FDRD152PL
Product Features:
Counter depth
Stainless steel look
Bottom freezer drawers
Clear slide-out freezer trays
Digital controls
Adjustable glass shelves
Door storage
Crisper drawer
Interior LED refrigerator light
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799
Sized at just under 27" deep for an easy fit in space-challenged kitchens, with a 23.63" depth
from the rear to doors
Doors offer the look of stainless steel complete with a horizontal grain, but the easier
cleanability of a fingerprint-resistant steel finish
Two slide-out freezer drawers help you maximize storage for easier accessibility
Each freezer drawer includes a sliding top tray that fully extends with the drawer for added
storage convenience
Interior control panel with easy touch settings to adjust the refrigerator and freezer
compartments as needed
Spill-proof safety glass for durable and easy-to-clean storage that can be rearranged as
needed
Each door includes three removable racks
Large clear crisper offers plenty of space to store fruits and vegetables
Automatically illuminates when you open the door
70.63" x 27.5" x 26.88" (H x W x D)
Counter depth French door refrigerator with two bottom
freezer drawers in a fingerprint-resistant stainless steel
look
Highlights:
Uniquely sized at less than 27" deep for an easy fit in
smaller kitchens
Digital temperature controls for both the refrigerator and
freezer section
Two bottom freezer drawers allows you to maximize your
storage
info@summitappliance.com
www.summitappliance.com
