Page 1 DPO70000SX Series Oscilloscopes Quick Start User Manual *P077335709* 077-3357-09...
Page 3 DPO70000SX Series Oscilloscopes Quick Start User Manual Register now! Click the following link to protect your product. tek.com/register *P077335709* 077-3357-09 March 2024...
Page 4 Copyright © 2024, Tektronix. 2024 All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material. Specifications and price change privileges reserved.
Page 5 Contents Contents List of Figures....................................9 List of Tables....................................10 Important safety information................................11 General safety summary..............................11 Service safety summary...............................13 Terms in the manual................................13 Terms on the product................................13 Symbols on the product............................... 13 Compliance Information................................14 EMC compliance..................................14 Safety compliance................................14 Environmental compliance..............................16 Preface......................................17 Install your instrument.................................
Page 6 Contents Activating Windows 10.................................45 Restoring instrument operating system and product software.....................45 Operating system restore..............................46 Internal recovery utility................................. 46 Product software installation..............................47 Getting acquainted with your instrument.............................48 Front-panel connectors................................ 48 Rear-panel connectors.................................50 Interface and display................................51 Control panel..................................52 Accessing online help................................53 Accessing menus and control windows..........................
Page 7 Contents Trigger coupling................................88 Horizontal position................................ 89 Slope and level................................89 Delayed trigger system..............................89 Choosing a trigger type................................89 Trigger selections.................................91 Checking trigger status................................ 92 Using A (Main) and B (Delayed) triggers..........................93 Trigger on B event................................ 94 B trigger after delay time...............................95 B triggers after arm on A...............................95 Arm-on-A then Trigger-on-B (Horizontal delay on).......................
Page 8 Contents Snapshot..................................137 Annotate measurements.............................137 Reference levels................................. 138 Taking cursor measurements.............................139 Setting up a histogram............................... 140 Using math waveforms..............................142 Using spectral analysis..............................144 Using the error detector..............................146 Using mask testing................................150 Using limit testing................................153 MyScope....................................155 Creating a new MyScope control window.......................... 155 Using MyScope control windows............................
Page 9 List of Figures List of Figures Figure 1: Wear an antistatic wrist strap............................24 Figure 2: Installing a connector saver............................24 Figure 3: Installing a cable................................25 Figure 4: Use a second backing wrench............................. 25 Figure 5: ATI with TekConnect channels............................. 48 Figure 6: TekConnect channels..............................49 Figure 7: Fast edge signals before deskew..........................
Page 10 List of Tables List of Tables Table 1: Maximum ATI voltage range............................22 Table 2: Stand-Alone instrument..............................38 Table 3: Multi-Unit configuration..............................38 Table 4: Front-panel connectors..............................49 Table 5: Rear-panel connectors..............................50 Table 6: Amplitude measurements............................132 Table 7: Time measurements..............................133 Table 8: More measurements..............................133 Table 9: Histogram measurements............................
Page 11 Use only insulated voltage probes, test leads, and adapters supplied with the product, or indicated by Tektronix to be suitable for the product. Observe all terminal ratings To avoid fire or shock hazard, observe all rating and markings on the product. Consult the product manual for further ratings information before making connections to the product.
Page 12 Use care when lifting and carrying the product. This product is provided with a handle or handles for lifting and carrying. WARNING: The product is heavy. To reduce the risk of personal injury or damage to the device get help when lifting or carrying the product. Use only the Tektronix rackmount hardware specified for this product.
Page 13 Important safety information Service safety summary The Service safety summary section contains additional information required to safely perform service on the product. Only qualified personnel should perform service procedures. Read this Service safety summary and the General safety summary before performing any service procedures.
Page 14 Compliance Information Compliance Information This section lists the EMC (electromagnetic compliance), safety, and environmental standards with which the instrument complies. EMC compliance EC Declaration of Conformity – EMC Meets intent of Directive 2014/30/EU for Electromagnetic Compatibility. Compliance was demonstrated to the following specifications as listed in the Official Journal of the European Communities: EN 61326-1, EN 61326-2-1 1 2 3 4...
Page 15 Compliance Information Low Voltage Directive 2014/35/EU. • EN 61010-1. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part 1: General Requirements. U.S. nationally recognized testing laboratory listing • UL 61010-1. Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part 1: General Requirements.
Page 16 Directives 2012/19/EU and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Tektronix Web site (www.tek.com/productrecycling). Perchlorate materials This product contains one or more type CR lithium batteries. According to the state of California, CR lithium batteries are classified as perchlorate materials and require special handling.
Page 17 Preface Preface This manual describes the installation and basic operation of DPO70000SX series instruments. For additional operating information, refer to the instrument help on your instrument. The following instruments are supported by this document: • DPO77002SX • DPO75902SX • DPO75002SX •...
Page 18 User manual. Operation and user interface Instrument help from the Help menu. Programmer commands Programmer manual. This manual is available on the Tektronix Web site (www.tektronix.com/manuals). Conventions used in this manual The following icons are used throughout this manual. Step...
Page 19 Install your instrument Unpack the instrument and check that you received all items listed as Standard Accessories. Recommended accessories, probes, instrument options, and upgrades are listed in the online help. Check the Tektronix Web site (www.tektronix.com) for the most current information.
Page 20 Install your instrument Operating requirements WARNING: To prevent injury and instrument damage, do not operate the instrument while the instrument is resting on its rear feet. 1. Place the instrument on a cart or bench. The instrument should rest on its bottom feet. An optional rack mounting kit is available. Observe the following clearance requirements and dimensions: •...
Page 21 Install your instrument Preventing instrument damage Preventing ESD CAUTION: A direct electrostatic discharge can damage the instrument input. To learn how to avoid this damage, read the following information. Electrostatic discharge (ESD) is a concern when handling any electronic equipment. The instrument is designed with robust ESD protection, however it is still possible that large discharges of static electricity directly into the signal input may damage the instrument.
Page 22 Install your instrument Observe maximum input voltage WARNING: Observe all terminal ratings. To avoid damaging the instrument, observe all rating and markings on the product. Consult the product manual for further ratings information before making connections to the product. Do not apply a potential to any terminal, including the common terminal, that exceeds the maximum rating of that terminal. The maximum input voltage for the ATI (Asynchronous Time-Interleaved) input is ±0.75 V .
Page 23 Install your instrument WARNING: To avoid eye damage, ware eye protection when using compressed air. 3. With the connector pointed down, use low pressure compressed air, at an angle to the connector, to clean the connectors. 4. If the connector still needs cleaning, use an appropriately sized swab moistened with isopropyl alcohol to clean the connector threads and mating surfaces.
Page 24 Install your instrument Figure 1: Wear an antistatic wrist strap 2. Use the supplied connector saver to protect the instrument connector. When not in use, protect against dirt and ESD damage by installing the end cap. Alternate locations to store the ATI protective cover include the upper right corner of the front panel and to the right of the audio connectors on the rear panel.
Page 25 Install your instrument Figure 3: Installing a cable CAUTION: Failure to prevent rotation of the center conductors when making connections to the ATI input will damage your instrument. If necessary use a second backing wrench on the cable, to prevent its rotation. Use the supplied torque wrench to tighten (8 inch-pounds) all connectors.
Page 26 Install your instrument 2. Use the front-panel power button to switch the instrument on. The power button indicates instrument power states: • No light – no power applied • Yellow – standby mode • Green – powered on Power off the instrument Procedure 1.
Page 27 Install your instrument 2. To completely remove power to the instrument, perform the shutdown just described, and then remove the power cord from the instrument. Multi-instrument configuration Connect instruments in a multi-instrument configuration to create an up to 4 channel, highest bandwidth, and highest sample rate system with synchronized trigger and sample clock.
Page 28 Install your instrument Standard orientation of the top feet is useful when placing an instrument inverted on the work bench. Standard orientation of the top feet is also use when stacking an OM4000 on the instrument.
Page 29 Install your instrument Use the rotated orientation of the top feet to stack two instruments on top of each other. When stacking two instruments, the bottom feet sit in the holes exposed when the top feet are rotated. DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 30 Install your instrument Before startup All instruments in a multi-Instrument configuration must be connected properly before powering on the instruments. If the configuration is changed after the instruments are powered on, a system restart may be required. If an instrument is not connected in a multi-instrument configuration, the instrument powers on in its stand alone mode, not multi-instrument mode.
Page 31 Install your instrument Connect UltraSync bus cable bundles to the Extension. At the Extension, connect each UltraSync cable bundle set to the designated ports: 1. Connect the clock cable to the 12.5 GHz Clock In connector (8 in-lbs torque). 2. Connect the trigger cable to the To Master Trigger connector. 3.
Page 32 Install your instrument If powering off a multi-instrument system, power off the master first. Multi-instrument power on During the start-up process the instrument checks to see if instruments are connected in a Multi-instrument configuration. If instruments are not connected, the instrument powers up in stand-alone mode. If instruments are connected, the configuration is validated. If the configuration is not valid, guidance is provided to help you create a valid configuration.
Page 33 Install your instrument The following image shows a master connected incorrectly and provides guidance to fix the problem (provide the missing connection to the extension). The following images show the master and extension with valid connections. DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 34 Install your instrument After the multi-instrument connections are verified and the instruments display their operating status displays, the master displays its status and timer display. Pause the timer if you have additional changes to make before the oscilloscope application starts. Press Start Scope to bypass the timer.
Page 35 TekConnect channel data using programmable interface commands. Waveform data is not sent to the Master. If you plan to use Time Synchronized mode, contact your Tektronix representative for additional information. After the multi-instrument connections are verified, the instruments display their operating status displays. In this example the Master (A) is acquiring on channel 2 (ATI).
Page 36 Install your instrument After the multi-instrument system powers on, perform a signal path compensation. See Signal path compensation on page 42. Switching between multi-instrument modes To switch among ATI channels, TekConnect channels, and Time Synchronized modes, use the following procedure: 1.
Page 37 Install your instrument Restart of a multi-instrument system To restart your multi-instrument system without powering down the oscilloscopes, do the following step: 1. To shut down the Configuration Manager and all of the Scope applications and then restart them without changing the configuration mode, select File >...
Page 38 Install your instrument Available features Features discussed in this manual that are available on some instruments or configurations are noted in the tables. Table 2: Stand-Alone instrument Feature DPO77002SX, DPO75902SX, DPO75002SX DPO73304SX, DPO72504SX, DPO72304SX, DPO72004SX, DPO71604SX, DPO71304SX State (Clocked Pattern) trigger Available on TekConnect channels Available XYZ mode...
Page 39 Install your instrument Feature DPO77002SX, DPO75902SX, DPO75002SX DPO73304SX, DPO72504SX, DPO72304SX, DPO72004SX, DPO71604SX, DPO71304SX Runt, Transition, Window, Timeout triggers Not available Not available Period, Frequency Not available Not available Pattern (Boolean) Not available Not available Setup/Hold (Clock & Data) Not available Not available State (Clocked Pattern) Not available...
Page 40 Install your instrument Inspect the instrument About this task Every time you power on the instrument, the instrument automatically performs the power-on self test diagnostics. Verify internal diagnostics pass Use the following procedures to verify the functionality of your instrument. 1.
Page 41 Install your instrument 3. Click Run. The test results appear in the diagnostics control window. 4. Verify that all tests pass. If diagnostic failures occur, contact your local Tektronix service personnel. Activating Windows 10 The copy of Microsoft Windows 10 that ships with this product is shipped in Deferred Activation mode. Microsoft has a default activation method that requires a connection to the Internet.
Page 42 Signal path compensation Perform the Signal Path Compensation (SPC) regularly to ensure that your measurements have the highest level of accuracy. Tektronix considers it a best practice to run SPC when using the instrument to measure signals with higher sensitivity (10 mV/div and lower) settings regardless of temperature shift or time since it was last run.
Page 43 Install your instrument 3. When the Temperature Status changes to Ready, click Run SPC to start the calibration. Calibration may take 10 to 15 minutes. Note: Before running the SPC calibration, remove all channel input signals. Note: If you use a drive that has not had SPC run while in the current instrument, you will see a no prior SPC warning message.
Page 44 Install your instrument 5. If the SPC needed icon is red, perform a signal path compensation. Check the color of the SPC Status icon: • Green indicates that SPC successfully passed and the temperature is stable. • Yellow indicates that the instrument is in the warm up state or that it has been over 30 days since SPC was last run. •...
Page 45 Install your instrument 4. Connect mouse. 5. Turn instrument power on. 6. Turn monitor power on. Activating Windows 10 The copy of Microsoft Windows 10 that ships with this product is shipped in Deferred Activation mode. Microsoft has a default activation method that requires a connection to the Internet.
Page 46 Install your instrument To restore or update the product software, you need to download the current version from the Tektronix web site. Note: Restoring or updating the product software does not require that you restore the Windows operating system. Operating system restore CAUTION: Using the restore process reformats the hard drive and reinstalls the operating system.
Page 47 Install your instrument Product software installation About this task Note: For DPO77002SX instruments you must order the product software from Tektronix. Procedure 1. Download the product software installation package. The installation package contains: • Instructions • Product software installer 2. Install the product software following all on-screen prompts.
Page 48 Getting acquainted with your instrument Getting acquainted with your instrument Front-panel connectors Figure 5: ATI with TekConnect channels...
Page 49 Getting acquainted with your instrument Figure 6: TekConnect channels Table 4: Front-panel connectors Identifier Connector Description USB 2.0 Four USB connectors. Chassis ground Banana type ground connection. Ground through 1 MΩ resistor Banana type ground connection. Discharge the static voltage from your body by wearing a grounded antistatic wrist strap while connecting and disconnecting cables and TekConnect adapters.
Page 50 USB 3.0 Four USB 3.0 Host connectors (type A) to connect devices such as a mouse, keyboard, or other USB devices. Tektronix does not provide support or device drivers for USB devices other than the supplied mouse and keyboard. USB device connector VGA port to connect a monitor for extended desktop operation.
Page 51 Getting acquainted with your instrument Interface and display The menu bar mode provides access to commands that control all of the instrument features and functions. The toolbar mode provides access to the most common features. 1. Menu Bar: Access to data I/O, printing, online help, and instrument functions. 2.
Page 52 Getting acquainted with your instrument values in waveforms that are stored or exported for use in other programs. If a math waveform is clipped, it will not affect amplitude measurements on that math waveform. 8. Status: Display of acquisition status, mode, and number of acquisitions; trigger status; date; time; and quick reference to record length and horizontal parameters.
Page 53 Getting acquainted with your instrument 10. Push to turn cursors on or off. 11. Use to search and mark waveforms. 12. Push to turn the touch screen on and off. 13. Turn channel displays on and off. Vertically scale, position, or offset the waveform. Toggle between position and offset. Accessing online help In-depth information is available in the online help on all the features of your instrument.
Page 54 Getting acquainted with your instrument 1. To access any topic in the help system, select Help > Contents and Index..2. Use the Contents, Index, Search, or Favorites tab to select the topic, and then click Display. To navigate within the help system: •...
Page 55 Getting acquainted with your instrument Accessing menus and control windows Access menus and control windows using the following techniques: • Click a menu, and then select a command. • For a shortcut menu, right-click anywhere in the graticule or on an object. The shortcut menu is context sensitive and varies with the area or object where you right-clicked.
Page 56 Verify internal diagnostics pass 1. Power on the instrument. 2. Select Instrument Diagnostics... 3. Click Run. The test results appear in the diagnostics control window. 4. Verify that all tests pass. If diagnostic failures occur, contact your local Tektronix service personnel.
Page 57 Signal path compensation Perform the Signal Path Compensation (SPC) regularly to ensure that your measurements have the highest level of accuracy. Tektronix considers it a best practice to run SPC when using the instrument to measure signals with higher sensitivity (10 mV/div and lower) settings regardless of temperature shift or time since it was last run.
Page 58 Acquisition Note: Before running the SPC calibration, remove all channel input signals. Note: If you use a drive that has not had SPC run while in the current instrument, you will see a no prior SPC warning message. If you see this warning, run SPC. 4.
Page 59 Acquisition Setting up analog signal input Use the drop down menus or the Auxiliary Front Panel to set up your instrument to acquire the signal. If using the drop down menus, do the following steps: 1. Connect the probe or cable to the input signal source. CAUTION: To prevent damage to the instrument, always wear an antistatic wrist strap when making connections to the instrument and observe the maximum input voltage ratings for input connectors.
Page 60 Acquisition 5. If you want to invert the input signal, click the Invert button to toggle invert on and off. The Invert button is in the Vertical Setup menu or the Deskew/Attenuation/Invert menu. 6. Select Horiz/Acq > Horizontal/Acquisition Setup. Adjust the horizontal position and scale: Double click the Position and Scale controls and use the pop-up keypad to make the adjustment.
Page 61 Acquisition 3. Select Horiz/Acq then Autoset. 4. Adjust the vertical position, scale, and offset. 5. Adjust the horizontal position and scale. The horizontal position determines the number of pretrigger and posttrigger samples. DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 62 Acquisition Using default setup 1. To quickly return to the factory default settings, select Recall Default Setup from the file menu or push DEFAULT SETUP on the Auxiliary Front Panel. Using autoset Use Autoset to quickly and automatically set up the instrument (acquisition, horizontal, trigger, and vertical) based on the characteristics of the input signal.
Page 63 Acquisition • If you use Autoset when no channels are displayed, the instrument turns on channel one (Ch 1) and scales it. • Close Autoset Undo control window by clicking the X. After Autoset Undo closes, you can still undo the last Autoset by selecting the Undo Last Autoset command from the Edit menu.
Page 64 Acquisition as the reference edge for alignment. For differential signals, the nearest edge with the opposite polarity as the trigger will be used for alignment. 1. Display Mode where the modes can be: • Standalone for a standalone oscilloscope • Multiscope for multiple ATI/TekConnect instruments •...
Page 65 Acquisition 2. Select the channels to deskew. Ensure that each channel has a live signal attached and it has an edge that is within 0.5 UI of the edge on the trigger channel. 3. Select the slope and level for each channel. 4.
Page 66 Acquisition Figure 8: Fast edge signals after deskew This figure is an example of differential signals before deskew:...
Page 67 Acquisition This figure is an example of differential signals after deskew: DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 68 Acquisition Acquisition concepts Acquisition hardware Before a signal is displayed, it must pass through the input channel where it is scaled and digitized. Each channel has a dedicated input amplifier and digitizer. Each channel produces a stream of digital data from which the instrument extracts waveform records. Sampling process Acquisition is the process of sampling an analog signal, converting it into digital data, and assembling it into a waveform record, which is then stored in acquisition memory.
Page 69 Acquisition Real-time sampling In real-time sampling, the instrument digitizes all of the points it acquires using one trigger event. Use real-time sampling to capture single-shot or transient events. Interpolated real-time sampling In interpolated real-time sampling, the instrument digitizes all of the points it acquires using one trigger event. If the instrument cannot acquire enough samples for a complete waveform at the maximum real-time sample rate, it interpolates.
Page 70 Acquisition Interpolation Your instrument can interpolate between the samples it acquires when it does not have all of the actual samples it needs to fill the waveform record. Linear interpolation computes record points between actual acquired samples by using a straight line fit. Sin(x)/x interpolation computes record points using a curve fit between the actual values acquired.
Page 71 Acquisition Acquisition mode Waveform Database mode is a three-dimensional accumulation of source waveform data over several acquisitions. In addition to amplitude and timing information, the database includes a count of the number of times a specific waveform point (time and amplitude) was acquired.
Page 72 Acquisition 3. For Average or Envelope acquisition modes, click the # of Wfms control, and then set the number of waveforms with the multipurpose knob. For WfmDB mode, click the Samples control, and then set the number of samples with the multipurpose knob. Quick tip •...
Page 73 Acquisition Selecting the horizontal mode Your instrument has three horizontal modes. Automatic is the default mode. Select the horizontal mode that works best for your test setup. To set the horizontal mode, select Horiz/Acq > Horizontal/Acquisition Setup to display the horizontal control window. Choose one of the modes described below.
Page 74 Acquisition In Manual mode you can set the Sample Rate and Record Length. Horizontal Scale is a dependent variable calculated from the sample rate and record length. The Horizontal Scale knob changes record length in manual mode. All three modes interact with sample rate, scale, and record length as shown. The horizontal line is the maximum real-time sample rate. Each staircase shows that as you increase the scale, the sample rate must decrease when either the maximum record length or the record length limit you set is reached.
Page 75 Acquisition 2. Find glitches, transients, or other random events. When you have identified an anomaly, set the trigger system up to look for it. See Capturing intermittent anomalies on page 177. Quick tips • To optimize for capturing details or rare events, select Horiz/Acq > Horizontal/Acquisition Setup > Acquisition> Fast Acq, and then select Optimize For Capturing Details or Capturing rare events.
Page 76 Acquisition 3. Click Digital Filters (DSP) Enabled to turn the enhanced bandwidth on. You must set the sample rate correctly to enable DSP. 4. To force a constant sample rate that enables DSP filters, check Force Constant Sample Rate. Note: If not already set, selecting Constant Sample rate sets the horizontal mode to constant sample rate, sets the sample rate to allow DSP, and selects a DSP bandwidth.
Page 77 Acquisition Quick tips • Right click the waveform handle to display a menu where you can select the channel bandwidth and other bandwidth enhanced settings. • The DSP enhanced bandwidth occurs at maximum sample rate. • Use the DSP enhanced bandwidth when your signals have rise times less than 50 ps. •...
Page 78 Acquisition 1. Select Horiz/Acq > Horizontal/Acquisition Setup..2. If not selected, click the Acquisition tab. Click Auto to turn on Roll mode. Note: Roll mode requires Sample, Peak Detect, or Hi Res acquisition mode. 3. To stop acquisitions in Roll mode: •...
Page 79 Acquisition 2. Select the Config tab. 3. Scroll to, and then select the bus to set up. 4. To toggle the display of the bus on or off, click the Bus button. 5. To change the default label of the bus, click Label and enter a new label using the keyboard. 6.
Page 80 Acquisition Set up a serial bus You can set serial (optional) bus parameters. 1. To set up a serial bus, select Bus Type Serial and select the type of serial bus from the drop-down list. Each bus type has its own collection of parameters that you set up. Set up other bus types as appropriate for the selected bus. See the online help for additional help setting up a bus.
Page 81 Acquisition • To use a custom serial decoder, see the online help. Set up a parallel bus You can set parallel bus parameters. To set up a parallel bus, select Bus Type Parallel. See the online help for additional help setting up a bus. To add sources to the bus, click the Add Sources Select button.
Page 82 Acquisition For each threshold you want to set, double click the channel Threshold, and enter the threshold using the keypad or multipurpose knobs on the optional Auxiliary Front Panel. When the desired thresholds have been set, click the OK button. To set all channels to the same threshold, double click Digital Threshold and use the keypad to enter a threshold.
Page 83 Acquisition 2. Select the Display tab. 3. To select the bus, scroll to display the bus, and then select the bus. 4. Select the decoding from the bus decoding list. See the online help for information on the Results Table. 5.
Page 84 Acquisition Using fastframe mode FastFrame allows you to capture many trigger events as single records in a larger record, and then view and measure each record individually. Time stamps display the absolute trigger time for a specific frame and the relative time between triggers of two specified frames.
Page 85 Acquisition 4. Select Frame Size and # of Events Frames. Then use the multipurpose knobs to set each one. Number of frames represents the number of trigger events that are captured. Frame size is the number of samples that are stored with each trigger event (or frame). The number of frames is reduced if there is insufficient memory to store all the records.
Page 86 Acquisition • If you select an Average Summary Frame, you can set Math functions (Averaging) to apply to All Frames or have it apply to Only the Summary Frame. If the summary data is of primary interest, selecting Summary Frame Only can substantially improve system throughput.
Page 87 Acquisition Frame Finder searches for and displays a different frame. 5. If the anomaly you are looking for is not in the displayed frame, push No. Frame Finder searches for another different frame. 6. If the anomaly you are looking for is in the displayed frame, push Yes. 7.
Page 88 Pinpoint triggers Pinpoint triggers The Pinpoint trigger system comes with advanced trigger types that are usable on both A and B triggers, and it can reset the trigger sequence if the B event does not occur after a specific number of events or a specific time. Pinpoint triggers support capture of events based on the most complex trigger event or sequence of trigger events.
Page 89 Pinpoint triggers Horizontal position Horizontal position defines where the trigger occurs on the waveform record. It lets you choose how much the instrument acquires before and after the trigger event. The part of the record that occurs before the trigger is the pretrigger part. The part that occurs after the trigger is the posttrigger part.
Page 90 Pinpoint triggers 3. To select one of the other trigger types, select a trigger type directly from the Trig menu. 4. Complete the trigger setup using the controls displayed for the trigger type. The controls to set up the trigger vary depending on the trigger type, instrument model, and options.
Page 91 Pinpoint triggers Trigger selections Trigger Type Trigger Conditions Edge Trigger on a rising or falling edge, as defined by the slope control. Coupling choices are DC, AC, LF Reject, HF Reject, Noise Reject, and RF. Glitch Trigger on a pulse narrower (or wider) than the specified width or ignore glitches narrower (or wider) than the specified width.
Page 92 Pinpoint triggers Trigger Type Trigger Conditions State Trigger when all of the logic inputs to the selected logic function cause the function to be True or False when the clock input changes state. On multi-instrument configurations, this trigger is not available. Setup/ Hold Trigger when a logic input changes state inside the setup and hold times relative...
Page 93 Pinpoint triggers • If TRIG'D is on, the instrument has recognized a valid trigger and is filling the posttrigger part of the waveform. • If READY is on, the instrument can accept, and is waiting for, a valid trigger to occur. Pretrigger data has been acquired. •...
Page 94 Pinpoint triggers Note: in a multi-unit system both the A and B trigger sources must be from the same unit. 3. Choose a function in the A →B Seq tab. 4. Set the trigger delay time or the number of B events. 5.
Page 95 Pinpoint triggers B trigger after delay time The A trigger arms the instrument. Posttrigger acquisition starts on the first B edge after the trigger delay time. B triggers after arm on A Arm on A Trig on B the oscilloscope waits for the A-Event to occur (once), before arming the oscilloscope to trigger on one or more B-Events.
Page 96 Pinpoint triggers • Trigger Level • Horizontal Position • Trigger Reset • Counter Measurements To use. 1. Set up the A Event and B Events from their individual tabs. 2. Select the A–>B Seq tab; then click Arm on A Trig on B. 3.
Page 97 Pinpoint triggers Overview When using the Arm-on-A Trigger-on-B sequential trigger, set the Minimum and Maximum Amplitude values for each unmapped channel used by the trigger. Use this control window to set the minimum and maximum amplitude vertical setting for the unmapped channels on an UltraSync stack master oscilloscope.
Page 98 Pinpoint triggers Quick tips • B-trigger delay time and horizontal delay time are independent functions. When you establish a trigger condition using either the A trigger alone or the A and B triggers together, you can also use horizontal delay to delay the acquisition by an additional amount. Correcting trigger position Trigger position correction corrects for differences in the data path and the trigger path to more accurately place the trigger on the displayed waveform.
Page 99 Pinpoint triggers To more accurately place the trigger on the display, check Enhanced Triggering. To more accurately place the trigger on noisy signals, also check Optimized for Noisy Signals. Select Trig on nth Event and B Event Scan in the A>B Seq tab. To display the B Event Scan Setup window, press B Event Scan >...
Page 100 Pinpoint triggers Select the method that the B Event value is incremented after the selected number of acquisitions occur: Sequential Scan increments by 1 until the End Event is reached. When the End Event is reached, the B Event value is reset to the Start Event value and the process starts over.
Page 101 Pinpoint triggers Triggering on a parallel bus Locate problems by triggering on a parallel bus. 1. Set up a parallel bus. See Setting up a bus on page 78. Select Trig > A Event (Main) Trigger Setup..2. Select the A Event tab. 3.
Page 102 Pinpoint triggers 4. Select the bus to trigger on. Note: Clocked buses will only appear in the drop down list if the clock source is set to Ch4. 5. Click an Edit button and set the pattern and format that you want to trigger on. 6.
Page 103 Pinpoint triggers 7. Set the pattern to trigger on using the keypad. 8. Analyze your waveforms. Triggering on a serial bus Locate problems by triggering on a serial bus. Set up a serial bus. See on page 78 Setting up a bus 1.
Page 104 Pinpoint triggers 2. Select the A Event tab. 3. Select the Bus Trigger Type. 4. Select the bus.
Page 105 Pinpoint triggers 5. Select the bus signal to trigger on. 6. Depending on your Trigger On choice and your bus type, make the required selections for the bus. See the online help for additional help setting up a bus. Triggering using visual triggers (visual triggering) Visual triggering allows you to create trigger conditions directly on the display screen.
Page 106 Pinpoint triggers 3. Right click in the visual trigger area and select Visual Trigger Area from the menu. Use the visual trigger menus to edit the trigger area and set conditions for the visual trigger. Refer to online help for detailed information about creating and editing visual triggers. 4.
Page 107 Pinpoint triggers 3. Select the action to take when the event occurs. Select Save, Send E-mail, or both. Use the Setup button (next to Save) to display the Save on Event Setup display screen. Use the Setup button (next to Send E-mail) to display the Send E-mail Setup display screen. See Setting up e-mail on on page 108 event...
Page 108 Pinpoint triggers 1. Select Trig > A Event (Main) Trigger Setup..2. Select the Mode tab. 3. Under E-mail on Trigger, click On, and then click setup. See Setting up e-mail on event on page 108 Setting up e-mail on event 1.
Page 109 Pinpoint triggers 6. Set the maximum message limit and e-mail size. When the maximum message limit is reached, you must click Reset to send more e-mails on event. 7. To verify that you have set up the e-mail addresses correctly, send a test-mail by clicking Send. 8.
Page 110 Pinpoint triggers Quick tips • Use MultiView Zoom and Horizontal Delay together to magnify a delayed acquisition. • Toggle Horizontal Delay on and off to quickly compare signal details at two different areas of interest, one near the trigger location and the other centered at the delay time.
Page 111 Display a waveform Display a waveform This section contains concepts and procedures for displaying a waveform. Detailed information is available in the online help. Setting the display style To set the display style select Display > Display Style, and then select one of the following styles: Vectors.
Page 112 Display a waveform • Infinite persistence continuously accumulates record points until you change one of the acquisition display settings. Use for displaying points that may occur outside the normal acquisition envelope. • Variable persistence accumulates record points for a specified time interval. Each record point decays independently according to the time interval.
Page 113 Display a waveform Setting the display format The instrument can display waveforms in two different formats. Choose the format that best suits your needs. Select Display >Display Format. • Select YT format to show a signal amplitude as it varies over time. •...
Page 114 Display a waveform • Linear interpolation computes record points between actual acquired samples by using a straight line fit. Quick tips • Sin(X)/X interpolation is the default interpolation mode. It requires fewer actual sample points than linear interpolation to accurately represent the waveform.
Page 115 Display a waveform Quick tips • Click and drag screen text to reposition it on the screen. • You can also label waveforms and buses. See Setting up a bus on page 78. Setting the graticule style To set the graticule style, select Display > Graticule Style, and then select one of the following styles: Use for quick estimate of waveform parameters.
Page 116 Display a waveform Use with automatic readouts and other screen text when display features are not needed. Use for NTSC video signals. Use for video signals other than NTSC. Solid is similar to Full, but the grid, cross hairs, and frame are drawn using solid lines. Setting the trigger level marker 1.
Page 117 Display a waveform 2. Toggle the display of the date and time on the graticule. Use the Utilities menu to set the date and time. Using the color palettes Select Display > Record View Palette or FastAcq/WfmDB Palette, and then select one of the following color schemes for the waveform and graticule: •...
Page 118 Display a waveform • Choose one of the color grading palettes in the Display > Colors control window to see different sample densities represented in different colors. • There are two color palettes, one for Record View and one for FastAcq/WfmDB. Setting reference waveform colors Select Display >...
Page 119 Display a waveform • The default color for math and reference waveforms are different for each waveform. Using MultiView zoom Use the MultiView Zoom function to magnify a waveform vertically, horizontally, or in both dimensions. Zoomed waveforms can also be aligned, locked, and automatically scrolled.
Page 120 Display a waveform • Use the Zoom Setup menu to change the graticule size of the zoomed waveform. Zooming in multiple areas When you want to view and compare multiple areas of one record at the same time, use the following procedure. 1.
Page 121 Display a waveform 6. To adjust the zoomed area vertically, select Vertical > Zoom Setup..., click a vertical field, and then use the optional multipurpose knobs or double click the readout and use the keypad to adjust the Vertical Position and Factor. Quick tips •...
Page 122 Display a waveform 3. To scroll multiple zoomed areas simultaneously, click Lock, and then select the Zoom1-4 check boxes that you want to scroll through. Locking the zoomed areas locks in their relative horizontal position. Changing the horizontal position of one locked and zoomed area changes them all.
Page 123 Display a waveform 3. Select the zoomed area that contains the waveform you want to show or hide. 4. Uncheck the channel, math, or reference waveform you want to hide. Searching and marking waveforms You can mark locations of interest in the acquired waveform. These marks help you limit your analysis to particular regions of the waveform.
Page 124 Display a waveform 3. Move (the zoom box) to the area on the waveform where you want to set (or clear) a search mark by selecting the bottom of the zoom box and dragging it to the desired location or by turning a multipurpose knob on the Auxiliary Front Panel. Push the Next ( →) or Prev (←) arrow button to jump to an existing mark.
Page 125 Display a waveform To automatically set and clear (delete) search marks Push Search or select Analyze > Search. Select the desired search type from the menu. The search menu is similar to the trigger menu. Serial bus searches are optional. DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 126 Display a waveform Set up your search from the Configure tab. To copy the trigger setup or a search setup, press Copy Settings. From the Copy Settings window, select where to copy the settings from and where to copy the settings to. Press Copy and then Close.
Page 127 Display a waveform On the screen, triangles show the location of automatic marks and triangles with a white outline show the custom (user-defined) locations. These appear on both normal and zoomed waveform views. Quickly investigate your waveform by moving from mark to mark with the Next ( →) or Prev (←) arrow button. No other adjustments are needed.
Page 128 Display a waveform To toggle between the display of search events counts or Marks time, select the Results tab and press View Count. 10. To export the Mark Table to a file, press All Marks Export. 11. To convert a mark or all marks to user marks, press Search Marks Save or Save All. 12.
Page 129 Display a waveform Search includes the following search capabilities: Search Description Edge Searches for edges (rising or falling) with a user-specified threshold level. Glitch Searches for pulses narrower (or wider) than the specified width, or ignores glitches narrower (or wider) than the specified width. Width Searches for positive or negative pulse widths that are >, <, =, or ≠...
Page 130 Display a waveform 4. Visual Trigger areas are displayed in blue. 5. Visual Search areas are displayed in green. 6. Only the active visual search area is displayed. Press the mark Next and the mark Prev buttons to move the active area to other visual search areas.
Page 131 Analyzing waveforms Analyzing waveforms Your instrument features cursors, automatic measurements, statistics, histograms, math, spectral analysis, and advanced pass/fail tests to help you to analyze waveforms. This section contains concepts and procedures for analyzing waveforms. Detailed information is available in the online help. Taking automatic measurements 1.
Page 132 Analyzing waveforms Quick tips • In roll mode, measurements are not available until after you stop the acquisition. WARNING: If there is vertical clipping, there may be a dangerous voltage on the probe tip, but the readout will indicate a low voltage.
Page 133 Analyzing waveforms Measurement Description The most positive peak voltage. Max is measured over the entire waveform or gated region. The most negative peak voltage. Min is measured over the entire waveform or gated region. Pk-Pk The absolute difference between the maximum and minimum amplitude in the entire waveform or gated region.
Page 134 Analyzing waveforms Measurement Description Cycle Area The area over the first cycle in the waveform or the first cycle in the gated region expressed in volt-seconds. The area above the common reference point is positive while the area below the common reference point is negative.
Page 135 Analyzing waveforms Measurement Description Eye Width The measurement of eye width in seconds. Eye Top The top value used in the extinction ratio measurements. Eye Base The base value used in the extinction ratio measurements. Crossing % The eye crossing point expressed as a percentage of eye height. Jitter P-P The peak-to-peak value for the edge jitter in the current horizontal units.
Page 136 Analyzing waveforms Statistics Statistics turn on automatically with measurements. Statistics characterize the stability of the measurement. 1. To change the statistics that are displayed, select Measure > Statistics, and then select Mean or All. (All includes min, max, mean, standard deviation, and population.) 2.
Page 137 Analyzing waveforms Snapshot To see a one-time view of all valid measurements, select Measure > Snapshot. Note: If the setup for a measurement is invalid, the results of that measurement is displayed as 3 question marks. To select between taking a snapshot of general measurements or communications measurements, select General or Comm. Annotate measurements 1.
Page 138 Analyzing waveforms 2. To select the amount of measurement annotation detail, select Measure > Annotation > Standard or Detailed. Reference levels Reference levels determine how time-related measurements are taken. 1. Select Measure > Reference Levels..2. Adjust the measurement reference levels to different relative or absolute values. •...
Page 139 Analyzing waveforms Quick tips • To ensure accurate noise values, be sure to go to the Reference Levels Setup menu and set the signal type to Eye when measuring an Eye signal. Taking cursor measurements Use cursors to take manual measurements on acquired data. 1.
Page 140 Analyzing waveforms 5. Select Cursors > Cursor Position..., and then use the multipurpose knobs to adjust the cursor position. 6. Read cursor measurement results in the display. Quick tips • Use the Cursor Track Mode to set the cursors to move in tandem. Use the Cursor Independent mode to move the cursors separately. •...
Page 141 Analyzing waveforms 3. View the histogram at the top (for horizontal histograms) or the left edge (for vertical histograms) of the graticule. 4. To make adjustments to the histogram scale or the size and location of the histogram box, select Measure > Waveform Histograms, and then use the Histogram Setup control window.
Page 142 Analyzing waveforms • Use vertical histograms to measure signal noise and horizontal histograms to measure signal jitter. • Use the click and drag procedure to activate the shortcut menu to turn the histogram display off. Using math waveforms Create math waveforms to support the analysis of your channel and reference waveforms. By combining and transforming source waveforms and other data into math waveforms, you can derive the data view that your application requires.
Page 143 Analyzing waveforms 3. Build your advanced math waveform expression using sources, operators, constants, measurements, variables, and functions. 4. When you have defined the expression to your satisfaction, click Apply. 5. To add your own filter, click the Filter tab. Click Load. 6.
Page 144 Analyzing waveforms Quick tips • Double clicking on a math expression opens the Math Equation Editor. • Math definitions are not implemented if the sources are not valid. • Math waveforms are created from analog channel, reference, math source waveforms and from measurements. •...
Page 145 Analyzing waveforms Note: Resolution BW and Frequency Span are only adjustable in Manual Horizontal Mode. Use the following procedure to build an advanced spectral math expression. 1. Select Math > Advanced Spectral..2. Select the math waveform that you want to define. 3.
Page 146 Analyzing waveforms 6. View time-domain and frequency-domain waveforms simultaneously. Use Gating to select only a part of the time-domain waveform for spectral analysis. See on page 135 Gating Quick tips • Sources for spectral math waveforms must be channel or other math waveforms. •...
Page 147 (.txt file). Once selected, the file name and path will appear in the Pattern File field. The default location for Error Detector pattern files is C:\Users\Public\Tektronix\TekScope\ErrorDetector. 4. Select the signal Source and Data Rate from the drop-down lists.
Page 148 Error Detector. These AWG setup files are located in Windows in the directory C:\Users\Public\Tektronix\TekScope\ErrorDetector\AWG. Alternatively, you can verify operation by disconnecting and reconnecting the signal. There will be massive errors when the signal is disconnected, but after the signal is reconnected the Error Detector will clear the error counts and rates and resume testing.
Page 149 Analyzing waveforms To verify DUT bit error rate performance, insert the DUT between the Signal Generator and the Error Detector as shown. With the DUT inserted between the Signal Generator and the Error Detector, put your DUT into loop-back and start outputting the pattern from the Signal Generator.
Page 150 Analyzing waveforms Using mask testing Serial Communications Mask Testing (Option MTM or MTH) allows you to compare your signal to a predefined template or mask. For the signal to pass the test, it must fall outside the segments defined by the mask. Generally, standards committees such as ANSI define the masks.
Page 151 Analyzing waveforms Click Lock Mask to Wfm On to track mask changes in the horizontal or vertical settings. Toggle Hit Count On to highlight violations during a mask test. Click Autoset to automatically align the waveform with the mask based on the characteristics of the input signal. 10.
Page 152 Analyzing waveforms 12. Select the Pass/Fail Setup tab, and then set up the pass/fail parameters. (When acquisition mode is Waveform Database, the # of Wfms label becomes Samples.) 13. Select your Pass/Fail Test Notifications. 14. Select the polarity of the waveform you want to test. 15.
Page 153 Analyzing waveforms Using limit testing Optional limit testing allows you to compare an active signal with a template waveform. Build your template waveform from a known good signal and use it to compare to an active signal to perform pass/fail testing. Select Mask >...
Page 154 Analyzing waveforms Click Lock Template to Waveform On to lock the vertical scale or position of the template to that of the source waveform. Click Highlight Hits On to show points that fall outside the template in a different color. 10.
Page 155 MyScope MyScope MyScope allows you to create custom control windows that include only the controls that you use regularly. Instead of switching between several control windows, put the controls you use into a custom control window. This section contains procedures for creating and using MyScope control windows. Detailed information is available in the online help. Creating a new MyScope control window Select MyScope >...
Page 156 MyScope Clear the check boxes to remove any components that you do not want included in the control. Click and drag the control to your MyScope control window. The control will snap to the nearest grid location when you release the mouse.
Page 157 MyScope Click New Tab to add a tab to your MyScope control window. You can have up to six tabs. To rename a tab do one of the following: • Click Rename Tab. • Double-click the tab, and then type the new name. Click User Pref...
Page 158 MyScope Quick tips • To reconfigure a control, click and drag it back to the preview window. Then select or clear the check boxes to include or remove components in the control. • To change the tab order, click and drag a tab to a new location. •...
Page 159 MyScope To display the active MyScope control window, do the following: 1. Select MyScope > Current... or click MyScope in the toolbar mode. (Your MyScope control window remains active even when it is not displayed.) To edit a MyScope control window do the following: 1.
Page 160 MyScope • Some controls function differently in a MyScope control window than they do in the standard control window. For details, see the online help. • You can copy MyScope control windows (.tcw files) to other MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/ DPO5000B Series instruments.
Page 161 Saving and recalling information Saving and recalling information This section contains procedures for saving and recalling screen captures and setups, saving measurements, using the clipboard, and printing on your instrument. Detailed information is available in the online help. Saving screen captures 1.
Page 162 Saving and recalling information Quick tip • To quickly save multiple screen captures, select Set Front Panel Print Button to Save, and then click Save. You can now save a screen capture by pushing the Print button on the Auxiliary Front Panel. Saving waveforms 1.
Page 163 Saving and recalling information 4. Select the Source. 5. You can either save the waveform as a reference waveform in the instrument memory or as a .wfm file in a Windows directory. To save the waveform as a reference, select Ref 1–4. To save as a .wfm file, select the location where you want to save the waveform. 6.
Page 164 Saving and recalling information 2. Click Waveform. 3. Select the Destination of the waveform you are recalling. 4. Select the waveform to recall. 5. Click Recall. Clicking Recall turns on the reference waveform and activates the Reference Waveform control window. 6.
Page 165 Saving and recalling information 2. Click Setup. 3. Select the location where you want to save the setup. Either save the setup to the instrument memory in one of the ten setup storage locations or as a .set file in a Windows directory. 4.
Page 166 Saving and recalling information 2. Click Setup. 3. Select the setup you want to recall. Recall a setup file from one of the ten locations in the instrument memory or from a Windows directory. 4. To retain your current deskew settings, click Don't recall deskew values. 5.
Page 167 Saving and recalling information 2. Click Options... to specify Displayed Measurements, Measurement Snapshot, or Measurement Format; otherwise, skip to step3. 3. Select the location to save the measurement. 4. Type in a name for the measurement, and then select a file type. 5.
Page 168 Saving and recalling information 2. Click User Mask. 3. Select the location to save the mask. 4. Type in a name for the mask, and then select a file type. 5. Click Save. Saving histogram data 1. Select File > Save or Save As > Histogram Data.
Page 169 Saving and recalling information 2. Select Histogram. Depending on previous selections, you may need to select More > Histogram Data to display the Histogram selection. 3. Select the location to save the histogram. 4. Type in a name for the histogram, and then select a file type. 5.
Page 170 Saving and recalling information 2. Click Timestamp. Depending on previous selections, you may need to select More > Timestamp Table to display the Timestamp selection. 3. Click Options... to specify the Source or FastFrame Data Range; otherwise, skip to step4. 4.
Page 171 Saving and recalling information Copying your results to the clipboard Use the following procedure to set the output content and format for images, waveforms, or measurements to be copied to the Microsoft clipboard. 1. Select Edit > Copy Setup..2. Click the Images, Waveforms, or Measurements tab, and then select the desired options. To copy images, waveforms, or measurements, use the following procedure: 1.
Page 172 Saving and recalling information Printing a hard copy 1. To print a hard copy, push the print button or select File > Print. If necessary, make changes to the page orientation in the Page Setup dialog box. Your Print and Page Setup dialog boxes will depend on the printer you are using. 2.
Page 173 Saving and recalling information DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 174 Each application is available for ten free trials on your instrument. These applications provide application-specific measurement solutions. Some examples are described below. Additional packages may be available. Some applications may not be available on your instrument. Contact your Tektronix representative or visit our Web site at www.tektronix.com for more information. •...
Page 175 Run application software • Use SATA-DHB SATA TekExpress SATA SW Bundle to automate SATA testing (TSG and RSG for Hosts or Devices). • Use SATA-RSG SATA RSG/RMT Receiver Tests for TekExpress for automated SATA receiver testing. • Use SATA-R-UP to upgrade TEKEXP for SATA RSG/RMT Receiver Tests for TekExpress. •...
Page 176 Run application software Follow the instructions provided with the application software to install it. To run the software, select Analyze and then select the application.
Page 177 Application examples Application examples This section contains examples of using your instrument in common troubleshooting tasks and extending the use of your instrument. Capturing intermittent anomalies One of the most difficult tasks that design engineers face is tracking down the cause of intermittent failures. If you know what type of anomaly you are looking for, it is easy to configure the oscilloscope advanced triggering capability to isolate it.
Page 178 Application examples Select Horiz/Acq > Fast Acquisitions, or push FastAcq on the Auxiliary Front Panel. Find glitches, transients, or other random anomalies that are present in the signal. In this example, FastAcq revealed an ≈300 ns positive glitch after only a few seconds. To trigger on the glitch that you identified in step5 , select Glitch Setup..
Page 179 Application examples 11. To trigger on a single glitch, select Horiz/Acq > Run/Stop... and then click Single Sequence, or push Single on the Auxiliary Front Panel. Using the extended desktop and OpenChoice architecture for efficient documentation Engineers often need to document their lab work for future reference. Instead of saving screen shots and waveform data to a CD or USB memory device, and then generating a report later, try using the OpenChoice architecture to document your work in real time.
Page 180 Application examples 4. Click TekScope to restore the instrument application. 5. Select Edit > Select for Copy > Full Screen (bitmap). 6. Press Ctrl+C. 7. Click in the Word document wherever you want to place the screen shot, and then press Ctrl+V. Quick tips •...
Page 181 Application examples 2. Select a bus type. 3. If you selected the Serial Bus Type, select the type of serial bus. 4. Specify the components. 5. Select Trig > Bus Setup. 6. Select the bus you set up. 7. Select Trigger On to select the desired trigger on feature. DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 182 Application examples 8. Depending on your Trigger On selection, you may need to make additional selections.
Page 183 2000 hours of operation or once a year if the instrument is used infrequently. Adjustment Adjustment can be performed only by a Tektronix Service Center. See Contacting Tektronix, following the title page in this manual, for information on contacting Tektronix Service Support.
Page 184 Tektronix as an email attachment. If you contact Tektronix for help in diagnosing TekScope Errors, you may be asked to run this utility and supply Tektronix with the .zip file.
Page 185 Appendix A, Maintenance Running the utility Click the utility link. If TekScope is running when the utility is invoked, the utility will warn the user that TekScope must be stopped. This is necessary to allow the utility to access some of the files. The utility will automatically stop TekScope after it queries the serial number of the instrument. Click Yes to allow the utility to stop TekScope and collect files for the report.
Page 186 2. However, if TekScope was not running when the utility was invoked, the name of the .zip report file will not contain the serial number. For example: TekScope_Recovery_Report_DPO77002SX.zip Data contained in the report When the utility is finished running, if these files exist on the instrument, the report will contain copies of these specific files: C:\Windows\Sysnative\winevt\logs\Application.evtx C:\programdata\tektronix\ISD.XML C:\programdata\Tektronix\TekScope\Calibration\console.log C:\programdata\Tektronix\TekScope\Calibration\console.logOld C:\programdata\Tektronix\TekScope\Calibration\calSPCConst.dat C:\programdata\Tektronix\TekScope\Calibration\caldiag.log C:\programdata\Tektronix\TekScope\Calibration\caldiag.logOld C:\programdata\Tektronix\TekScope\Calibration\error.log...
Page 187 • Instrument modification number, if applicable If you order a part that has been replaced with a different or improved part, your local Tektronix field office or representative will contact you concerning any change in part number. DPO70000SX Series Oscilloscopes Quick Start User Manual...
Page 188 If you purchased the application with your instrument, your Tektronix License Key will enable you to use the application. If you are upgrading, follow the instructions on How to Install your new Tektronix License Key in the Readme.txt file to enable the...
Page 189 Index Connectors (continued) rear-panel Accessories rear-panell Acquisition Copying input channels and digitizers Coupling sampling trigger Acquisition modes Cross Hair graticule style changing Cursor measurements Action on event setup adjustment adjustment interval Delayed trigger 89, Amplitude measurements Deskew Tool Analog input Display map front-panel connector Display properties...
Page 190 Mark Mask Gate width and resolution bandwidth autoset Glitch trigger margin tolerance defined Mask testing Glitches Math capturing 70, 74, editor triggering on maximum input voltage Grid graticule style Measurements accuracy cursor customizing defined Help Menus Hi Res acquisition mode MIPI CSI-2 Histogram measurements MIPI DSI-1...
Page 191 Power button (continued) Software (continued) yellow optional Power cord input version Power supply requirements Software installation Powering off Spectral math expression Powering on advanced multi-instrument power on Pretrigger 88, Standard accessories Probe Start an acquisition calibration 49, State trigger compensation defined deskew Status message...
Page 192 User preferences Variable persistence Vertical position and autoset vertical setup control window M Chx tab VGA port rear-panel Video port Visual Trigger Waveform analyzing search and mark user marks Waveform database acquisition mode Width trigger defined Window trigger defined Windows shutdown X-Y display format X-Y-Z display format Y-T display format...
