- Page 1 INSTRUCTION MANUAL Swivel Bar Chair Set of 2 SKY6182 + SKY6183 + SKY6722 + SKY6723 + SKY6724 + SKY7991 SKY7992 + SKY7993 + SKY7994 + SKY7995 + SKY7996 + SKY7997 SKY7998 + SKY7999 Ver. 4...
- Page 2 NOTICE Please retain these instructions for future reference. • Please do not exceed the weight limitations of this item. • Do not stand on or use any part of this item as a step ladder. • Do not lean backwards when sitting in chair. •...
- Page 3 PARTS LEFT ARMREST RIGHT ARMREST SEAT 2 PCS 2 PCS 2 PCS BACKREST FOOTREST BAR 2 PCS 8 PCS 2 PCS BRACING ROD LEG CONNECTOR 2 PCS 2 PC...
- Page 4 PRODUCT ASSEMBLY Attach one part A left armrest to one part C seat with two part 1 bolts and two part 6 washers. Attach one part D backrest to the seat assembly with two part 1 bolts and two part 6 washers. Attach one part B right armrest to the seat assembly with four part 1 bolts and four part 6 washers.
- Page 5 PRODUCT ASSEMBLY Attach one part G bracing rod to the part A & B armrests with two part 2 bolts and two part 6 washers. Set the seat assembly aside. Locate one part H leg connector and slide on four part E legs. NOTE: Be sure to align the fastening holes for later assembly).
- Page 6 PRODUCT ASSEMBLY Place one part F footrest bar onto the leg assembly and secure with four part 3 bolts, eight part 6 washers, and four part 7 nut caps. Place the seat assembly onto its front, then turn the rotating hardware plate as indicated. This will make the following steps easier to complete.
- Page 7 PRODUCT ASSEMBLY Attach the leg assembly to rotating hardware plate on the bottom of the part C seat with four part 4 bolts, four part 6 washers, and four part 5 nuts. Loosen and tighten the feet until level. Repeat steps 1-7 to assemble a second chair.
- Page 8 HELP CENTER Question about your product? We're here to help. Visit us at: help.bestchoiceproducts.com CHAT Chat Support Product Inquiry Orders FAQ Product Assembly Returns & Refunds PRODUCT WARRANTY INFORMATION All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the item is returned in its original product packaging and all accessories from its original shipment are included.
