- Page 1 AC Coupled Inverter User Manual LXP 3600ACS Normal Fault Return Down Enter Version: UM-ACS36001E...
- Page 2 User Manual Copyright© 2024 Lux Power Technology Co., Ltd. All Rights Reserved. This manual, protected by the copyright and intellectual property rights of Lux Power Technology, may not be modified, copied, or reproduced without prior written permission. Brands and trademarks mentioned belong to their respective owners.
- Page 3 User Manual Table Of Contents About This Manual Target Group How to Use This Manual 1. Information on this Manual 1.1 Validity 1.2 Target Group 1.3 Storage of the manuals 1.4 Additional Information 1.5 Safety 1.5.1 Symbol Explanation 1.5.2 Safety Warning 2.
- Page 4 4.2.5 UPS Settings 4.2.6 AC Charge Settings 4.2.7 Force Discharge Settings 4.3 The Working/Warning/Fault Code Explanation 5. Start UP And Shutdown 5.1 Start-UP The LXP 3600ACS System 5.2 Shut-down the LXP 3600ACS System 6. Troubleshooting&Maintenance 6.1 Troubleshooting 6.2 Maintenance 6.2.1 Inverter Maintenance 6.2.2 Battery Maintenance...
- Page 5 The user or qualified operator should keep this manual stored carefully and accessible at any time. Once lost this manual for some reason, the soft copy can be download from the official website of Lux Power Technology or e-mailed from the service department.
- Page 6 1.1 Validity This manual describes the aeesmbly, installation, commissioning and maintenance of the following AC energy storage inverter from Shenzhen Lux Power Technology Co., Ltd. 1.2 Target Group This manual is for qualified personnel who is well trained and has demonstrated skills and knowledge in the construction and operation of this device.
- Page 7 DC differential currents from battery are created, thus an external RCD(type A) can be used(≥30mA) in the AC output of the LXP 3600ACS. As the LXP 3600ACS used with PV inverters in the system, so the PV inverters are creating residual current too, in order to prevent unwanted triggering during operation, we recommend that the rated residual current of the RCD has to be min 50mA.
- Page 8 UPS function to activate this working mode.) MODE 5: PV Inverter LXP 3600ACS can be set to “Force Discharge” mode, no matter PV inverter output energy is sufficient or not, the LXP 3600ACS discharge the power to the grid and Time&power&SOC limit...
- Page 9 User Manual Forbidden System Connections Grid Without the micro-grid mode version UPS side can’t connect to Grid. hardware and firmware, UPS side should not be paralleling connected. Diesel generator Incompatible battery If it is 48V pack, and no incompatible batteries Without the micro-grid mode version hardware and firmware, On-Grid or UPS side should not could be setting as lead-acid mode in LCD,...
- Page 10 User Manual 3. Installations&Connection 3.1 Packing List Please check to make sure all the components as below are in good condition. Communication Quick installation Inverter X1 cover X1 User manual X1 guidance X1 Lead-acid Wi-Fi Module X1 AC connector X1 UPS connector X1 battery NTC kit X1 Pan head...
- Page 11 User Manual Product Overview and Connection Overview PV Inverter CT Grid CT Lithium Battery Communication Port Battery Input+ Battery Input- Lead-acid battery NTC DRMS Input(Only for Australia) Micro-grid Communication Port 3.2 Installation SYSTEM CONNECTION DIAGRAMS Household Load Sub RCD breaker (I△n≥30mA) Sub RCD breaker (I≥40A, I△n≥30mA)
- Page 12 The diagram is for Australian and New Zealand grid system 3.2.1 Select Mounting Locat The LXP 3600ACS is designed as lP65 devices with a capability to be installed in both outdoor and indoor conditions. However, selecting an optimal installation location is highly recommended to increase the safety, performance and lifespan of the inverter.
- Page 13 User Manual i ) The inverter should be installed vertically on the wall, or lean back on plane with a limited tilted angle. Please refer to below. j ) Do not install the inverter in living area. k) Do not install the inverter near TV antenna or other antenna or antenna cables. l ) Make sure there are enough space of the location for easy access to the inverter, relevant connection points and switches in future operation and maintenance.
- Page 14 Step 1. Position the machine’s probably size onto the wall; the thickness of wall for LXP 3600ACS at least 60mm. Step 2. Drill 4 holes of 8mm (5/16in.) diameter at the marked point, the depth is not less than 50mm.
- Page 15 User Manual 3.3 Connection • Make sure the inverter is totally isolated from any DC or AC power before connection. 3.3.1 Grid Connection Cable Requirements: Uninstall the AC connector. A. Diameter 10~12 mm B. Cross Section 3~4mm Pressure screw Seal ring Threaded sleeve Connection terminal C.
- Page 16 User Manual 3.3.2 UPS Connection Cable Requirements: Uninstall the UPS connector. A. Diameter 10~12 mm B. Cross Section 3~4mm Pressure screw Seal ring Threaded sleeve Connection terminal C. Strip Length 10 mm Lead the UPS cable through cable gland, Confirm the L, N, PE Ports to the UPS load lines are correct.
- Page 17 User Manual 3.3.3 Battery Connection • This part in this manual only describe the battery connection on inverter side, should you need more detailed information regarding the battery connection on battery side please refer to the manual of the battery you are using. •...
- Page 18 PV inverter • An external RCD (type A) can be used (≥30mA) in the UPS output of the LXP 3600ACS and the input of household Load. • As the LXP 3600ACS used with PV inverters in the system, so the PV inverters are creating residual current too, in order to prevent unwanted triggering during operation, we recommend that the rated residual current of the Main RCD Breaker has to be ≥50mA.
- Page 19 User Manual 3.3.6 Connecting Battery Communication Line/NTC And CTs • Before any installations, must read following description of battery communication port and “NTC” port. • Before any installations, must read following description of DRMS port (Only for Australian safety). Battery communication port RJ45 Red color switch Blue co lo r switch...
- Page 20 User Manual R ed co lo r switch Blue co lo r switch F unctio n Descrip tio n F unctio n Descrip tio n M eter R S 485- B M eter R S 485- B M eter R S 485- A M eter R S 485- A Deb ug g ing R S 485- B Deb ug g ing R S 485- A...
- Page 21 User Manual Cable Requirements: 3. “CT cable”(With RJ485) 1. “Batterycommunication cable” 2. “NTC”(For lead-acid battery) 4. “CT cable”(With RJ11) (lithium battery CAN/RS485 communication) Step 1. Unscrew the swivel nut from the cable gland. Step 2. Remove 3 plug-columns from the rubber stopper and others reserved.
- Page 22 User Manual Step 7. lf lithium battery connecting the Battery communication cable the side with label of “Battery” (lithium battery) to the lithium battery communication port. lf lead-acid battery, just let the NTC near the lead-acid battery surface. Step 8. Catching the CT1 to the grid L line from grid and the direction is "Grid→House”. Catching the CT2 to the grid L line of the inverter output.
- Page 23 User Manual 4. Display, Setting And Operation 4.1 LCD Overview And Brief Introduction This type LCD screen contains the system information display and setting functions, the overview of the LCD screen is shown below: Normal Fault Return Down Enter Screen Interface instruction: Description Remarks This area will display the currently time/date by default (year “month: day,...
- Page 24 User Manual There are three type of working status-normal, warning and fault, in System working status right side of this area, there are code display, it will display different type of code-the system working mode code, warning code and fault code. When UPS function is enabled, this area will display UPS voltage, UPS/EPS output frequency, power etc.
- Page 25 User Manual 4.2.2 Start The Settings When the system is not in Auto Test or Programming status, then please press Return button access into the setting process: When pressed Return button the area 1 (for fime setting) will flashing at the start, you can press UP and Down buttons to select what to set, and then press Enter button to start the settings on selected setting options.
- Page 26 User Manual • Set the Month: When finished the years setting then the month number will fashing, press UP and Down buttons to change the month number, and press Enter button to confirm and finish the month setting. • Set the Day: When finished the months setting then the day number will flashing, press UP and Down buttons to change the day number, and press Enter button to confirm and finish the day setting.
- Page 27 User Manual 4.2.4 Battery Settings Press Return button, then press UP or Down buttons to select area ③ (when area ③ is flashing), then press Enter button to start the battery settings. Normal Fault Return Down Enter Press Enter button to select battery type ( Lead-Acid or Li-ion). •...
- Page 28 User Manual BAT. Brand number Battery Brand Reserve Reserve Pylon Tech Reserve Reserve Reserve Reserve … … 4.2.5 UPS Settings To use the UPS (sometimes regarded as EPS or back-up function) function, it must be enabled through the UPS settings. Normal Fault Return...
- Page 29 User Manual Press Return button to get into setting mode, then press UP and Down button to select the area ⑤ (when area ⑤ is flashing), then press Enter button to start the UPS settings. • Enable/Disable UPS function: Press UP and Down buttons to select the Disable or Enable option when they are flashing, and press Enter button to enable or disable the UPS function.
- Page 30 User Manual 4.2.6 AC Charge Settings Normal Fault Return Down Enter Press Return button to get into setting mode, and press UP and Down button to select the AC Charge option of area ⑨ is flashing, then press Enter button to start the AC charge settings. •...
- Page 31 User Manual • AC charge power limit rate settings: When enabled the AC charge function, it will turn to the setting of AC charge power limit rate settings which means to set the AC charge power rate against the maximum AC output/input power.
- Page 32 Step 1. Turn off all the circuit breakers and switches, make sure that the grid connection, battery connection, PV connection and UPS connection are all disconnected by turning off the relevant breakers and switches. Step 2. Wait for 5mins and the LXP 3600ACS is shut down completely.
- Page 33 User Manual 6. Troubleshooting&Maintenance 6.1 Troubleshooting Once there are any warning or fault occurred, the LED and LCD will displays information to remind the operator, the LCD will display relevant error code and short description. LCD Display Description Troubleshooting Restart inverter, if the error still exist, Internal communication fault 1 please contact us.
- Page 34 User Manual Temperature over range Check NTC connection. Restart inverter, if the error still Internal fault exist, please contacts us. Restart inverter, if the error still Sampling inconsistent exist, please contacts us. between main and slave CPU Restart inverter, if the error still Internal communication fault4 exist, please contacts us.
- Page 35 For detailed information please refer to the warranty card in the packaging of the inverter or contact our service center via email, web message or phone call. Contact Shenzhen Lux Power Technology Co., Ltd Add: 5th floor, Building 11, Hengchangrong High-Tech Industrial Park, Huangtian Comunity, Hangcheng Street Bao’an District, Shenzhen, China...
- Page 36 User Manual Nominal Output Voltage(V) Nominal Output Frequency(Hz) 50/60 Max. AC Current Output to Utility Grid(A) Max. AC Current From Utility Grid(A) Output Power Factor ~1(Adjustable from 0.8 leading to 0.8 lagging) Output THDI ＜3% Single phase Grid Connection Inrush Current 10A/10us Max.
- Page 37 User Manual Note...
- Page 38 User Manual...
- Page 39 User Manual...
- Page 40 Lux Power Technology Co., Ltd Headquarter: +86 755 8520 9056 www.luxpowertek.com Contact us: info@luxpowertek.com 092.20062AA...
