Aqua Control SP10 Installation & Owner's Manual

Phone 800.377.0019
Fax 815.664.4901
50Hz SHALLOW POND DIFFUSED AERATOR
Product Damaged in Delivery
If damage is discovered upon delivery, refuse the shipment until the transportation company's agent has noted damage on
the freight bill. Do not sign delivery acknowledgement until the damage is noted. Notify the transportation company
immediately to inspect the damaged equipment. Inspections must be requested within 5 days of delivery. Do not move
damaged goods from original point of delivery and retain all original packing for inspection. File a FULL VALUE
REPLACEMENT claim with the transportation company. If any part of shipment is LOST IN TRANSIT, have the shortage
noted on freight bill by agent. Notify your distributor immediately for assistance in repairing or replacing equipment.
Safety Screw
Occasionally during shipping the installed safety screw is broken. An extra safety screw has been included in the box for
replacement, if necessary. Refer to Fig.4 for instructions on how to replace the screw.
Product Warranty
Aqua Control will repair or replace any defective part for a period of one year from date of receipt. Customer is responsible
for return shipping of any goods for warranty inspection. After inspection, if product shows a manufacturing defect, Aqua
Control will replace or repair it at no cost to customer. Should inspection indicate non-warranty failure (incorrect voltage,
faulty installation procedures, vandalism, customer negligence, etc.) warranty would be void.
SYSTEMS MATERIAL LIST
Upon receipt, inspect to ensure that all of the components are included. If your aeration system has experienced damage
from shipping, promptly report the damage to the carrier that provided delivery. Verify that you have received the following:
- Compressor
- Diffuser
- 3/8 Hose Barb preinstalled SP10 / SP20
GENERAL INFORMATION
CAUTION: The pump is designed for air only. Do not allow corrosive gases or particulate material to enter the pump. Water
vapor, oil-based contaminants or other liquids must be filtered out.
CAUTION: Ambient temperature should not exceed 40°C (104°F). For operation at higher temperatures, please consult the
factory. Keep out of direct sunlight whenever possible.
CAUTION: To avoid risk of electrocution, do not use this product where it could become submerged in water or other liquids.
CAUTION: Do not block the flow of cooling air around the pump in any way. The life of the pump may be reduced or
malfunction could occur if hazard is ignored.
GROUNDING INSTRUCTIONS FOR ALL GROUNDED, CORD-CONNECTED PRODUCTS
! DANGER:
This product must be grounded. The compressor is equipped with a grounding wire cord with appropriate grounding plug.
The plug must be plugged into a properly installed outlet and grounded in accordance with all local codes and ordinances.
Check with a qualified electrician if grounding instructions are not completely understood or if in doubt whether the product is
properly grounded. Do not modify the plug provided. If it does not fit the outlet, have the proper outlet installed by a qualified
electrician. This product is for use on a nominal 230 Volt 50Hz circuit only.
EXTENSION CORDS
When using an extension cord, be sure to use one in good condition that is heavy enough to carry the current that your
product will draw. A No.14 AWG cord no longer than 50 feet can be used. Undersized cord causes a drop in line voltage
INSTALLATION / OWNERS MANUAL
- Extra safety screw
- Rubber elbow
Improper installation of the grounding plug can result in electric shock. If repair or replacement of
the cord or plug is necessary, do not connect the grounding wire to either flat blade terminal. The
wire with green insulation with or without yellow stripes is the grounding wire.
- Hose clamps
- Self-Weighted Air Supply Tubing
- 3/8 or 5/8 Hose Barb installation required SP30 / SP40
