Cantek D405A Operations & Parts Manual

Sliding table saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operations & Parts
Manual
www.cantekamerica.com
D405A
Sliding Table Saw
Please ensure you have your serial number available when contacting us for parts or service.
Cantek America Inc. | 1.888.982.2683 | Parts: sales@cantekamerica.com | Service: service@cantekamerica.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D405A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cantek D405A

Summary of Contents for Cantek D405A

  • Page 1 Operations & Parts Manual www.cantekamerica.com D405A Sliding Table Saw Please ensure you have your serial number available when contacting us for parts or service. Cantek America Inc. | 1.888.982.2683 | Parts: sales@cantekamerica.com | Service: service@cantekamerica.com...
  • Page 2 PANEL SAW INSTRUCTION MANUAL 1-1 General Information We are specialized to supply full range of panel saw from 1600, 2200, 2600, 3200 to 3800mm. The outlook design of this machine is so unique with complete cast iron bracket instead of sheet metal, enlarged outrigger and carriage, direct dust collection outlet.
  • Page 3 PANEL SAW INSTRUCTION MANUAL 1-2. Safety Rules 1) Read instruction manual before operating the machine for your safety. People who operate the machine must be trained, read and understood to use the safety measures, possess the ability to obey, and execute the regulation stated in this manual.
  • Page 4 PANEL SAW INSTRUCTION MANUAL parts; otherwise this may result in considerable danger to the user. 13) Check any damaged parts. Before using the machine further, the guard or other damaged part should first be carefully checked to determine if it will operate properly and perform its intended function.
  • Page 5 PANEL SAW INSTRUCTION MANUAL emergency stop, follow the normal start up procedure and suitable operation to obviate the hazard. Please see the afterward pages of emergency stop position diagram. 22) Never open the protective cover or the machine door while the machine is running.
  • Page 6 PANEL SAW INSTRUCTION MANUAL piece against the fence. b) Selection of saw blade and riving knife- the operator should only select saw blade with suitable diameter and thickness for the machine. c) Selection of riving knife slot- The riving knife guiding slot should be no more than 0.5mm wider than the riving knife guiding elements.

  • Page 7: Main Feature

    PANEL SAW INSTRUCTION MANUAL 2-1. MAIN FEATURE Optional Optional Machine Body Sliding Table C. Edge Shoe D. Control Panel Overhead Guard Crosscut Fence G. Flip Stops H. Extension fence Hold Down Miter Fence Rip fence...

  • Page 8: Specifications

    PANEL SAW INSTRUCTION MANUAL 2-2. SPECIFICATIONS ITEM A405A-3200mm A405A-3800mm 3800x395mm Sliding table dimension 3200x395mm Cast Iron table 548x896mm Extension table (rear) 952x896mm Extension table (front) 830X320mm Table size 1500x1726mm Round rail Φ40mm Main saw blade (Max.) 400mm Main saw bore φ30mm Max.
  • Page 9 PANEL SAW INSTRUCTION MANUAL 3-1. UNPACKING SETUP SAFETY – By offering the comprehensive information regarding to the operation and maintenance of the machine, it will be ensured that operators will use the machine properly. – Our sales organization is always willing to provide solutions for every technical problem (reparation, spare part delivery), and to help your business with our professional knowledge.
  • Page 10 PANEL SAW INSTRUCTION MANUAL 3-2. CHECKS THE MACHINE ACCESSORIES Packing List Saw base Unit x 1 wooden Sliding Table Unit x 1 Assembly parts for crosscut fence x1 Assembly parts for crosscut frame. x1 Assembly parts for rip fence. x3 Assembly parts for dust collection.
  • Page 11 PANEL SAW INSTRUCTION MANUAL 3-3.FITTING THE SLIDING TABLE The accessories bag contains hex head bolts for fixing the sliding table For packing and transport reasons, some machine members are removed. All fitting operations in this section require approx. 4 people Note: The parallelism has been adjusted before shipping, users only need to assemble by following the steps below.
  • Page 12 PANEL SAW INSTRUCTION MANUAL 3-4. FITTING THE CROSSCUT FRAME & EXTENSION FENCE ASSEMBLY All fitting operations in this section require approx. 2 people I. Fitting the crosscut frame 1. Fit the crosscut frame by putting A (Fig. 3-4.1) into the end of swing arm B(Fig. 3-4.1).
  • Page 13 PANEL SAW INSTRUCTION MANUAL 3. Slide the 4 sets of square pads by follow the arrow direction into the groove at the bottom and lock 1 pad at the end (Fig. 3-4.2a) 4. Fit crosscut fence in the groove H (Fig. 3-4.2) and holes on crosscut frame (as Fig 3-4.2b) 5.
  • Page 14 PANEL SAW INSTRUCTION MANUAL 3-5. FITTING THE EXTENSION TABLE All fitting operations in this section require approx. 2 people 1. Fasten the extension table and keep it aligned with cast iron table. Check the flatness by placing fence plate (F, Figure 3-7.1) on the tables as Fig 3-5.1. The extension table must be even height to cast iron table.
  • Page 15 PANEL SAW INSTRUCTION MANUAL 3-6. FITTING THE SAW BLADE GUARD Stand saw blade guard A (fig. 3-6.1) Insert the riving knife to the fixed plate which next to the main saw blade Mount the simple saw blade guard to the riving knife fig.
  • Page 16 PANEL SAW INSTRUCTION MANUAL 5. Put the fixed bracket on the support frame and aim at those four holes, then tighten the screws, lock spring washers and washers. 6. Insert the dust bracket into the fixed bracket then push it inside the fixed bracket 7.
  • Page 17 PANEL SAW INSTRUCTION MANUAL 8. mount the saw blade guard to the support bracket , tighten Mounted the connect plate direct to the the screws, lock washers and washers to steady it. (before overhead guard, fasten with the nut. fasten all the screws check the following step first) 9.
  • Page 18 PANEL SAW INSTRUCTION MANUAL 13. Install hose to the dust hood. 14. Release the red screw can change the guard.
  • Page 19 PANEL SAW INSTRUCTION MANUAL 3-7. FITTING RIP FENCE All fitting operations in this section require approx. 2 people Remove the washer and nut from the round bar first and then 1. Insert the screw rods H (Fig. 3-7.1a) of the round bar into the position A (Fig. 3-7.1) of working table and extension table then put the washers and nut at the back side of the table, then fasten them in (there are 4 points for fixing the round bar in this position).
  • Page 20 PANEL SAW INSTRUCTION MANUAL 3-8. FITTING THE SAW BLADE CAUTION 1. Handle the saw blade with gloves. 2. Open blade protect guard before install the saw blade Procedure for fitting or replacing the saw blade is as follows: 1. Set the saw unit to 0 degree by turning switch A counter-clockwise (Fig.3-8.1). 2.
  • Page 21 PANEL SAW INSTRUCTION MANUAL Figure 3-8.2a Figure 3-8.2 Figure 3-8.2b Figure 3-8.3a Figure 3-8.3...

  • Page 22: Riving Knife

    PANEL SAW INSTRUCTION MANUAL 3-9. RIVING KNIFE CAUTION: Always install the riving knife with gloves. The machine is always equipped with one riving knife for 355mm saw blade. Always fit the proper riving knife: 1. Loosen nut A (Fig. 3-9.1) insert the riving knife with a wrench without complete tightening it.
  • Page 23 PANEL SAW INSTRUCTION MANUAL 3-10. CHANGING SCORING BLADE CAUTION: Changing scoring blade with gloves and always pay attention. when changing the blade. 1. Press the emergency button 2. Set the scoring blade in 90 degree by turning the hand wheel A (Fig. 3-10.1) 3.
  • Page 24 PANEL SAW INSTRUCTION MANUAL 3-11. EDGE SHOE, HOLD DOWN & MITER FENCE Edge shoe The edge shoe is used for trimming panel and fixes the work piece on the sliding table. ※ Notice: Edge shoe is demanded in heavy duty processing. Hold down Miter fence Edge shoe...
  • Page 25 PANEL SAW INSTRUCTION MANUAL 3-12. CONNECTION TO THE DUST COLLECTION The connection to the dust collection is necessary for the good machine operation. Always work with the dust collector in operation. The saw is equipped with two dust ports connected to a dust collection system before operation.
  • Page 26 PANEL SAW INSTRUCTION MANUAL 3-13. WIRING & TEST RUN WIRING 1. Make sure that the electric system of the workshop may absorb the machine power and the grounding system follows the prescriptions in force. Notice: Comply with local codes to prevent fire accident. 2.
  • Page 27 PANEL SAW INSTRUCTION MANUAL 4-1. SAW BLADE LIFTING AND TILTING I. SAW BLADE LIFTING Turn button B (Fig. 4-1.1) counter clockwise: the saw blade rises. Adjust the saw blade height according to the work piece thickness. The saw blade height must exceeds the piece thickness 1 ~ 1.5cm Set the guard C (Figure 4-1.1a) to a max.
  • Page 28 PANEL SAW INSTRUCTION MANUAL 4-2. SCORING BLADE ADJUSTING I. SCORING BLADE HEIGHT ADJUSTING 1. Loosen nut A (Fig. 4-2.1) 2. Turn the knob B (Fig. 4-2.1) till the scoring blade has reached to the height desired, then tighten nut A (Fig. 4-2.1) 3.
  • Page 29 PANEL SAW INSTRUCTION MANUAL III. USE OF SCORING BLADE The scoring blade is used to avoid the chipping on the bottom pat of panels coated with finishing material. Take Fig 4-2.3 as reference. A. Single blade: with blade thickness equal to the saw blade one. B.

  • Page 30: Control Panel Operation

    PANEL SAW INSTRUCTION MANUAL 4-3. CONTROL PANEL OPERATION Figure 4-1.1 Control panel close-up A. Read out for main blade angle B. Switch for main blade tilting C. POWER LIGHT D. Switch for main blade rising E. MAIN BLADE ON Button—Start the main saw blade. F.

  • Page 31: Speed Change

    PANEL SAW INSTRUCTION MANUAL 4-4. 3 SPEED CHANGE 1. Set the saw unit down 2. Stop the machine , turn the main switch to 0 ; then lock it and indicating this with a sign 3. Open the rear door 4.
  • Page 32 PANEL SAW INSTRUCTION MANUAL 4-5. SETTING THE RIP FENCE UNIT FOR PARALLEL CUTS Make sure the distance value before operation 1. Turn off power , and lift the saw guard 2. Unlock the rip fence unit A(Fig. 4-5.1) by loosing knob F (Fig. 4-5.1) & pull up handle B(Fig.
  • Page 33 PANEL SAW INSTRUCTION MANUAL I. ADJUSTING THE RIP FENCE UNIT FOR PARALLEL CUTS Move sliding table G(Fig. 4-5.3) lock knob H(Fig. 4-5.3) Lift lever A (Fig. 4-5.2) for unlocking the fence unit. Move the fence unit to the desired position ( readout the value on fence scale C(Fig.
  • Page 34 PANEL SAW INSTRUCTION MANUAL II. POSITION OF FENCE PLATE 1. Vertical position (Fig. 4-5.4a) turn to the work piece 2. Horizontal position (Fig. 4-5.4b) for cutting thin work piece and for slanting cuts. It will be safer to move the work piece forwards by using pusher. NOTE: For the execution of special working, the operators are obliged to put his hands near the tools.

  • Page 35: Sliding Table

    PANEL SAW INSTRUCTION MANUAL 4-6. SLIDING TABLE CAUTION: Lock sliding table before placing heavy work piece for safe location. The sliding table is moved on high precision sideways which is made of hardened steel for a uniform and smooth motion with less friction and obtain accurate cutting. The sliding table is locked and unlocked by lever A (Fig.
  • Page 36 PANEL SAW INSTRUCTION MANUAL 4-7 SETTING THE CROSSCUT FENCE 1. Turn threaded nut C (Fig. 4-7.1a) to make crosscut fence exactly vertical with sliding table. Then lock knob D (Fig. 4-7.1a) to fix A (Fig. 4-7.1. 2. Turn on the machine, then trimming the panel with the crosscut fence. Figure 4-7.1 90°...
  • Page 37 PANEL SAW INSTRUCTION MANUAL I. SQUARE CUTTING TEST 1. Lock all knobs for crosscut fence. 2. Lower the guard, then do test trimming to A, B, C & D (Fig. 4-7.2) of the testing panel. 3. After cutting, measuring the cutting width of E & F (Fig. 4-7.2). As a test for square cutting, the length of them MUST be the same.
  • Page 38 PANEL SAW INSTRUCTION MANUAL III. RULE ADJUSTING FOR OBLIQUE CUTS 1. Loosen knob D(Fig. 4-7.4a)& F(Fig. 4-7.4b) to change position of crosscut fence 2. Adjust the position for making sure the right side of the fence A (Fig. 4-7.4) aligning with the desired angle. ※...
  • Page 39 PANEL SAW INSTRUCTION MANUAL 5-1. Machine cleaning & check Before carrying out maintenance, adjustments or demounting any machine member, turn the main switch to 0. Then lock it and indicate this with a sign. The general cleaning can extend life of usage for the machine and it would also affect operation safety.
  • Page 40 PANEL SAW INSTRUCTION MANUAL Cleaning & Checking Schedule Weekly Monthly 3-month 6-month Check items Daily yearly   Check emergency stop and indicate lamp whether normal or not?    Check the integrity of noise, pressure and ventilation of the machine.

  • Page 41: Periodical Lubrication

    PANEL SAW INSTRUCTION MANUAL 5-2. PERIODICAL LUBRICATION An accurate lubrication ensures the long life of usage as well as the best performance of the machine. CAUTION Weekly lubricate with grease Disconnect the electrical Trunnions and the linear guides A & B (Fig. and pneumatic system 5-2.1) for height adjusting and tilting of the saw before maintenance...

  • Page 42: Replacing Belt

    PANEL SAW INSTRUCTION MANUAL 5-3. REPLACING BELT Disconnect the machine from the electrical and pneumatic system I. REPLACING THE SCORER SPINDLE BELT 1. Set the saw unit 45∘tilted by turning the wheel 2. Open the rear door 3. Lift the small motor A (Fig. 5-3.1). When the belt B(Fig. 5-3.1) is slack, it can be replaced 4.
  • Page 43 PANEL SAW INSTRUCTION MANUAL II. REPLACING THE SAW SPINDLE BELTS 1. Set the saw unit 45∘tilted by turning the wheel. 2. Open rear door 3. Use wrench to turn Adjust Lever A (Figure 5.3.2) to make motor being moved down and make the belt B (Figure 5.3.2) slacked 4.
  • Page 44 PANEL SAW INSTRUCTION MANUAL TOOLS INVENTORY  Tool Box  Riving Knife 300~350mm  Open spanner  Rob for fixing spindle  Push Stick...

  • Page 45: Troubleshooting

    PANEL SAW INSTRUCTION MANUAL WARNING-Disconnect the machine from the power source before troubleshooting or serious personal injury could occur. Problem Possible cause Troubleshooting The machine cannot be 1. Door in machine frame or saw 1. Close the machine door or cover plate. switched on.
  • Page 46 PANEL SAW INSTRUCTION MANUAL Problem Possible cause Troubleshooting Motor fails to develop full 1. Power line overloaded with 1. Reduce load on power line. power (output of motor lights, appliances, and other decreases rapidly with motors. decrease in voltage at 2.
  • Page 47 PANEL SAW INSTRUCTION MANUAL Problem Possible cause Troubleshooting The finished size of the 1. Dimension scale for cutting 1. Reset the flip stop to correct size. cut workpiece does not widths is misadjusted. match the cutting width 2. Incorrect fence position. 2.
  • Page 48 PANEL SAW INSTRUCTION MANUAL Problem Possible cause Troubleshooting Workpiece has chip out 1. Scoring blade height is 1. Adjust the height of the scoring blade. on the bottom edge. incorrect. 2. Scoring blade is not aligned 2. Align the scoring blade. with the main blade.

  • Page 49: Parts Name

    ASSEM 1.1.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 208247 Plate SH100700 Hex Head Bolt M10*35 NH101700 208239 Machine frame SH121000 Hex Head Bolt M12*50...
  • Page 50 ASSEM 1.1.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE WS120000 Lock Washer 203410 Ring WS060000 Lock Washer SR069400 Cap Screw M6*16 ST049300 Tap Screw 170736 Hanger 207128 Plate SP060200 Pan Head Screw(+)/W M6x10 SG050200 Hex Flange Screw M5*10 203412 Block SP040500 Pan Head Screw(+)/W...
  • Page 51 ASSEM 1.1.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SP060200 Pan Head Screw(+)/W M6*10 207723 Plate WF061310 Washer M6x13 NF061000 Hex Flange Nut 150527 2x300x7.5(M/M) 200867 Electric.Panel SH161100 Hex Head Bolt M16x50 NH162400 Hex Nut SS080500 Set Screw M8*25 NH081300 Hex Nut 205397A...
  • Page 52 ASSEM 1.1.4...
  • Page 53 ASSEM 1.1.4 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 208275 Plate GK/A405A 208330 Plate GK/A405A3/A5 208247A Plate SH100700 Hex Head Bolt M10*35 NH101700 208239 Machine frame SH121000 Hex Head Bolt M12*50 WS120000 Lock Washer 203410 Ring WS060000 Lock Washer SR069400 Cap Screw M6*16...
  • Page 54 ASSEM 1.1.4 ITEM PART NO PARTS NAME SIZE Q`TY NOTE ST040204 Tap Screw M4*10 SP050400 Pan Head Screw M5*20 709421 Strain Relief PG20 207749 Strain Relief MGB50-39B 207748 Plate WS060000 Lock Washer SR069300 Cap Screw M6*12 206442 Hole Plugs HP-38 206345-32 Plate 207309-33...
  • Page 55 ASSEM 1.1.4 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SH100640 Hex Head Bolt M10*30 NH101700 Hex Nut SH101340 Hex Head Bolt M10*65 NH101400 Hex Nut 994817 Emergency Stop Button R2 PNR4-2B-R 994819 Emergency Stop Button R2 PNR4-3B-R A3,A5 SH120500 Hex Head Bolt M12*25 WS120000...
  • Page 56 A405M A405_1.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SS100400 Set Screw M10*20 NH101700 Hex Nut 207077 Left Ext. Plate STANDARD 207151 Left Ext. Plate OPTION R / S SR100500 Cap Screw M10*25 206643 Table 207078 Ext. Plate 207079 Ext.
  • Page 57 A405A ASSEM 2.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 205240 Switch Button Cut Out 994993 Switch Button R2 PNF-1A-W 994855 Switch Button-ON R2 PNF-1A-G 994856 Switch Button-OFF R2 PNF-1B-R 207738 Label 208276 Plate WS060000 Lock Washer SR069400 Cap Screw M6*16 994817 Emergency Stop Button...
  • Page 58 A405M A405_2.5 ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB208327 Control Panel ASM 205240 Switch Button Cut Out 994855 Switch Button-ON R2 PNF-1A-G 994856 Switch Button-OFF R2 PNF-1B-R YK.24V φ22 (W) 996002 Pilot Lamp 205581 Label 208327 Plate WS060000 Lock Washer SR069400 Cap Screw...
  • Page 59 QCA405M030101 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 208069F1L Protection Cover 0020 AB136012-5 0030 SH059300 Hex. Head Screw M5*0.8*12 0040 WS050000 Spring Washer...
  • Page 60 QCA405M030101 ITEM PART NO PARTS NAME SIZE Q`TY NOTE M5*φ10 0050 WF051010 Flat Washer 0060 150527 Sponge 2*300*7.5(M/M) 0070 SF089300 Pan Head Screw(＋)/W M8*1*12 0080 206118 Exhaust Pipe 5 " 0090 207940 Door Latch M5*φ10 0100 WF051010 Flat Washer 0110 WS050000 Spring Washer 0120...
  • Page 61 A405A ASSEM 3.1.1...
  • Page 62 A405A ASSEM 3.1.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 208069F1L Cover AB136012-3 Door Safety Switch Assembly 136012 Door Safety Switch 709411 Strain Relief PG11 SP040700 Pan Head Plate M4*35 206341 Fix Plate IC200807 STOP CORD 0.75x2Cx2Mx3Y1.E 1 IC207016 STOP CORD 0.75x2Cx2.9Mx3Y1.E 1 S,NOV...
  • Page 63 A405A ASSEM 3.1.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE NH081300 Hex Nut SH080600 Hex Head Bolt M8*30 208070 Plate M6*ψ16 WF061620 Washer WS060000 Lock Washer SR060400 Cap Screw M6*20 LM208001 Warning Label SH081500 Hex Head Bolt M8*75 NH081300 Hex Nut SS081100 Set Screw...
  • Page 64 QCD400E0302...
  • Page 65 QCD400E0302 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 SR100402 Hex. Socket Screw M10*1.5*20(L.H) M10*φ40*t3 0020 WF104030 Flat Washer 0030 205788 Motor Pulley 50HZ X2 / CE 0040 994220 Thrust Bearing 0050 210018A Main Motor Fixed Plate 0060 210008 Motor Plate Rotate Shaft Φ55*Φ31*t4 0070...
  • Page 66 A405M A405_3.3...
  • Page 67 A405M A405_3.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 999455 AB208186 Fix Block ASM NH121900 Hex Nut M12*1.75 M12*ψ40 WF124030 Washer SS050200 Setscrew M5x10 206461 Fix Block 208186 Fix Block SC120800 Carriage Screw M12x40 SI069400 Counter Sunk Screw M6*16 208141 M24*3.0P 210059...
  • Page 68 A405A ASSEM 4.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SR080400 Cap Screw M8×20 WS080000 Lock Washer 210038 Gear wheel...
  • Page 69 A405A ASSEM 4.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SR101600 Cap Screw M10*80 205568 Angle Driver NL101700 Lock Nut NH101700 Hex Nut RS100000 Retaining Ring SH120500 Hex Head Bolt M12*25 WS120000 Lock Washer M12*ψ30 WF123025 Washer 208062 Shaft M6*ψ16 WF061620 Washer...
  • Page 70 A405A ASSEM 5.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 207139 NH142200 Hex Nut 208124 Plate WS080000 Lock Washer SJ080500 Button Head Screw M8*25 RS100000 Retaining Ring AB205545 Height Driver 205545 Height Driver 205545-1 Gear 994656 Switch SR101300 Cap Screw M10*65 NH101700 Hex Nut...
  • Page 71 A405M A405M_6.1...
  • Page 72 A405M A405M_6.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SH120440 Hex Head Bolt M12×20 206320 Flange 206321 Shaft BB600304 Ball Bearing 6003LLB RS150000 Int. Retaining Ring ψ26*ψ34 t=0.3 ( 6202 ) WW263403 Wave Washer RR350000 Int. Retaining Ring 206497 Shaft WF061310 Washer...
  • Page 73 ASSEM 6.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SH089400 Hex Head Bolt M8*16 WS080000 Lock Washer...
  • Page 74 ASSEM 6.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE M8*ψ30 WF083030 Washer 206590 Spring 208172 Shaft SS069300 Setscrew M6*12 205919 Ring SR080400 Cap Screw M8*20 WS080000 Lock Washer M8*ψ30 WF083030 Washer 207033 Ring 207034 Ring SH069400 Hex Head Bolt M6*16 208120 Fix Plate...
  • Page 75 ASSEM 6.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 206627 Pully 50Hz 206336 Pully 60Hz LF150020 Belt 18WX380L 50Hz/60Hz 208184 Shaft SJ080400 Button Head Screw M8*20 WS080000 Lock Washer 208185 Plate M14*ψ35 WF143530 Washer NL142200 Lock Nut MH206301 Scoring Motor 0.75P (M20P) Feature NH101700...
  • Page 76 D401_7.5...
  • Page 77 D401_7.5 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 205208 Sliding Tube 203545 Hex Nut 205505 Screw Threads 203470 Plug 40*120 NH081300 Hex Nut SH080400 Hex Head Screw M8*20 207948 Rotary Arm BB620203A Ball Bearing 6202LLU 208405 Shaft AB203356 Ring Assembly BB620202 Ball Bearing 6202ZZ...
  • Page 78 ASSEM 7.5.1...
  • Page 79 ASSEM 7.5.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 205395 Sliding Tube 203545 Hex Nut 205505 Screw Threads 203470 Plug 40*120 NH081300 Hex Nut SH080400 Hex Head Screw M8*20 207948 Rotary Arm BB620203A Ball Bearing 6202LLU 208405 Shaft AB203356 Ring Assembly BB620202 Ball Bearing...
  • Page 80 ASSEM 8.0...
  • Page 81 ASSEM 8.0 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 203116 Fixed Plate ψ8×20 PS082000 Spring Pin SI100400 Counter Sunk Screw M10×20 200910 Plug 40×80 203979 Frame 201576 Hole Plugs HP-09 NH081300 Hex Nut WS080000 Lock Washer 201103 T-Nut M8x1.25p 203284 Hole Plugs HP-19...
  • Page 82 ASSEM 8.0 ITEM PART NO PARTS NAME SIZE Q`TY NOTE NS050800 Square Nut 203110 Screw M5×10 RS140000 Retaining Ring 203109 Square Pipe 203230 Hole Plugs HP-16 SR060800 Cap Screw M6*40 207219 Fixed Block 207220 Plate SS069100 Setscrew M6*6 SH120801 Screw M12×1.25×40 NH121901...
  • Page 83 QCP400A0801 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 201576 Plug HP-09 0020 203497A Block 0030 203491 Fixed Block V1.2 0040 WS080000 Spring Washer 0050 SR080200 Hex. Socket Screw M8*1.25*10 0060 203493 Block 0070 203494 Fixed Block 0080 WS050000 Spring Washer 0090 SJ059400...
  • Page 84 A405A ASSEM 8.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 201576 Hole Plugs HP-09 207734 Fixed Plate WS080000 Lock Washer SR080200 Cap Screw M8×10...
  • Page 85 P400A 9.0.2...
  • Page 86 P400A 9.0.2 ITEM PART NO PART NAME SIZE Q`TY NOTE 205430 Square Pipe SI050200 Counter Sunk Screw M5×10 205428 Fixed Block SI069300 Counter Sunk Screw M6×12 BB600002 Ball Bearing 6000ZZ 203267 Spindle 203285 Set Screw M4×6 203268 Fixed Block BB680002 Ball Bearing 6800ZZ SI060200...
  • Page 87 P400A 9.0.2 ITEM PART NO PART NAME SIZE Q`TY NOTE 203120 Block 203078 Square Fence M5×ψ10 WF051010 Washer SR059200 Cap Screw M5×12 205544 Wearing Tape 875x15 LM001320 Ruler Right 0~2000 LM001601-1 Ruler Right 0~2000 S, ST SP049100 Screw 205429 Block SR060500 Cap Screw M6×25...
  • Page 88 P400A 9.0.6 ITEM PART NO PART NAME SIZE Q`TY NOTE 203264 Square Pipe SI050200 Counter Sunk Screw M5×10 203266 Fixed Block SI069300 Counter Sunk Screw M6×12 BB600002 Ball Bearing 6000ZZ 203267 Spindle 203285 Set Screw M4×6 203268 Fixed Block BB680002 Ball Bearing 6800ZZ SI060200...
  • Page 89 P400A 9.0.6 ITEM PART NO PART NAME SIZE Q`TY NOTE 203269 Spindle SS050100 Set Screw M5×5 SR059300 Cap Screw M5×12 WS050000 Lock Washer SR040200 Cap Screw M4×10 203270 Fixed Block SM040200 Sunk Head Screw M4×10 203235 Ext.Fence 203272 Fixed Block 203292A Plug 203273...
  • Page 90 QCD4010902...
  • Page 91 QCD4010902 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 AB207207 SS-A401(5)(M) 0020 AB207205A Ext. Fence Assembly 0040 200827 Knob Bolt M8x1.25px40L 0050 NA081300 Acorn Nut M8*1.25 0060 203790 Knob 0070 SJ080400 Pan Head Socket Screw M8*1.25*20 0080 203598 Rod End Screw M8x1.25p M8*φ18*t1.8 0090...
  • Page 92 P400A 9.2.1 ITEM PART NO PART NAME SIZE Q`TY NOTE 203178 Bushing 203275 Spindle 203105 Pedestal AB203261R Monitor ASM NL030600 Lock Nut M3*0.6 203466 Label SN039300 Sunk Head Screw M3*12 203261...
  • Page 93 P400A 9.2.1 ITEM PART NO PART NAME SIZE Q`TY NOTE M3*ψ6 WF030605 Washer NH030600 Hex Nut M3*0.5 203772 Monitor 203260 001044 203263 Fixed Plate WS030000 Lock Washer SJ039200 Button Head Screw M3*8 M4*ψ8 WF040808 Washer SJ039100 Button Head Screw M3*6 203783 Plate 203262...
  • Page 94 ASSEM 10.2...
  • Page 95 ASSEM 10.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB205801 Rip Fence Housing Assembly SI069400 Counter Sunk Screw M6*16 206433 Fixed Plate 203193 Shafts NL081000 Lock Nut 200875 Locate Plate SH069400 Hex Head Bolt M6*16 203179 Eccentric Ring 205801 Seat 203213 Eccentric Shaft...
  • Page 96 ASSEM 10.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 203545 Hex Nut 205078 Rule X7，S 205078-1 Rule X7，S 206437 End Washer WS080000 Lock Washer SR089400 Cap Screw M8*16 SR080500 Cap Screw M8*25 S205939 NH203000 Hex Nut 205116A Screw M20*160 200884 Handle 206432...
  • Page 97 A405A3G 11.1 20200306...
  • Page 98 A405A3G 11.1 PART NAME SIZE Q`TY ITEM PART NO NOTE Plate 2395320D-1 SJ069300 Screw M6*12 Top Base 2395320D-2 (3200) 2395320D-3 Hole plug Hex Nut NH081300 WE080000 Washer M10*ψ20 Washer WF102025 SI080700 Counter Sunk Screw M8*35 Ring 2395320D-4 BB620202 Ball Bearing 6202ZZ Eccentric shaft 2395320D-5...
  • Page 99 A405A3G 11.2 ITEM PART NO PART NAME SIZE Q`TY NOTE 2395320D-22 Rack 3200mm SI109300 Counter Sunk Screw M10×12 2395320D-23 BB620202 Ball Bearing 6202ZZ 2395320D-24 Roller 2395320D-25 Shaft 2395320D-26 Roller SJ069300 Screw M6*12 SR069300 Cap Screw M6*12 2395320D-27 Knob 2395320D-28 Shaft 2395320D-29 Ring 2395320D-30...
  • Page 100 A405A3G 11.3 ITEM PART NO PART NAME SIZE Q`TY NOTE 2395320D-35 Bottom Base (3200) 2395320D-36 Front Cover ST040200 Tap Screw M4x10 2395320D-37 Fixed Block SR080500 Cap Screw M8*25 2395320D-38 Fixed Block SR080500 Cap Screw M8*25 SS060200 Setscrew M6*10 2395320D-39 Teeth Locate Plate 2395320D-40 Locate Block 2395320D-41...
  • Page 101 A405A ASSEM 12.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB205075 Hood Assembly 205075 Hood ST029404 Screw M3×16 ST029304 Screw M3×12 205076 Hood 203110 Screw M5×10 205124 Shaft NL101700 Lock Nut 205162 Cap Screw M10×25 200535 Hose Clamp 2-1/2" Optional φ60x3000 200536...
  • Page 102 ASSEM 12.6.3...
  • Page 103 ASSEM 12.6.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 207770 Fixed Bracket SR080500 Cap Screw M8x25 WS080000 Lock Washer WF081818 Washer M8x18 207774 Fixed Bracket NH203000 Hex Nut ψ22*ψ60*t8 203338 Washer 205116 Screw M20*130 NH121900 Hex Nut SH121400 Hex Head Bolt M12X70 201039 SR080400...
  • Page 104 ASSEM 12.6.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SR100900 Cap Screw M10*45 205557 Handle MS-737-1-A-330 207915 Case M10×ψ25 WF102520 Washer NH101700 Hex Nut 207758 Plate WS050000 Lock Washer SR050200 Cap Screw M5×10 204196 NFE-08B Plastic Corrugated Tubing 998808 Strain Relief N-MGQ32-34B 150527...
  • Page 105 D401_12.9...
  • Page 106 D401_12.9 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SR060400 Cap Screw M6*20 WS060000 Lock Washer M6*ψ19 WF061920 Washer AB207981 Link ASM SH100700 Hex Head Bolt M10*35 WS100000 Lock Washer SR060900 Cap Screw M6*45 WS060000 Lock Washer SH100700 Hex Head Bolt M10*35 M10*ψ20 WF102020...
  • Page 107 D401_12.9 ITEM PART NO PARTS NAME SIZE Q`TY NOTE NH121900 Hex Nut SH121400 Hex Head Bolt M12X70 201039 SR060400 Cap Screw M6*20 WS060000 Lock Washer M6×ψ16 WF061620 Washer 207776 Fixed Plate S,207352 NH061000 Hex Nut AB207866 Rear Cover ASM ST030500 Tap Screw M3.5x25 207866...
  • Page 108 D401_12.9 ITEM PART NO PARTS NAME SIZE Q`TY NOTE NH081300 Hex Nut SR080600 Cap Screw M8x30 WF081818 Washer M8x18 WS080000 Lock Washer SR080500 Cap Screw M8x25 207971 Square Tube 207973 Plate SJ060200 Cap Screw M6x10 ITEM PART NO PARTS NAME SIZE Q`TY NOTE...
  • Page 109 ASSEM 12.10...
  • Page 110 ASSEM 12.10 ITEM PART NO PARTS NAME SIZE Q`TY NOTE SR060400 Cap Screw M6*20 WS060000 Lock Washer M6*ψ19 WF061920 Washer AB207981 Link ASM SH100700 Hex Head Bolt M10*35 WS100000 Lock Washer SR060900 Cap Screw M6*45 WS060000 Lock Washer SH100700 Hex Head Bolt M10*35 M10*ψ20 WF102020...
  • Page 111 ASSEM 12.10 ITEM PART NO PARTS NAME SIZE Q`TY NOTE WF081818 Washer M8x18 NH081300 Hex Nut LM207031 Warning Label LM207032 Warning Label LM207033 Warning Label AB205355 Protection Hood ASM 207867 Guard SP040200 Pan Head Screw M4*10 205355 Protection Hood AB207868 Roller ASM SP040200 Pan Head Screw...
  • Page 112 A405A ASSEM 13.2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 203017 Gear Wheel ψ10*30 PP103000 210055 Encoder Fixed Plate 206454 Encoder Shaft Ring 203154 Encoder M6*ψ19 WF061920 Washer WS060000 Lock Washer SJ069400 Button Head Screw M6*16 M3*ψ6 WF030605 Washer WS030000 Lock Washer SR039100...
  • Page 113 QCA405M1302 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 203017 Gear Wheel φ10*30 0020 PP103000 0030 210055 Encoder Fixed Plate 0040 206454 Shaft Of Bushing 0050 AB203154 M6xφ19 0060 WF061920 Flat Washer 0070 WS060000 Spring Washer 0080 SJ069400 Pan Head Socket Screw M6*1*16 M3*φ6 0090...
  • Page 114 A405A ASSEM 14.1 ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB207065-2 Down Press ASM D.E.M 207143 Adjust Handle 100271 Ball Knob M8×P1.25 207070 Handle Bar 207067 RS140000 Ext. Retaining Ring 207069 Spring 207145 207065 Down Press 207068 Shaft NH602300 Hex Nut 5/16 200807...
  • Page 115 ASSEM 14.2.3 ITEM PART NO PARTS NAME SIZE Q`TY NOTE AB208390 Block SI100400 Counter Sunk Screw M10*20 208390-1 Block 208390-2 Handle 208390-3 Hole Plugs ST040600 M4*30 208390-4 Knob M10*16...
  • Page 116 D401_14.3 PARTS NAME SIZE Q`TY ITEM PART NO NOTE AB201830 Edge Shoe Plate Assembly Edge Shoe Plate 201830 φ5xφ16 Spint Pin PS051800 WF102025 Washer M10x25 Knob 203718 T-Nut M10x1.5p 201829...
  • Page 117 ASSEM 14.4.5 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 200526 Fence Plate 201632 Spring plungers with ball M4×9 AC198170AB1 Miter Gauge Assembly S, A AC204295A Miter Gauge Assembly S, A 198170A Miter Gauge Body NH050800 Hex Nut SR050500 Cap Screw M5×25 SP049300 Pan Head Bolt...
  • Page 118 AB136012-5+AB136012-5C AB136012-5 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 AB136012A 0050 IC200810 Stop Control Cord 0.75x2Cx3.1Mx4Y AB136012-5C ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 AB136012A 0050 Cord (CSA) 18AWGx2Cx3.1Mx4Y AA01823104Y00E40...
  • Page 119 AB198170AD...
  • Page 120 AB198170AD ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0020 205758 Fence Plate L:900mm 0030 200830 Plate V1.2 0040 ST040200 Tapping Screw M4*0.7*10 0050 201103 Fixed Block 0060 205715 Fixed Plate 0070 WS080000 Spring Washer 0080 SJ089400 Pan Head Socket Screw M8*1.25*16 0090 LM200149...
  • Page 121 AB203348 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 RS150000 Retaining Ring (S-type) 0020 BB620202 Ball Bearing 6202ZZ 0030 203348 Roller 0040 203349 Shaft V1.1...
  • Page 122 AB207065-2 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 207143 Quick Release Handle 0020 100271 Ball Knob 0030 207070 Handle 0040 207067 0050 RS140000 Retaining Ring (S-type) 0060 207069 Spring 0070 207145 Lock Pin 0080 207065 Down Press Base 0090 207068 Down Press Shaft...
  • Page 123 AB207205...
  • Page 124 AB207205 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 207212 Extended Tube 0020 207213 Rip Fence Magnifier 0030 207216 Aluminum Rule 0040 205544 Fiber Rubber Strip 0050 207205-1 Fence Plate 0060 207884 Fixed Plate 0070 207205-2 Extend Fence 0080 SS069100 Set Screw M6*1*6...
  • Page 125 AB207205A...
  • Page 126 AB207205A ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0010 207212-1 Ext. Tube 0020 207213 Rip Fence Magnifier 0030 207216-1 Aluminum Ruler (Metric) 0040 205544 Fiber Rubber Strip 0050 207205-1 Fence Plate 0060 207884 Fixed Plate 0070 207205-2 Extend Fence 0080 SS069100 Set Screw...
  • Page 127 AB207207 ITEM PART NO PARTS NAME SIZE Q`TY NOTE 0020 207203 Stop Plate Shaft 0030 207207 Stop Plate φ15.5xφ22x0.5t 0040 207208 Copper Washer 0050 207263 Knob Bolt M8x1.25px42L M8*φ20*3mm 0060 WF082030 Flat Washer M8*φ18 0070 WF081820 Flat Washer 0080 207235 Nylon Acorn Nut 0090 207200...
