LuxenHome WHF1901 Instruction Manual

Product Name:
Aqua Glazed Birdbath Fountain
SKU #: WHF1901
Thank you for purchasing this LuxenHöme product. This product has been manufactured with the highest standards of
safety and quality.
PLEASE READ ALL INSTRUCTIONS BEFORE ASSEMBLY.
Please make sure to unpack all the components from the packaging inside the carton to ensure that there are no missing or
damaged parts. Do not attempt to assemble or use the product if any parts are missing or damaged.
CARTON CONTENTS:
Description
Fountain Top
Fountain Bowl
Fountain Pedestal
Pump
Compatible Pumps for this fountain:
Pump Model No.
YH-300-70
Tools required for assembly: No tools are required for assembly.
ASSEMBLY INSTRUCTIONS:
1. Unpack the box's contents and check to ensure that all items are accounted for and in good condition.
2. Remove the pump from the package and untie the power cord. The pump is packaged inside the fountain's carton.
Please check the packaging thoroughly.
4. Insert the longer power cord ① of the water pump the top of the fountain pedestal and guide it out through the
3. Select a flat, level surface for your fountain's assembly and final location.
5. Insert the water supply tube on the upper cover into the pump outlet ②. Place the pump upright inside the pedestal
opening in the back of the fountain's pedestal.
with the water tube leading out of the pedestal. ③
pump in your fountain is completely submerged in the water. ④
6. Add clean water into the pedestal. The water level should be approximately 30mm lower than the edge. Ensure the
turning it clockwise to lock it. ⑤
7. Insert the water tube into the middle of the bowl's opening and guide it through. Place the bowl on top of the pedestal
8. Attach the water tube to the opening in the fountain top, and place the fountain top in the center of the bowl. ⑥
9. Add water to the fountain bowl.
10. Connect the power cord from the pump to a properly grounded, grounding type receptacle (GFCI).
11. If installed properly, water flow in the fountain will begin shortly.
12. Adjust the flow rate (if applicable) to the maximum (+) position. If necessary, readjust the flow rate to the desired level
(remember to always disconnect from the power source before handling the pump).
Quantity
1
1
1
1
Instruction Manual
SAVE THESE INSTRUCTIONS–This manual contains important
safety and operating instructions for power units.
