remove the brush and holder from the workstand base. Pull up on the peg in the back of the holder and slide out the brush tray. - Page 8 As you use the brass solder tip cleaning brush, solder debris will be cast off your tip and collect around the base of the brush. Metcal has designed the MFT-WS10 to make it easy to contain, collect, and dispose of this potential mess.
