General Filter Cleaning Tips
1. ALWAYS Wear a Mask and Use Rubber gloves.
Prevents accidental inhalation of any contaminants when cleaning your
filters.
2. Move the unit, Not the Filters
Minimizes filter shaking.
3. Handle the Filters Carefully
Be careful not to agitate the filters to avoid releasing trapped
contaminants.
4. Dry the Filters Completely
Never install a wet or damp filter into your unit. Allow 12-24 hrs for the
filter to completely dry.
To Clean the Ozone Emission Removal Filters
1. Remove the filters. take them outside or a well-ventilated area to clean.
2. Gently, but thoroughly, clean the filters using a brush-tipped vacuum.
3. Repeat the process on the other side. DO NOT GET WET.
To Clean the Stainless-Steel Prefilters
The Prefilters need to be cleaned at least once every two months, depending
on use. Use a brush-tipped vacuum to remove any dust or lint.
Cleaning the Odor Sensor
The Odor Sensor is behind the three slots above the Dust Sensor
may ONLY be cleaned using a brush-tipped vacuum.
Note: If you are unable to close the Filter Access Panel for any
reason, the unit will not operate. Contact Nuwave Customer
Service.
©2024 Nuwave
LLC • All Rights Reserved.
®
Item: BQ47265-V1-11-08-24-YK
Customer Service: For Amazon Purchases: support@nuwavenow.com ● For All Other Purchases: help@nuwavenow.com
Cover and
E1000
Master Your Forever
Smart Air Purifier
Scan the code to watch
how-to videos and more!
Cleaning the Dust Sensor
The Dust Sensor, located on the side of the
unit, requires regular cleaning
(approximately every 3 months) for the unit
to operate efficiently.
1. Open the Dust Sensor Cover.
2. Using a dry cotton swab, gently remove
any dirt or dust from the Dust Sensor.
3. For more buildup on the Dust Sensor,
wipe it with a slightly wet cotton swab.
4. Remove any moisture with a dry cotton
swab.
If your unit is set up in an area with high dust accumulation, more frequent
cleaning of the Dust Sensor is needed.
DO NOT use the cotton swab on any part or area other than the Dust
Sensor.
DO NOT immerse the unit in water. Clean the outside of the unit with a
damp sponge or cloth and wipe it dry. Make sure all parts and covers
are securely attached.
DO NOT dry the filters in direct sunlight or with a hot blow dryer.
Retrieve a Foreign Object in the Fan
1. Unplug the unit and carefully turn the unit upside down.
2. Gently rock back and forth, then side to side until the object falls out.
3. Contact Customer Service if unable to dislodge.
Open
Dust Sensor Cover
Close
EPA Establishment Number: 101594-CHN-1
Odor Sensor
