Summary of Contents for Tellabs FlexSym ONT202

Page 2: Tellabs® Information
Information in this publication is subject to change without notice. Trademarks The following trademarks and service marks are owned by Tellabs Operations, Inc. or its affiliates in the United States and/or other countries: TELLABS ®...
Page 3: Table Of Contents
The Tellabs ® FlexSym ONT202 (ONT202) is part of the Tellabs 200 series of ONTs for 10 Gigabit Symmetrical Passive Optical Networks (XGS-PON). When connected to a Tellabs 1100-series optical line terminal (1150/1150E, 1134, FlexSym OLT1, FlexSym OLT2, FlexSym OLT6, FlexSym BOLT, FlexSym OLT-mini Plus), the ONT202 provides high- performance enterprise features, combined with cost, energy, and space savings, all within the Tellabs exclusive high- security All Secure™...
Page 4: Precautions
: Do not bend the fiber optic cable to a diameter smaller than 7.5cm/3 inches. Doing so may damage the fiber or prevent the signal from passing through properly. Page 4 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 5 Warning! Do not open the enclosure unless directed to do so by Tellabs technical support. Doing so is dangerous and voids the warranty. Check that the DC power supply polarity is correct. The system will not be damaged by reversed polarity but ·...
Page 6: Description
DESCRIPTION The Tellabs FlexSym ® ONT202 (ONT202) is part of the Tellabs 200 series of optical network terminals (ONT) for 10 Gigabit Symmetrical Passive Optical Networks (XGS-PON). The ONT202 offers two multi-rate Ethernet ports as follows: MG1 (10G) - Muti-gig service port supporting 10G/5G/2.5G/1G/100M speeds.
Page 8 60W of PoE when powered by the 75W AC wall and up to 90W of PoE when powered remotely. The ONT202 can be deployed with the Tellabs OLT1150/OLT1150E, OLT1134AC, FlexSym OLT1, FlexSym OLT2, FlexSym OLT6, FlexSym BOLT, and the FlexSym OLT-mini Plus optical line terminals.
Page 9 Tellabs® ONT202 Installation and Turnup Guide FEATURES The FlexSym ONT202 provides the following features: Passive Optical Network ITU-T G.984.1 Amd 1 Class B+ · APD Receiver / DFB Transmitter · 4-9dBm launch power, -28 dBm sensitivity and -9 dBm overload ·...
Page 10 Management Information Base (MIB) manipulation over OMCI by Create, Delete, Set, Get, and Get Next · commands Remote image download over OMCI as well as activation and rebooting · Page 10 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 11 Tellabs® ONT202 Installation and Turnup Guide Security Tellabs has implemented unique advanced security features to protect enterprise networks. The ONT202 supports security across the optical distribution network and end-to-end over the OLAN system, such as encryption of traffic on the PON using the Advanced Encryption Standard AES-128 and Access Control Lists (ACL) at Layer 2 through 4 levels.
Page 12 • Data (No data detected) When the ONT202 MG1-MG2 LED indication is green blink: • Link (Up) Green Blink • PoE (No PD Detected) • Data (Data detected) Amber When the ONT202 MG1-MG2 LED indication is amber: Page 12 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 13 • Link (Up) Amber Blink • PoE (Powering PD) • Data (Data Detected) When the ONT202 MG1-MG2 LED indication is dark, the Ethernet Port is disabled, or link is not Dark detected Page 13 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 14 Reset – This momentary pushbutton switch resets the ONT · The Reset switch pushbutton is accessible through a small hole on the back of the unit. SPECIFICATIONS The FlexSym ONT202 specifications are listed in the following table: FlexSym ONT202 Specifications DC Input Power DC 54V connector 52 VDC to 57 VDC @ 2.78A max (150 W)
Page 15: Preparation
Environmental Requirements · Power Requirements · Tools and Supplies · Tools · Supplies · Unpacking and Inspection · Inside the Box · Outside the Box · Accessories · Page 15 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 16 The ONT can be installed in most any location including desktop, indoor surface and electrical gang box mount, outdoor NEMA enclosures, ceiling plenums and racks in communication closets. The ONT design, optional mounting hardware and accessories provide installation options to fit most needs. Page 16 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 17 Power Requirements The FlexSym ONT202 requires 52-57 VDC at up to a maximum of 2.78 amps (at full PoE load). DC power can be obtained from one of the two optional AC adapters at the installation location, or from a central remote bulk 54-volt DC power supply.
Page 18 · UNPACKING AND INSPECTION The Tellabs ONT and related accessories may arrive in a single shipping container, or in multiple containers. When unpacking the boxes, check each item against the installation work order and for obvious shipping damage. If a shortage or damage is found, contact the Tellabs Warranty/Repair and Return Center immediately.
Page 19 Tellabs® ONT202 Installation and Turnup Guide Inside the Box The FlexSym ONT202 box contains: FlexSym ONT202 – desktop Optical Network Terminal unit (no power supply) · Phoenix-type pluggable terminal connector (5.08 mm pitch 2P) · Universal ONT DIN Rail Mounting Bracket (includes two screws) ·...
Page 20: Installation
Plenum Bracket · Outdoor NEMA Enclosure · Connecting to Power · Local AC Adapter · Remote Bulk DC Power Supply · Connecting the Optical Fiber · Cable Management · Page 20 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 21 Verifying the Installation · INSTALLATION OVERVIEW This page provides guidance on installing the Tellabs FlexSym ONT202 and any required accessories. The procedure involves the following steps: 1. Physically mount the ONT and accessories 2. Connect the ONT to DC power 3.
Page 22 Wall Mounting Bracket The FlexSym ONT202 can be attached to a wall or other indoor surface using an optional Wall Mounting Bracket. Before mounting the ONT, consider the location and orientation appropriate for access and ease of use. Consider the power cable, optical fiber and ethernet cables that will need to be attached to the ONT.
Page 23 2. Press the ONT onto the bracket to engage the keyholes and compress the bracket spring clips. 3. Slide the ONT away from the bracket spring clips until they pop up and lock the ONT into place. Page 23 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 24 Use a screwdriver to start the screws into the threads. See the illustration below. 7. Ensure the cables are clear of any pinch points and tighten the screws with a screwdriver to secure the ONT. Page 24 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 25 2. Attach the DIN mounting bracket to the ONT. a. Align the holes in the DIN rail mounting bracket with the mounting holes on the bottom of the ONT202. Page 25 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 26 DIN rail. b. Lightly Press down and in on the ONT until the bracket locks into position. The illustration below shows the most common DIN rail mounting orientation: Page 26 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 27 A Recommended OEM DIN Rail Mount is from the Panduit Catalog. The rackmount is a standard, 19-inch, with a DIN rail that can hold up to 11 vertically stacked ONTs. The ONTs mount to the DIN rail using the Tellabs Universal ONT DIN Rail Mounting Bracket.
Page 29 1. Locate a suitable position, within reach of a wall outlet, to install the plenum bracket. 2. Drill two level holes, to accommodate the 2 - 1/4-inch screws, into the wall, as shown in the example. Page 29 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 30 3. Insert the 2 - 1/4-inch screws into the drilled holes and tighten the screws through the holes in the bracket and into the wall, as illustrated below: Page 30 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 31 The ONT202 supports industrial temperatures and humidity and can be mounted in an outdoor rated NEMA enclosure. The procedure for this type of installation will vary depending upon the type of enclosure and application. Page 31 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 32 Tellabs® ONT202 Installation and Turnup Guide CONNECTING TO POWER DC power for the Tellabs FlexSym 202 can be provided locally by one of two optional AC adapters (150-W and 85-W power bricks) or by a remote bulk DC power supply.
Page 33 The ONT Power LED Indicator will come on in about five seconds and be steady green. (See the LED Behavior Table in the Description page of this document.) Page 33 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 34 Warning: Do not bend the fiber optic cable to a diameter smaller than 7.5cm/3 inches. Doing so may damage the fiber or prevent the signal from passing through properly. VERIFYING THE INSTALLATION Once the installation, software download, and bootup is complete, use the following procedure to verify ONT status: Page 34 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 35: Adding To Panorama Pon Manager
Bulk configuration via Excel Files · Add Via Unexpected ONT Menu The unexpected ONT menu can be found by right clicking at the OLT, OIU, or PON level and Selecting Unexpected ONT. Page 35 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 36 User Label: You can give a name or label to the ONT that can be used to indicate its location or how it is being · used. The Serial Number and PON AID are automatically populated. Page 36 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 37 The intent is that you would configure the ONT prior to installation and upon installation the unit would be automatically accepted and go into service without any further manual intervention. From the Panorama GUI, select the correct PON and then right click and select Add ONT. Page 37 of 40 © 2024 Tellabs Enterprise, Inc. All rights reserved.
Page 38: Contact Us
Previous | Next Contact Us TELLABS WARRANTY & REPAIR CENTER The Tellabs Repair Center is staffed Monday-Friday 6:00 AM-4:00 PM CT, excluding Tellabs company holidays. If you have a technical or hardware emergency after hours, please contact the Tellabs TAC. Contacting Repair Contact the Repair Center To: ·...
Page 39 France: 01 85 64 04 05, option 6 TELLABS TECHNICAL ASSISTANCE CENTER Tellabs TAC is available 24x7x365. Our team is comprised of Support Engineers with years of telecommunications and networking experience, holding a variety of networking certifications in addition to the Tellabs Certification for the product(s) they support.
