  • Page 1 Products Solutions Services SD02484D/06/EN/03.22-00 71620267 2023-07-28 Valid as of version 01.00.zz (Device firmware) Special Documentation Proline t-mass 500 Functional safety manual HART...

  • Page 3: Table Of Contents

    Proline t-mass 500 HART Table of contents Table of contents Manufacturer's declaration ..4 Repair and error handling ..43 Safety-related characteristic values ..5 Maintenance ..... . . 43 Repair .

  • Page 4: Manufacturer's Declaration

    Manufacturer' s declaration Proline t-mass 500 HART Manufacturer's declaration A0046114-EN Endress+Hauser...

  • Page 5: Safety-Related Characteristic Values

    Proline t-mass 500 HART Manufacturer' s declaration Safety-related characteristic values General Device designation and permitted 6F5B (t-mass F 500) versions 6I5B (t-mass I 500) Order code for "Output; input 1": Option BA "4-20mA HART" Order code for "Output; input 2": All options Order code for "Output;...
  • Page 6 Manufacturer' s declaration Proline t-mass 500 HART Hardware safety integrity Single-channel service  SIL 2 capable  SIL 3 capable (HFT = 0) Multi-channel service  SIL 2 capable  SIL 3 capable (HFT ≥ 1) FMEDA Safety function(s) Min., Max., Range λ...

  • Page 7: Certificate

    Proline t-mass 500 HART Certificate Certificate Certificate can be accessed at www.endress.com: Downloads Approvals Type: Functional safety (SIL) Product root: e.g. 5H3B Press the "Search" button About this document Document function This document is part of the Operating Instructions and serves as a reference for application- specific parameters and notes.
  • Page 8 About this document Proline t-mass 500 HART 3.3.2 Symbols for certain types of Information Symbol Meaning Permitted Procedures, processes or actions that are permitted. Preferred Procedures, processes or actions that are preferred. Forbidden Procedures, processes or actions that are forbidden.

  • Page 9: Supplementary Device Documentation

    For an overview of the scope of the associated Technical Documentation, refer to the following: • Device Viewer (www.endress.com/deviceviewer): Enter the serial number from the nameplate • Endress+Hauser Operations app: Enter serial number from nameplate or scan matrix code on nameplate. 3.4.1 Standard documentation...

  • Page 10: Design

    Design Proline t-mass 500 HART Contents Documentation code NEPSI Ex i XA01502D NEPSI Ex nA XA01503D Functional safety manual Contents Documentation code Proline t-mass 500 SD02484D Special documentation Installation Instructions Contents Comment Installation instructions for spare part sets and Overview of accessories available for order: see the Operating...
  • Page 11 Proline t-mass 500 HART Design Feature Designation Option selected Output; input 3 Output; input 4 Display; operation Integrated ISEM electronics Transmitter housing Sensor connection housing Cable, sensor connection Electrical connection Sensor version; sensor; measuring tube • HA "Unidirectional; Alloy; stainless steel"...

  • Page 12: Marking

    ‣ Avoid proximity to sources that radiate heat. Further information on the suitability of the measuring device for safety-related operation is available from your Endress+Hauser sales center. Marking SIL certified devices are marked with the SIL logo on the nameplate.

  • Page 13: Notes On The Redundant Use Of Multiple

    Proline t-mass 500 HART Design Order code: Ser. no.: Ext. ord. cd.: Date: A0031473 SIL logo Notes on the redundant use of multiple sensors This section provides additional information regarding the use of homogeneously redundant sensors e.g. in 1oo2 or 2oo3 architectures.
  • Page 14 Design Proline t-mass 500 HART The safety-related output signal is fed to a downstream logic unit, e.g. a programmable logic controller or a limit signal transmitter, where it is monitored for the following: • Overshooting and/or undershooting of a specified limit value •...

  • Page 15: Basic Conditions For Use In Safety-Related Applications

    Proline t-mass 500 HART Design Safety-related Explanation Item no →  1 Implication for safety-related error Impact on measuring output signal uncertainty λ Dangerous undetected: May be outside the defined Dangerous, undetectable failure May be outside the defined error range...

  • Page 16: Safety Measured Error

    Design Proline t-mass 500 HART 4.4.1 Additional restrictions for safety-related use An incorrect output signal that deviates from the value specified in the Operating Instructions but is still in the range of 4 to 20 mA, is considered a dangerous, undetected failure.
  • Page 17 Proline t-mass 500 HART Design NOTICE The safety-related connection values depend on the Ex approval. ‣ Pay attention to the safety-related connection values. For detailed information on the connection values, see the Safety Instructions.→  9 4.5.2 HART communication The measuring device also communicates via HART or WirelessHART in the SIL mode. This comprises all the HART features with additional device information.

  • Page 18: Useful Lifetime Of Electrical

    Commissioning (installation and configuration) Proline t-mass 500 HART Useful lifetime of electrical components The established failure rates of electric components apply for a useful lifetime of 12 years as per IEC 61508-2: 2010, Section 7.4.9.5, Note 3. Once a device has exceeded its useful lifetime, it should be replaced.

  • Page 19: Operation

    Proline t-mass 500 HART Commissioning (installation and configuration) Operation For detailed information on the operating options, see the Operating Instructions.→  9 Parameter configuration for safety-related applications 5.5.1 Adjustment of the measuring point The measuring point is calibrated via the operating interfaces. A wizard guides you systematically through all the submenus and parameters that have to be set for configuring the measuring device.
  • Page 20 Commissioning (installation and configuration) Proline t-mass 500 HART Detailed information concerning the SIL label: • Permitted device types →  10 • SIL marking on the transmitter nameplate →  12 Overview of the SIL mode The SIL mode enables the following steps: Makes sure that the preconditions are met.
  • Page 21 Proline t-mass 500 HART Commissioning (installation and configuration) NOTICE Once the SIL device has been locked, the process-related parameters are write protected, and thereby locked, for security reasons. It is still possible to read the parameters. When SIL locking is enabled, restrictions apply on all communication options, such as the service interface, HART protocol and WirelessHART protocol, local display and WLAN.
  • Page 22 Commissioning (installation and configuration) Proline t-mass 500 HART ‣ Follow the specified locking sequence. Check preconditions are met.  Setup Measurement mode Current output 1 Single gas Gas mixture Current span Failure mode = Air = Carbon dioxide CO2 or = 4...20 mA...
  • Page 23 Proline t-mass 500 HART Commissioning (installation and configuration) Select the Set write protection parameter. Enter the SIL locking code 7452.  The device first checks the preconditions listed under item 1. NOTICE If these preconditions are not met, the message "SIL preparation = failed" appears on the display along with the parameter that failed to meet the preconditions under 1.
  • Page 24 Commissioning (installation and configuration) Proline t-mass 500 HART Setup Status input Assign status input A0042071-EN Diagnostics Simulation Assign Simulation process variable current output 1 A0021506-EN The diagnostic behavior is set in such a way that the measuring device is set to the safe state when an error occurs.
  • Page 25 Proline t-mass 500 HART Commissioning (installation and configuration) Expert System Diagnostic handling Diagnostic behavior Diagnostic no. Diagnostic no. 834, 835 Alarm A0042073-EN • 834 Process temperature too high diagnostic message • 835 Process temperature too low diagnostic message • S976 Mass flow out of calibrated range...
  • Page 26 Commissioning (installation and configuration) Proline t-mass 500 HART Expert Sensor Process parameter Flow Flow damping override A0042074-EN Expert Sensor External compensation Pressure compensation compensation Fixed value A0042075-EN Endress+Hauser...
  • Page 27 Proline t-mass 500 HART Commissioning (installation and configuration) To check that values are displayed correctly, the following string appears on the device display or operating tool: 0123456789+-. The user must confirm that the values are displayed correctly.  The device displays the current settings for the following parameters one after...
  • Page 28 Commissioning (installation and configuration) Proline t-mass 500 HART A0029675  2 Proline 500 – digital Check the write protection switch (WP) in the connection compartment. Set this switch to the ON position where necessary.  Hardware write protection enabled. Restart the device on completion of the SIL confirmation sequence.

  • Page 29: Operation

    Proline t-mass 500 HART Operation NOTICE Unlocking the device deactivates diagnostic functions, and the device may not be able to carry out its safety function in the unlocked SIL mode. ‣ Therefore, independent measures must be taken to ensure that there is no risk of danger while the SIL device is unlocked.

  • Page 30: Safe States

    Operation Proline t-mass 500 HART Safe states The system adopts one of the three states depending on the error detected: • Application error Application errors are detected by the device and a fixed failure current is output. The device can continue communicating via HART (device state: "temporarily safe"). This state persists until the application error is resolved and the device can again supply a valid measured value at the current output.

  • Page 31: Proof Testing

    This supports the documentation of proof tests according to IEC 61511-1, Section 16.3.3, "Documentation of proof tests and inspections". The Heartbeat Technology developed by Endress+Hauser can be used to implement the "Flexible testing" test strategy of field devices under NA106.

  • Page 32: Test Sequence A (Ptc = 99 %)

    The Heartbeat Technology developed by Endress+Hauser can be used to implement the "Flexible testing" test strategy of field devices under NA106 . Device verification (Heartbeat Verification) enables the documentation of the current device diagnostic or the device status as proof of testing.
  • Page 33 Proline t-mass 500 HART Proof testing 7.1.1 Test sequence: Testing with a secondary standard (mass flow) The measured values (3 to 5 measuring points) are checked with a secondary standard on an installed device (mobile calibration rig or calibrated reference device) or on a factory calibration rig following device removal.
  • Page 34 Proof testing Proline t-mass 500 HART Comparing the current values The current values can be compared using one of the following methods: • Measure the current of the DUT at the logic subsystem (process control system or safety- related PLC).

  • Page 35: Test Sequence C (Ptc = 98 %)

    Proline t-mass 500 HART Proof testing Parameter overview with brief description Parameter Prerequisite Description Selection / User entry Current output 1 to n – Switch the simulation of the simulation current output on and off. Value current output In the Current output 1 to n Enter the current value for •...
  • Page 36 Proof testing Proline t-mass 500 HART The measured values (3 to 5 measuring points) are checked with a secondary standard on an installed device (mobile calibration rig or calibrated reference device) or on a factory calibration rig following device removal.

  • Page 37: Test Sequence D (Ptc = 36 %)

    Proline t-mass 500 HART Proof testing Test sequence D (PTC = 36 %) • Device restart (Verification of RAM memory) • Verification of current output 1 • Heartbeat Verification • Inspection and on-site visual check Detection of additional systematic errors with Heartbeat Verification: influence of the process on the device (e.g.
  • Page 38 Proof testing Proline t-mass 500 HART Performing the test For proof testing, use only the Current output simulation parameter (→  35) and the Value current output parameter (→  35), as these are the only parameters approved for testing the safety-related characteristics.
  • Page 39 Proline t-mass 500 HART Proof testing Evaluation of results: Testing of current output 1 The amount of deviation between the measured current and the set point must not exceed the measured error specified for the safety function. The deviation should not exceed ±1 % / ±300 µA.

  • Page 40: Test Sequence E (Ptc = 19 %)

    Proof testing Proline t-mass 500 HART Document results of proof test in accordance with the safety management guidelines applicable to the system. At least 36 % of the dangerous, undetected failures (PTC = 0.36) can be detected with the test sequences described.
  • Page 41 Proline t-mass 500 HART Proof testing Evaluation of results: Device restart ‣ Test restart of device.  After a successful startup, the local display switches automatically from the startup display to the operational display. If the device restarts and no diagnostic message is displayed, this step has been completed successfully.

  • Page 42: Test Sequence F (Ptc = 0 %)

    Proof testing Proline t-mass 500 HART NOTICE The influence of systematic errors on the safety function is not fully covered by the test. Systematic errors can be caused, for example, by medium properties, operating conditions or buildup. ‣ If one of the test criteria from the test sequences described above is not fulfilled, the device may no longer be used as part of a protective system.

  • Page 43: Verification Criterion

    Proline t-mass 500 HART Repair and error handling Document results of proof test in accordance with the safety management guidelines applicable to the system. NOTICE No dangerous, undetected failures can be detected using the test sequences described (PTC = 0). The influence of systematic errors on the safety function is not fully covered by the test.

  • Page 44: Repair

    • Person who performed the repair Components may be repaired/replaced by the customer' s technical staff if original Endress+Hauser spare parts are used (they can be ordered by the end user), and if the relevant installation instructions are followed. For detailed information on returns, see the Operating Instructions. →  9 8.2.1...

  • Page 45: Taking Out Of Service

    Proline t-mass 500 HART Appendix ‣ Modifications to devices with SIL capability by the user are not permitted. Taking out of service The requirements of IEC 61508-1:2010 Section 7.17 must be observed when taking the device out of service. Disposal For detailed information on the device disposal, see the Operating Instructions →...
  • Page 46 Appendix Proline t-mass 500 HART For fault monitoring, the logic unit must recognize both HI alarms (≥ 21 mA) and LO alarms (≤ 3.6 mA). Endress+Hauser...
  • Page 47 Proline t-mass 500 HART Appendix 9.1.2 Description of use of protective system The measuring device can be used in protective systems to monitor the following (Min., Max. and range): Mass flow NOTICE The device must be correctly mounted to guarantee safe operation.

  • Page 48: Commissioning Or Proof Test Report

    Appendix Proline t-mass 500 HART Commissioning or proof test report 9.2.1 Test report – Page 1 A0049162 Endress+Hauser...
  • Page 49 Proline t-mass 500 HART Appendix 9.2.2 Test report – Page 2 A0049163 Endress+Hauser...

  • Page 50: Verification Or Calibration

    Appendix Proline t-mass 500 HART 9.2.3 Parameter settings for the SIL mode A0049164 Verification or calibration The SIL mode must be disabled in order to verify the measuring point with Heartbeat Technology or calibrate the measuring point. NOTICE To use the device in a safety function again following a verification or calibration, the configuration of the measuring point must be checked and the SIL mode must be enabled again.
