3. Preparation before use
Please ensuring that the machine is placed appropriately, removingthe machine's fixed sheet
metal, and confirming that the power-on andstartup actions are normal and the machine
moves normally.
4.Confirmation of machine placement environment
Confirm the installation location
1.There are no problems with the floor of the installation site and the levelness and
strength of the installation table.
2.The installation place is not under direct sunlight, uneven ground, vibration, direct air
blowing from air-conditioning or other equipment, or open flame.
3.No chemicals are placed around the installation site.
4.There are no large equipment producing noise nearby.
5.The equipment installation environment ensures that the temperature is 20℃~25℃ and
the change is less than ±10℃/h.
5.
Machine fixed sheet metal disassembly
The two fixed sheet metals that fix the platform and the carriage need to removed before
printer can be energized. As shown below:
Confirm that the boot operation is normal
6.
1.Confirm that the machine has a normal appearance and is placed stably. Check whether
the power supply voltage mark of the machine is 220V or 110V. It should only be used if it
matches the local supply voltage.
2.Connect the machine to the power supply, turn on the main power switch at the rear of
the machine, and the machine begins initialization.
The specific action process is as follows:
1.The cap station and the wiper drop simultaneously →
2.The platform moves forward →
3.The platform moves to the rear limit →
4.The carriage moves left →
5.The carriage moves right to the limit →
6.The carriage moves left to the top of the cap station →
7.The head of the cap station is closed
Add ink to new machine
7.
1.As shown in the picture below, add the corresponding ink according to the color prompts.
2.When adding ink, in order to prevent the ink from leaking and contaminating the shell
sheet metal. Please wrap the bottle mouth with paper towels.
3.After adding ink, pay attention to surrounding hygiene.
Open the ink filling port cover
Confirm the ink cartridge at the back
of the machine
03-04
