SHALLOW POND DIFFUSED AERATOR

Contents:

 Initial Inspection

 General Information

 Electrical Grounding

 Placement & Operation

 Maintenance

 Product Warranty

6A Wolfer Industrial Drive

Spring Valley, Illinois 61362

1(800) 377-0019 Toll Free

1(815) 664-4900 Bus.

1(815) 664-4901 Fax

www.aquacontrol.com

info@aquacontrol.com

INSTALLATION/OWNERS MANUAL

3, 4

4, 5, 6, 7

8, 9, 10, 11

Need help?

Do you have a question about the SP10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aqua Control SP10

Page 1 6A Wolfer Industrial Drive Spring Valley, Illinois 61362 1(800) 377-0019 Toll Free 1(815) 664-4900 Bus. 1(815) 664-4901 Fax www.aquacontrol.com info@aquacontrol.com SHALLOW POND DIFFUSED AERATOR INSTALLATION/OWNERS MANUAL Contents:  Initial Inspection  General Information  Electrical Grounding 3, 4  Placement & Operation 4, 5, 6, 7 ...
Page 2 UPON RECEIVING YOUR ORDER – OPEN AND INSPECT PRODUCT IMMEDIATELY Product damaged in delivery The Aqua Control Inc., (ACI) aeration system was properly packed and accepted by the freight carrier for shipment. It is therefore their responsibility to deliver the system in perfect condition.
Page 3 GENERAL INFORMATION CAUTION: The pump is designed for air only. Do not allow corrosive gases or particulate material to enter the compressor. Water vapor, oil-based contaminants or other liquids must be filtered out. CAUTION: Ambient temperature should not exceed 40C (104F). For operation at higher temperatures, please consult the factory.
Page 4 AERATION EXPECTATIONS The following benefits can be expected from an Aqua Control, Inc. (ACI) aeration system:  Increased and constant oxygen levels from the surface to the bottom.  Constant temperature from the surface to the bottom.
Page 5 INSTALLATION TOOLS & MATERIALS For quick, easy and professional installations, the following tools and materials are needed:  Utility razor knife  Flat head screwdriver COMPESSOR INSTALLATION The compressor is designed for easy placement on the ground. The entire system can be hidden behind landscaping and foliage.
Page 6 During operation never completely close any valves. Model SP10 does not require the use of a Manifold. Model SP30 and SP40 will need the appropriate Hose Barb installed for the size of Tubing being utilized.
Page 7 DIFFUSER BASE PLACEMENT Correct placement of the Stainless Steel Diffuser Base is critical. The ability of the aeration system to affect your pond is dependent upon the position of the Diffuser. 1. Uncoil the roll of self-weighted tubing along the shoreline of your pond. Make sure the tubing has no twist or tangles to make it easier to install the Stainless Steel Diffuser Base.
Page 8 For repairs or replacement parts, please contact your distributor or manufacturer. Cleaning the filter (Refer to Fig.3) REPLACEMENT FILTERPAD PART# SP10 ..............A1361 SP20 ..............A1362 SP 30 & 40 ............A1363 • Undo the truss screw securing the cover to the pump housing, and remove the Filter pad.
Page 9 (Refer to Fig.4-2) If stuck, insert screwdriver between exhaust outlet and Upper housing, and gently pry apart. • Remove the Sound absorbing foam. (Refer to Fig.4-2 except for SP10) • Remove the screws from all the corners of frame cover for subsequent removal of the frame cover.
Page 10 Replacing Diaphragm mounting block (Refer to Fig.5) • After removing Head (Casing) block, remove one of the hex nut (U-lock nut) and washer in the center of the diaphragm. • Remove one of the Diaphragm mounting blocks from the Rod, and pull out the other Diaphragm mounting block from the pump body together with the Rod without loosening its hex nut (U-lock nut) and washer.
Page 11 Replacement of Safety Screw (Refer to Fig.6) (For SP20, SP30, SP40) The body of the switch is set on the upper part of the Rod. If the Diaphragm is damaged or unit is dropped, the unusual movement of the Rod will cause the upper part of the Rod to touch the L-shaped lever, contacting the spring terminal, breaking the safety screw.
Page 12 • Reinstall the 4 screws holding the Frame cover on. (For SP30 Refer to Fig.4-4) • Reinstall the Sound absorbing form (except for SP10). • Reinstall the Upper housing and tighten corner screws. (Refer to Fig.4-1) TROUBLE SHOOTING Safety Screw...
Page 13 No implied warranties of any kind are made by Aqua Control, Inc. for its products, and no other warranties, whether expressed or implied, including implied warranties of merchantability and fitness for a particular purpose, shall apply.
