Tellabs® ONT203W Installation and Turnup Guide

Need help?

Do you have a question about the FlexSym ONT203W and is the answer not in the manual?

Questions and answers

Summary of Contents for Tellabs FlexSym ONT203W

Page 2 Information in this publication is subject to change without notice. Trademarks The following trademarks and service marks are owned by Tellabs Operations, Inc. or its affiliates in the United States and/or other countries: TELLABS ®...
Page 3 The Tellabs ® ONT203W is part of the Tellabs 200 series of ONTs for 10 Gigabit Passive Optical Networks (XGS-PON). When connected to a Tellabs 1100-series optical line terminal (1150, 1134/OLT6, FlexSym OLT1, FlexSym OLT2, FlexSym Bolt, and the FlexSym OLT-mini Plus), the ONT203W, provides high-performance enterprise features, combined with cost, energy, and space savings, all within the Tellabs ®...
Page 4 · Specifications · The Tellabs® ONT203W Optical Network Terminal (ONT) is part of the Tellabs 200 series of optical network terminals (ONT) for 10 Gigabit Passive Optical Networks (XGS-PON). Page 4 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 5 · It is designed to be installed inside a standard single gang wall outlet box. The FlexSym ONT203W provides flexible and symmetrical extended Ethernet connectivity over a 10gigabit passive optical network at multi-rate Ethernet speeds of 1G, and 2.5G. Page 5 of 28...
Page 6 Tellabs® ONT203W Installation and Turnup Guide The FlexSym ONT203W provides Power over Ethernet (PoE) for the IEEE 802.3af and PoE+ IEEE 802.3at (Class-4 negotiations) standards as well as support for Cisco UPoE. PoE of up to 60W is supported on 3 high power ports (GE1, GE2, and MG3).
Page 7 MTU Maximum Transmission Unit (MTU) 9216 bytes GE LAN Ethernet Interface - 2x RJ-45 connectors · Standard Compliance - IEEE 802.3, 802.3u, 802.3ab · Link - · Half-duplex and full-duplex operations 10/100/1000Mbps Page 7 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 8 802.1p marking based on DSCP Multicast - IGMP v2, v3, IGMP snooping Security Features Tellabs has implemented unique advanced security features to protect enterprise networks. The ONT203W supports security across the optical distribution network and end-to-end over the OLAN system; such as encryption of traffic on the PON using the Advanced Encryption Standard AES-128 and Access Control Lists (ACL) at Layer 2 through 4 levels.
Page 9 Tellabs® ONT203W Installation and Turnup Guide CONNECTORS The FlexSym ONT203W module has 5 connectors: DC 54V – DC power input. This is a special power connector that mates with a Phoenix-type pluggable · terminal connector (5.08 mm pitch 2P), allowing remote bulk DC power to be used. (Remote DC power is limited to 100 VA by code.)
Page 10 • Link (Up) GE1-GE2, Green Blink • PoE (No PD Detected) • Data (Data detected) • Link (Up) Amber • PoE (Powering PD) • Data (No Data Detected) Page 10 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 11 Tellabs® ONT203W Installation and Turnup Guide Indications Comments • Link (Up) Amber Blink • PoE (Powering PD) • Data (Data Detected) Dark The Ethernet Port is disabled, or link is not detected Page 11 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 12 Reset – This momentary pushbutton switch resets the ONT. The Reset switch pushbutton is accessible · through a small hole on the front of the ONT. SPECIFICATIONS The FlexSym ONT203W specifications are listed in the following table: DC Input Power DC 54V connector 54 VDC @ 1.5A (71W) Physical ·...
Page 14 Warning! Do not open the enclosure unless directed to do so by Tellabs technical support. Doing so is dangerous and voids the warranty. Check that the DC power supply polarity is correct. The system will not be damaged by reversed polarity but ·...
Page 16 Digital multimeter with test leads (a DMM with only basic functions will do) · Optical Power Meter · Fiber Optic Inspection Microscope · Multi-purpose fiber optic cleaning tool with bulkhead adapter · Page 16 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 17 DC power termination with back box IN-WALL ONT POWER MODULE, 10CT Note: The ONT203W faceplate cover can be made to order in a color of your choice (in bulk). Please contact your Tellabs sales representative for more ordering details. Previous ...
Page 18 Note: When the ONT is first connected to the PON, the PON will download and install software on the OLT. This process can take up to 20 minutes to complete. If multiple ONTs need to be installed at the site, the next physical install can proceed. Page 18 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 19 Power Module ONT Module Faceplate cover 2. If any damage is found, contact the Tellabs® Warranty/Repair and Return Center immediately. 3. Place all components on a work bench or table. 4. Find a suitable location for the ONT203W. 5. If installing the ONT in a drywall, use a drywall saw and cut a hole to accommodate an interior wall outlet, using the low voltage mounting bracket, illustrated in Figure B.
Page 20 Power Module, depicted below. Ensure that the 4 plastic clips on the ONT Module are aligned with the power module for a tight fit. Page 20 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 21 16. Strip the insulation from the copper wire and then insert the bare copper wire into the 2-pin male input connector on the ONT module. 17. Use a small screwdriver to tighten the screws to grip the copper wire as shown below. Page 21 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 22 ONT Module that identifies the ONT’s Serial Number. 24. Slide the top of the faceplate cover so that the plastic locks on the top and the bottom also snaps into place. Page 22 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 23 Turnup and Initialization ADDING AN ONT TO PANORAMA An ONT must be added to the EMS from the EMS GUI. This can be done in one of several ways: Page 23 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 24 User Label: You can give a name or label to the ONT that can be used to indicate its location or how it is being · used. The Serial Number and PON AID are automatically populated. Page 24 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 25 The intent is that you would configure the ONT prior to installation and upon installation the unit would be automatically accepted and go into service without any further manual intervention. From the Panorama GUI, select the correct PON and then right click and select Add ONT. Page 25 of 28 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 26 Contact Us TELLABS TECHNICAL ASSISTANCE CENTER Tellabs TAC is available 24x7x365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
Page 27 TELLABS WARRANTY & REPAIR CENTER The Tellabs Repair Center is staffed Monday-Friday 6:00 AM-4:00 PM CT, excluding Tellabs company holidays. If you have a technical or hardware emergency after hours, please contact the Tellabs TAC.
