Draper Expert BBK3A Instructions For Use

1. Product Introduction
Read this leaflet in full before using this product and retain it for future use. Please visit drapertools.com/manuals for the latest version.
(B)
(H)
1.1 Unpacking
– Fig. 1
Remove all packaging. Check that the product is in perfect condition and no visible damage to any of the parts.
(A) Top-up bottle.
(B) Top-up bottle (with adjustable nozzle).
(C) Collection pot.
(D) Air line inlet.
2. Specification
Stock No.
Part No.
Air supply
Air inlet size
Container capacity
Helpline: +44 (0) 23 8049 4344
Draper Tools Limited, Hursley Road, Chandler's Ford, Eastleigh, Hampshire, SO53 1YF, UK
Delta International BV, Oude Graaf 8, 6002 NL, Weert, Netherlands
UNIVERSAL BRAKE
BLEEDING KIT
71205 – INSTRUCTIONS FOR USE
71205
BBK3A
70 – 120psi (4.8 – 8.3bar)
¼" BSP
0.75L
Sales Desk: +44 (0) 23 8049 4333
(A)
(E) Trigger assembly.
(F) Brake bleed nipple connector.
(G) Bleed hose.
(H) Hanging magnets.
3. General Safety Instructions
• A competent and qualified technician with a good mechanical background
only should attempt work on a vehicle's braking system.
• Before use, jack the vehicle up on a level and secure surface – preferably
concrete. Ensure the vehicle is securely supported with suitable axle stands
and the wheels remaining on the ground are chocked.
• Leave the vehicle in neutral (automatics should be set into the 'park' position).
• Always work in a well ventilated area and away from children and pets.
General Enquiries: +44 (0) 23 8026 6355
(G)
(F)
Website: drapertools.com Email: sales@drapertools.com
EN
Original Instructions
Version 2 - July 2024
(E)
(D)
(C)
Fig. 1
0724
