60 Hz. SELECT SERIES 2 DISPLAY AERATOR INSTRUCTION MANUAL
Safety
Assembly
Vertical & Torrent
Nozzle Types
This product is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person
to ensure that they can operate the product safely.
Young children should be supervised to ensure that they do not play with the product.
Your Aqua Control, Inc. products are made entirely of corrosion resistant materials including stainless steel, aluminum alloy, bronze and
engineered plastics. They will provide safe, long and satisfactory service if properly installed, operated and maintained.
1.
Follow all applicable local and state electrical codes.
2.
Protect exposed or vulnerable wiring with tubing or conduit.
3.
Do not operate the unit when it is obvious the flow rate is reduced.
4.
Do not work on the unit when it is turned on or operating.
5.
Follow all normal safety precautions when working in and around the water.
6.
Prevent tension on the electrical wires.
7.
Do not carry or pull the unit by the lights or by the cable. Use the finger pockets on the float.
8.
Never try to dislodge debris from the impeller or propeller while the motor is connected to the power supply.
9.
Always verify the control panel and all electrical equipment are grounded properly.
10.
Any time high voltage electricity is used underwater, a potential safety hazard exists. Aqua Control builds and provides
UL listed control panels that are standard equipped with a Class A Ground Fault Circuit Interrupter (GFCI) for both motors and
lights. Class A GFCI's are designed to provide protection against electrocution for people. They have a nominal trip level of 5 ma
and are designed to shut the circuit off in 25 milli seconds. Such a system will shut off a current resulting from shorts or
dangerous leakage, whether from the motor, electrical cables or controls, befor a hazardous current can develop.
Prior to installing, verify the correct product has been ordered and received. Aqua Control, Inc. will not accept any returns for refund or exchange
of product or components that have been installed in the water or modified in any way. Keep original packaging for returns to the
factory or contact the factory for instructions as to how to obtain packaging for safe return of product.
1.
Check the packing list that came with the shipment. Make certain all the boxes have been received. Each label will have a box number
and total for the shipment (1 of 5, 2 of 5). The packing list has the total number of boxes noted at the bottom.
2.
Check the pond depth. Is the pond deep enough for the unit being installed?
3.
Verify the incoming voltage where it will be connected to the control panel. Does the measured voltage match the rated
motor voltage requirements? Note the HP, voltage and phase on the packing list.
4.
Is there a VFD operating from the same power supply or in the vicinity that might interfere with the GFCI?
Copyright 2014. All Rights Reserved.
Aqua Control Water Features

TABLE OF CONTENTS

PAGE
Cable
1
Control Panel & Start Up
2
3
4-5
6
Winter Sinking
SAFETY INFORMATION
Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual
PAGE
7
8
9
10
11
1 2
13
14
WARNING
PRE-ASSEMBLY
Troubleshooting
PAGE
15
16
17-18
19
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SELECT Series 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aqua Control SELECT Series 2

Summary of Contents for Aqua Control SELECT Series 2

  • Page 1: Table Of Contents

    PRE-ASSEMBLY Prior to installing, verify the correct product has been ordered and received. Aqua Control, Inc. will not accept any returns for refund or exchange of product or components that have been installed in the water or modified in any way. Keep original packaging for returns to the factory or contact the factory for instructions as to how to obtain packaging for safe return of product.
  • Page 2 11. The float has 12 finger pockets molded into the underside for lifting and carrying the assembled unit. 12. See the nozzle and light set instructions for attaching these to the unit. Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 3: Horizontal

    SELECT SERIES 2 HORIZONTAL DISPLAY AERATOR ASSEMBLY All horizontal units are shipped assembled therefore, NO assembly is required. determine the nozzle type, see page 4. To attach the nozzle, see page 5 for the nozzle instructions. If the unit has lights, see page 6 for the light set instructions.

  • Page 4: Nozzles

    Find the nozzle that is being attached to this unit in the table below. This table will tell you which of the two nozzle types a nozzle falls under to locate the correct instructions. The flow straightener has bee n replaced by the outlet fairing in the Select Series 2.
  • Page 5 Re-attach the screws with lock washers removed in step #1. The nozzle has been pre-set at the factory. Remove and dispose (step 2) Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...
  • Page 6 The rubber washer always goes between the insert and the hardware. 8. The unit is ready to be floated after the cable connection(s) have been made. Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 7: Lights

    The one without tape gets its power from the black wire in the 4-wire cable. The two connectors share the ground and neutral line. Join connectors and hand tighten. FROM CONTROL PANEL LIGHT SET CONNECTOR LIGHT SET CONNECTOR LIGHT CABLE CONNECTOR LIGHT CABLE CONNECTOR T-CONNECTOR Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 8: Light Cable & T-Connectors

    Motor Lead Connector Pump Cable Connector Motor Lead Connector Pump Cable Connector & Light Set Connector & Light Cable Connector Neutral Ground Ground Yellow Black Neutral Ground Ground Black Yellow Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...
  • Page 9 INSTALLATION Aqua Control Inc. (ACI) is certified to manufacture UL Listed Industrial Control Panels (UL 508A), and all control panels are UL listed except 460V panels or panels built with prior agreement for certain special configurations. Certain special configurations, the 1hp-115V, all 460V and all 575V control panels cannot be UL Listed because of the National Electric Code and UL requirements.

  • Page 10: Installation / Launching

    6. Never allow long lengths of rope to float near the intake of the unit where it can be pulled in and entangled in the propeller or impeller. FINAL LOCATION OF UNIT FLOAT EYEBOLT MOORING EYE MOORING EYE BOTTOM OF POND Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 11: Anchoring

    The anchor lines must be kept tight enough to prevent the unit from rotating due to motor torque. If the water level changes or the anchor lines otherwise become slack, the unit will rotate and twist the electrical cord causing cord damage. FINAL LOCATION OF UNIT FLOAT EYEBOLT ANCHOR ANCHOR BOTTOM OF POND Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 12: Flotation 1

    SELECT SERIES 2 Diagram 1 below shows the optimum floating depth for an Aqua Control Unit. The shaded area of the diagram shows the least amount of float and nozzle possible. The chart shows the amount of weight that needs to be added to sink the unit to the optimum depth. This is an optional step. The unit will operate just the same without adding any weights, but more of the float will be showing.

  • Page 13: Maintenance

    WARRANTY DISCLAIMER: Many variables must be considered before deciding to operate a Select Series 2 Vertical Aerator or Titan Fountain (never a Select Series 2 Fountain or Horizontal Aerator) during the winter. These variables include but are not limited to the depth of the lake, overall size of the lake, climate variation, predictability of cold, and loss of power in winter conditions.
  • Page 14 To sink a unit for winter storage, the pond depth must be 4 to 6 feet plus the height of the unit itself. Get the minimum water depth from the Aqua Control brochure, add 4 to 6 feet plus the normal depth of ice on the pond. If the pond does not have sufficient depth, then sinking is not an option for winter storage.
  • Page 15 Three phase – check each hot wire; readings should be within 5% of one another. 6. If GFCI tripped, perform “GFCI Troubleshooting Procedures” 7. If overload tripped, perform “Overload Troubleshooting Procedures” Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 16: Cable

    3. It may be impossible to determine the location of the open line and a new cable may be the best solution. e. Perform these steps for each combination of wire pairs. Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 17: Motor Control Box

    If the meter has capacitance checking capability, check the capacitance. See table below. f. Reconnect the leads to the capacitor. # RUN CAPS RUN µF # START CAPS START µF 105-126 208-250 20/40 270-324 Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...

  • Page 18: Overload

    Check all output leads to motor for proper amps. d. If amps are good, go to “Nuisance Tripping.” e. If amps are high, continue. 1-PHASE 3-PHASE VOLTS AMPS VOLTS AMPS 12.5 10.9 20.5 17.8 Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...
  • Page 19 One possible solution is to remove the cover of the motor control box. Another solution is to cover the control panel with an awning or face the panel North or West. Aqua Control, Inc. 60 Hz. Select Series 2 Instruction Manual...
