NuWave OxyPure Zero E500 Quick Start Manual

E500
Getting Started
ICON NAME
When the OxyPure is plugged in, the Power button will be red, indicating that the unit is in Standby Mode. Press it once, the LED turns
green and the unit activates, either with the last settings used, or in Manual Fan Speed Mode at Fan Speed 1 if the unit is being
POWER
activated for the first time.
AUTO will put the unit into either Auto Mode or ECO Mode. Press it once for Auto Mode, running the unit based on air
AUTO
quality. Press and hold it for 1 second for ECO Mode, where the unit stays off until air quality issues are detected.
ECO
To quit ECO Mode, press and hold the AUTO for 1 second.
The OxyPure, while in Ultimate Clean Mode, automatically adjusts to the highest or lowest fan speed based on the air quality at its
ULTIMATE
location, running as long as is necessary to clean the air. To turn it on or off, simply press ULTIMATE CLEAN.
CLEAN
To activate Wi-Fi, press and hold ULTIMATE CLEAN. Once the Wi-Fi light is rapidly blinking you can release the button and begin
WIFI
pairing.
FAN SPEED controls the fan speed level, from 1 to 6, and also activates Sleep Mode. Simply press it until you reach the fan speed you
FAN
want. Pressing it a 7th time returns you to Fan Speed 1. Regardless of what mode the unit is in, the OxyPure will always display the
SPEED
current fan speed. To activate Sleep Mode, press and hold FAN SPEED for 1 second.
Pressing TIMER lets you decide how long the OxyPure remains on, pressing the button once for each of the following: 1hr, 2hrs, 4hrs,
6hrs, 8hrs, and 12hrs. Pushing it a seventh time will turn off the Timer but not the unit. TIMER can be used with AUTO, FAN SPEED,
TIMER
and TURBO.
Press TURBO to run the OxyPure at the highest fan speed for up to 2 hours. Press it once for 30 minutes, twice for 1 hour, and 3 times
TURBO
for 2 hours. Pressing TURBO four times turns it off. Once the time is up, the unit will run at Fan Speed 1.
For Amazon Purchases: support@nuwavenow.com ● For All Other Purchases: help@nuwavenow.com
Air/Odor Quality – Detects particles as small as 2.5µ
Clean
Customer Service:
Quick Start Guide
Refer to the Owner's Manual for more details
FUNCTION
Model No:
47351 / 47361
Dirty
