Page 1
Operations & Parts Manual www.cantekamerica.com P305 Sliding Table Saw Please ensure you have your serial number available when contacting us for parts or service. Cantek America Inc. | 1.888.982.2683 | Parts: sales@cantekamerica.com | Service: service@cantekamerica.com...
Page 2
PANEL SAW P305 Table of Contents General Information ........................2 Safety Precautions ........................3 Machine Information ......................... 6 Components ..........................6 Specification..........................7 Setup ............................8 Unpacking ..........................8 Check machine accessories ....................9 Sliding table assembly ......................10 Crosscut frame assembly ...................... 11 Support frame assembly ......................
Page 3
Effect only adjustments and maintenance operations on machine as indicated in this manual. Machine Performances The P305 panel saw is with 2600mm and 3200mm sliding table. The outlook design of this machine is unique and with complete cast iron bracket, enlarged outrigger, carriage, and direct dust collection outlet.
Page 4
PANEL SAW P305 2. Safety Precautions Read instruction manual before operating the machine for your safety. People who operate the machine must read and understand how to use the safety measures, and execute the regulation stated in this manual. Learn the application and limitations of the machine Ground all machines.
Page 5
PANEL SAW P305 Disposing of wasted material. Disposing waste material and waste lubricating oil shall obey the local regulation and be careful. Fire extinguisher Workshop of user shall be with the fire extinguisher or other devices according to the local safety regulations and be careful.
Page 6
PANEL SAW P305 During making wooden cases, it will emit harmful dust. User must install exhaust system for the extraction of harmful dust. Use correctly sharpened saw blades. Observe the maximum speed marked on the saw blade. User shall be to select the optimum speed for saw blade.
Page 7
PANEL SAW P305 3. Machine Information Components 1. Swing Arm 11. Left Extension Table (Optional) 2. Blade Tilt Control Handle 12. Hold Down 3. Control Panel 13. Flip Stop 4. Emergency Button 14. Crosscut Fence 5. Sliding Table 15. Crosscut Frame 6.
Page 8
PANEL SAW P305 Specification Model 2600mm 3200mm Sliding table dimension 2600x360mm 3200x360mm Cast Iron table 896 x 548mm Extension table (rear) 952 x 896mm Extension table (front) 830 x 320mm Table size 1,500 x 1,726mm Round rail φ40mm Main saw blade (Max.)
Page 9
PANEL SAW P305 4. Setup Unpacking By offering the comprehensive information regarding to the operation and maintenance of the machine, it will be ensured that operators will use the machine properly. Our sales organization is always willing to provide solutions for every technical problem (reparation, spare part delivery), and to help your business with our professional knowledge.
Page 10
PANEL SAW P305 Check machine accessories Packing List: Main machine Assembly parts for sliding table Assembly parts for crosscut fence Assembly parts for rip fence Assembly parts for dust collection Assembly parts for flip stop Assembly parts for rear extension table Assembly parts for left extension table (optional) Assembly parts for edge shoe &...
Page 11
PANEL SAW P305 Sliding table assembly Fig. 1: Slide three T slot bolts into the groove and locate in right positions. Fig. 2: Flip sliding table and through holes by T slot bolts. Fasten all bolts by nuts.
Page 12
PANEL SAW P305 Crosscut frame assembly Fig. 1 & 2: Slide T slot bolt into the groove and lock crosscut frame by lever. Fig. 3: Lock swing arm by hex nut.
Page 13
PANEL SAW P305 Support frame assembly Fig. 1 & 2: Fasten square nuts by lever on both ends. Fig. 3: Slide support frame through nuts and lock by lever.
Page 14
PANEL SAW P305 Crosscut fence assembly Fig. 1: Pull crosscut fence closed to sliding table. Fig. 2: Slide T slot bolts into the groove and locate them in right positions. Fig. 3 & 4: Lock rotate shaft by wrench, then connect with knob.
Page 15
PANEL SAW P305 Crosscut fence assembly#2 Fig. 5 & 6: Use T slot bolt through the square nut. Fig. 7 & 8: Locate black block on lever and use wrenches to lock nuts...
Page 16
PANEL SAW P305 Crosscut fence assembly#3 Fig.9: Put square nut inside the groove and locate on hole inside the channel. Flip stop assembly Fig. 1 & 2: Slide flip stop into channel groove. One on main fence, another on extension fence.
Page 17
PANEL SAW P305 Rare table assembly Fig. 1 & 2: Use three screws, lock washers and flat washers to put rear table on the main body of machine. Place table on the correct position. Fig. 3 & 4: Use three set screws to align the level with main body.
Page 18
PANEL SAW P305 Left table assembly (optional) Fig. 1 & 2: Use two screws, lock washers and flat washers to put left table on the main body of machine. Place the table on the correct position. Fig. 3 & 4: Use two set screws to align the level with main body.
Page 19
PANEL SAW P305 4.10 Rip fence scale assembly Fig. 1: Use three screws, lock washers, flat washers and one nut to put ruler on the main body of machine.
Page 20
PANEL SAW P305 4.11 Rip fence assembly Fig. 1 & 2: Use four sets of screws, lock washers and flat washers to put shaft on the main body of machine. Fig. 3: Install stop ring on the left end of the shaft and use set screw to lock-in.
Page 21
PANEL SAW P305 Rip fence assembly#2 Fig. 5: Make sure rip fence housing doesn’t hit rare table, but against knob when you rotate it. Fig. 6 & 7: Slide fence plate through bolts and use lever to lock-in. Fig. 8: Fasten end washer on the right end of round rail.
Page 22
PANEL SAW P305 4.12 Saw blade assembly Fig. 1: Hold T wrench through the hole and lock the main pulley. Fig. 2 & 3: Put on the main saw blade and loosen it by nut and flange.
Page 23
PANEL SAW P305 4.13 Riving knife assembly Fig. 1: Install the riving knife. Fig. 2: Make sure the gap between riving knife and main saw blade is 3mm at least. 4.14 Edge shoe assembly Fig. 1 & 2: Slide the edge shoe into the sliding table groove.
Page 24
PANEL SAW P305 4.15 Hold down assembly Fig. 1 & 2 & 3: Slide the hold down into the sliding table groove.
Page 25
PANEL SAW P305 4.16 Side handle assembly Fig. 1: Slide the handle into the groove on the side of sliding table groove. 4.17 Electrical installation Warning: The electrical installation should be carried out by qualified and trained person Fig. 1 & 2: The configuration should be from left to right. R, S, T and ground. Connect wires...
Page 26
PANEL SAW P305 4.18 Test run Once complete machine assembly, test run the machine to ensure wirings are properly connected to power and safety components are functioning correctly. If you find an unusual problem during the test run, STOP the machine immediately, disconnect it from power, and fix the problem BEFORE operating machine again.
Page 27
PANEL SAW P305 If main blade turns clockwise (when you stand in front of the machine), it’s in the correct direction (see below picture). If not, stop machine and disconnect it from the power source, then correcting phase polarity to change phrase.
Page 28
PANEL SAW P305 5. Operation 5.1. Overview The purpose of this overview is to provide the novice machine operator with a basic understanding of how the machine is used during operation, so the machine controls/components discussed later in this manual area easier to understand.
Page 29
PANEL SAW P305 5.2. Control Panel Main blade ON button Main blade OFF button Saw blade ON button Saw blade OFF button Status Indicator Emergency Stop...
Page 30
PANEL SAW P305 5.3. Main blade adjustment Blade tile handwheel & lock knob: Handwheel tilts main blade from 0˚ to 45˚ (turn clockwise to increase tile angle). The lock knob secures the handwheel to prevent it from moving during operation.
Page 31
PANEL SAW P305 Adjust forward and backward position Use a T-handle wrench to adjust the scoring blade front-back position. Turning the wrench to the right will move the blade forward, while turning it to the left will move the blade backward.
Page 32
PANEL SAW P305 5.5. Crosscut fence adjustment Setup reference It is necessary to setup a reference before cutting panels. Make sure 90˚ stop bolt is properly adjusted and lock by knob. Stop bolt Knob Setup a panel to cut off and measure W1 an W2 dimension.
Page 33
PANEL SAW P305 Make sure crosscut fence stay at zero for reference. If not, loose set screw on the back side and move the ruler back to zero point. Angle cutting Besides cutting straight, crosscut fence can rotate any angle from 0 to 60 degree.
Page 34
PANEL SAW P305 5.6. Long / short fence plate replacement The rip fence can be installed in the vertical position for thicker workpieces, or in the horizontal position for smaller workpieces. Horizontal Vertical...
Page 35
PANEL SAW P305 6. Maintenance 6.1. Overview Warning: Please disconnect power and air input before you do any action. General cleaning Please DO NOT attempt to remove wood chips while saw is turned on. Clean all saw dust and remove lumps of wood periodically, even if you use a dust collector, there may be parts that remain in the machine.
Page 36
PANEL SAW P305 6.2. Maintenance schedule Weekly Monthly Annual ● Clean off sawdust on machine ● Visual check on screws and nuts ● Visual check on damaged wires ● Visual check on damaged blades & riving knife ● Check electromagnetic brake ●...
Page 37
PANEL SAW P305 6.3. Lubrication Note: DO NOT get any lubrication on the dive V-belts to prevent slippage and damage. All the bearings are internally lubricated and sealed at the factory. Simply leave them alone unless they need to be replaced.
Page 38
PANEL SAW P305 Sliding table There are steel ways on the sides of the sliding table that fit between the top and the base and allow these parts to slide past each other. Clean the ways with mineral spirits and shop rags, then apply a thin coat of light machine oil with a shop rag.
Page 39
PANEL SAW P305 Troubleshooting Warning: Please disconnect power and air input before you do any action Review the troubleshooting procedures in this section if problem occurred on your machine. If you need spare parts or additional help with procedures, please gather serial number and manufacture date of your machine before sending requests.
Page 41
D305P_1.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 150527 2x300x7.5(M/M) SH100800 Hex Head Bolt M10*40 NH101700 Hex Nut 206413 Machine frame WF061310 Washer M6x13 NF061000 Hex Flange Nut 207128 Plate SP060200 Pan Head Screw(+)/W M6x10 SG050200 Hex Flange Screw M5*10 203412 Block...
Page 42
D305P_1.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 205655 Screw M12*185 205657 Concrete Block 709412 Strain Relief PG11 709421 Strain Relief PG20 206361 Plate WS060000 Lock Washer SR069300 Cap Screw M6*12 201458 Hole Plugs HP-22 SP060200 Pan Head Screw(+)/W M6*10 WS060000 Lock Washer...
Page 43
D305P_1.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 207299-32 Plate ST049300 Tap Screw 170736 Hanger SP059400 Pan Head Screw M5×16 SH161000 Hex Head Bolt M16*50 NH162400 Hex Nut 994809 Power Switch ZH-HD-2 136019 Cord Connetor 224-201 207568 Plate...
Page 45
ASSEM 1.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 150527 2x300x7.5(M/M) SH100800 Hex Head Bolt M10*40 NH101700 Hex Nut 206413 Machine frame 206367-37 Plate SR069300 Cap Screw M6*12 WS060000 Lock Washer WF061310 Washer M6x13 NF061000 Hex Flange Nut SS060400 Set Screw M6*20 NH061000...
Page 46
ASSEM 1.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SJ060400 Button Head Screw M6*20 201105 Power Box 201105A Power Box 994805 Terminal PB2504 4P 994805 Terminal PB2504 4P SP059200 Pan Head Screw M5*8 SJ059300 Button Head Screw M5*12 709421 Strain Relief PG20 NH121900...
Page 47
ASSEM 1.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 200841 Fix Plate WF061310 Washer M6x13 207399 Steel Wire SR050200 Cap Screw M5x10 SS050200 Setscrew M5x10 200843 Indicator Block SR069300 Cap Screw M6x12 WS060000 Lock Washer 200842 Shaft WF061310 Washer M6x13 200993 Spring...
Page 48
D305P_1.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SS100400 Set Screw M10*20 NH101700 Hex Nut 207077 Left Ext. Plate 207151 Left Ext. Plate R / S SR100500 Cap Screw M10*25 206362 Table 207078 Ext. Plate 207079 Ext. Plate R / S M10*ψ20 WF102030 Washer...
Page 49
P305 ASSEM02-1 (TWO MOTOR-optional) ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB200888A-A Control Panel Face Assembly A, OPT. 200888A Control Panel Face ST049200 Phillips Head Sheet Metal Screw M4X8 994810 Button Switch HY57(1A1B) 994808 Emergency Stop Button E2R1R(1B) 996002 Power Lamp YK.24V...
Page 50
P305 (ONE MOTOR) ASSEM02-2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB200888A-B Control Panel Face Assembly 200888A Control Panel Face ST049200 Phillips Head Sheet Metal Screw M4X8 994808 Emergency Stop Button E2R1R(1B) 205504 Power indicator Button 994810 Button Switch...
Page 51
P305 ASSEM02-3 (optional) ITEM PART NO PARTS NAME SIZE Q`TY NOTE 994855A Dust Cove R2 PRCF 994855 Switch Button-ON R2 PNF-1A-G 994856 Switch Button-OFF R2 PNF-1B-R YK.24V φ22 (W) 996002 Pilot Lamp 207248 Label 206403 Plate WS060000 Lock Washer SR069400...
Page 52
P305 (optional) ASSEM02-4 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 206407 Panel SJ050200 Button Head Screw M5*10 994808 Emergency Stop Button YK.24V φ22 (W) 996002 Pilot Lamp 996005 Pilot Lamp KE-22DS 205504 Pilot Lamp 994855 Switch Button-ON R2 PNF-1A-G...
Page 56
QCD305P2G0301 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 SR059200 Hex. Socket Screw M5*0.8*8 0020 WS050000 Spring Washer M5*φ10 0030 WF051010 Flat Washer 0040 SR069300 Hex. Socket Screw M6*1*12 0050 WS060000 Spring Washer 0060 SR059400 Hex. Socket Screw M5*0.8*16 染黑...
Page 57
P305 ASSEM03-2.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE LJ019130 Belt PJ190 x 13 OPT , 50Hz LJ018130 Belt PJ180 x 13 OPT , 60Hz SS069200 Set screw M6×8 206168 Pulley PJ x 13 OPT , 50Hz 206169 Pulley...
Page 58
P305 ASSEM03-2.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE M13×ψ22 WF132225 Washer WS120000 Lock Washer SH120600 Hex Head Bolt M12×30 KD080740 8x7x40 MA206302 Main Motor MH204006 Main Motor 5HP(220V/440V) M20H OPT. M8×ψ18 WF081818 Washer WS080000 Lock Washer SJ080400 Hex Head Bolt M8×20...
Page 59
ASSEM 3.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 206399 Belt 3VX-250 60Hz M10*ψ40*3t WF104030 Washer 208042 Belt Pulley 60Hz 201333 Shaft 206396D Main Motor Plate M13×ψ22 WF132225 Washer WS120000 Lock Washer SH120700 Hex Head Bolt M12×35 KD080740 8x7x40 MA208002 Main Motor 7.5HP...
Page 61
D305P_3.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 208044 Belt 3VX-265 50Hz/S 206399 Belt 3VX-250 60Hz/S SS080200 Setscrew M8×10 208043 Belt Pulley 50Hz CE/S 208042 Belt Pulley 60Hz CSA/S 201333 Shaft 206396 Main Motor Plate 206396D Main Motor Plate M13×ψ22 WF132225 Washer...
Page 63
ASSEM 3.3.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 208043 Belt Pulley 50Hz CE/S 208042 Belt Pulley 60Hz CSA/S SS080200 Setscrew M8×10 206600 Shaft NH101700 Hex Nut 201333 Shaft SJ080400 Hex Head Bolt M8×20 WS080000 Lock Washer M8×ψ18 WF081818 Washer 206396A Main Motor Plate...
Page 64
P305 ASSEM03-4 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 206304 Gip Plate SJ100500 Button Head Screw M10×25 WS100000 Spring Washer KD050520 5x5x20 201822 M16x2.0...
Page 65
P305 ASSEM03-4 ITEM PART NO PARTS NAME SIZE Q`TY NOTE ψ25.4 206350 Arbor Flange OPT. ψ30 206380 Arbor Flange WS080000 Lock Washer M8×ψ30 WF083030 Washer 200964 Bushing 201205 Shaft SJ080400 Button Head Screw M8×20 201346 Bushing M8×ψ30 WF083030 Washer WS080000...
Page 101
P305 (optional) ASSEM12-9 ITEM PART NO PARTS NAME SIZE Q`TY NOTE NL101700 Lock Nut 205004 Gas Expansion Cylinder M10*ψ20 WF102020 Washer SR060400 Cap Screw M6*20 WS060000 Lock Washer 207987 Fixed Plate 207970 204158 Hose Clamp 3-1/4" ψ3"x42cm HS330004 Hose ψ10×ψ20...
Page 102
P305 (optional) ASSEM12-9 ITEM PART NO PARTS NAME SIZE Q`TY NOTE NH121900 Hex Nut SH121400 Hex Head Bolt M12X70 201039 205358 Elbow Type Clamp WF081818 Washer M8x18 WS080000 Lock Washer NH081300 Hex Nut SR080600 Cap Screw M8x30 WF081818 Washer M8x18...
Page 103
P305 (optional) ASSEM12-9 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 207883 Shaft AB205356 Protection Hood ASM OPT. 207867 Guard SP040200 Pan Head Screw M4*10 205356 Protection Hood AB207868 Roller ASM SP040200 Pan Head Screw M4*10 SI060200 Counter Sunk Screw...
Page 104
P305 ASSEM14-2+14-3 ASM14-2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE Handle 200939 Washer M12x30 WF123030 φ13xφ25 Plastic Washer 992496 T-Nut M12x1.75p 201849 ASM14-3 (AB201830) PARTS NAME SIZE Q`TY ITEM PART NO NOTE AB201830 Edge Shoe Plate Assembly Edge Shoe Plate 101 201830 φ5xφ18...
Page 105
D401_14.4.5 PARTS NAME SIZE Q`TY ITEM PART NO NOTE 200526 Fence Plate M4×9 201632 Spring plungers with ball Miter Gauge Assembly AC198170AB1 S, A Miter Gauge Assembly AC204295A S, A Miter Gauge Body 198170A Hex Nut NH050800 Cap Screw M5×25 SR050500 SP049300 Pan Head Bolt...
Page 107
P305 PARTS NAME SIZE Q`TY ITEM PART NO NOTE Hex Nut M12x1.75p NH121900 WS120000 Lock Washer Washer M12x30 WF123030 Cap Screw 201665 Bottom Base 3200mm 2360320E-2 Cover 2360320E-7 Sunk Head Screw M6x30 SI060600 Rubber Block 2360320E-14 Locate Block 2360320E-12 Cover...
Page 108
AB136012-3+AB136012A AB136012-3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 AB136012A 0050 IC200807 Stop Control Cord AB136012A ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 136012A Door Safety Switch AZD-1112(UL) 45P~63P 0020 709411 Strain Relief PG11 0030 SP040500 Pan Head Screw (+) M4*0.7*25 0040...
Page 112
AB206423A ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 201103 Fixed Block 0020 206426 Extend Fence 0030 206427 Cover 0040 ST040200 Tapping Screw M4*0.7*10 0050 SJ089400 Pan Head Socket Screw M8*1.25*16 0060 WS080000 Spring Washer 0070 204264 Fixed Plate 0080 206424 Rotate Block...
Page 113
AB206407+AB206407-2 AB206407 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 AB206407A Operation Panel Asm. 0090 IC207028 Panel Control Cord 0.75x7Cx0.4Mx12Y2R 0100 IC207013 Stop Control Cord 2.5M 0110 IC200804 Switch Control Wire 0120 IC200805 Switch Control Wire AB206407-2 ITEM PART NO PARTS NAME SIZE Q`TY...
Page 114
AB206407A ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0020 206407 Operation Panel 0030 SJ050200 Pan Head Socket Screw M5*0.8*10 0040 994808 Emergency Button Switch R2PNR4-1B-R YK.24V φ22 (W) 0050 996002 Power Pilot Lamp 0060 994855 Flat Head Push Button Switch R2 PNF-1A-G 0070 994855A...
Page 115
AB207065-2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 207143 Quick Release Handle 0020 100271 Ball Knob 0030 207070 Handle 0040 207067 0050 RS140000 Retaining Ring (S-type) 0060 207069 Spring 0070 207145 Lock Pin 0080 207065 Down Press Base 0090 207068 Down Press Shaft...
