Bartscher GmbH Phone: +49 5258 971-0 Franz-Kleine-Str. 28 Fax: +49 5258 971-120 D-33154 Salzkotten Technical Support Hotline: +49 5258 971-197 Germany www.bartscher.com Version: 3.0 Date of preparation: 2025-01-22...
Page 3
Original instruction manual Safety ......................1 Explanation of Signal Words ..............1 Safety instructions..................2 Intended Use ................... 6 Unintended Use ..................6 General information ..................7 Liability and Warranty ................7 Copyright Protection ................7 Declaration of Conformity ................ 7 Transport, Packaging and Storage ..............
Page 5
Safety Diese Bedi enungsanlei tung besc hrei bt di e Installation, Bedi enung und Wartung des Geräts und gilt als wic htige Inform ationsquelle und N achschl agew erk. Z najom ość w szystkich zaw artyc h w ni ej wsk az ówek dotycz ącyc h bezpi ecz eńs twa i obsł ugi stanowi w arunek bez pi ecz nej i prawi dłow ej pr acy z urządz eni em. Ponadto należy przestrzeg ać odpowi ednio do mi ejsca użytk owani a urządz eni a l okal nyc h przepis ów dotycz ącyc h z apobieg ani a wy padk om oraz og ólnyc h zas ad BH P. This ins truc tion m anual is an integral part of the pro duct and m ust be kept i n the imm edi ate vici nity of the devic e for installati on, operation, m aintenanc e and cleani ng pers onnel to acc ess at all times . If the devic e is pass ed on to a thir d pers on, the operating instructions m us t al so be handed over.
Page 6
Safety WARNING! The signal word WARNING warns against hazards that may lead to moderate or severe injuries or death if the hazards are not avoided. CAUTION! The signal word CAUTION warns against hazards that may lead to light or moderate injuries if the hazards are not avoided. , di e IMPORTANT! The signal word IMPORTANT indicates possible property damages,...
Page 7
Safety • Do not bend, pinch nor knot the power cord. • Always completely unwind the power cord. • Never place the appliance or other objects on the power cord. • Always take hold of the plug to disconnect the appliance from the power supply. •...
Page 8
Safety • Do not heat up sealed containers, e.g. canned food, on the heating area of the induction cooker. Resulting overpressure may cause explosion (rupture) of a container or a can. The canned food is best to open it, put it in a pot filled with water and place the pot on a heating area in order to heat it up.
Page 9
Safety Supervised Usage only • Only supervised appliance may be used. • Always remain in an immediate vicinity of the appliance. Operating personnel • This appliance is not intended to be used by persons (including children) with limited physical, sensory or mental capabilities, nor by persons with limited experience and/or limited knowledge.
Page 10
Safety Intended Use This appliance is only intended for use described in the operating instructions, with the supplied and approved components. Any other use is considered against the intended purpose. The manufacturer shall not be liable for any damage due to unintended use. In such cases the responsible party shall only be the user/operator.
Page 11
General information General information Liability and Warranty The appliance was built in accordance with the current state of the art and recognized technical safety principles. Nevertheless, during its use, there may be a threat to the health and life of the user or bystanders, or the danger of damage to the device or other assets.
Page 12
Transport, Packaging and Storage Transport, Packaging and Storage Delivery Check Immediately upon reception, check the delivery for completeness and possible shipping damage. In the case of visible transport damage refuse to accept the appliance or accept it conditionally. Mark and note the scope of damage in shipping documents/consignment list of the shipping company and lodge a complaint.
Page 13
Technical Data Technical Data Technical Specifications Name: Induction cooker IK 35TC 105843 Art. No.: Material: stainless steel Heating plate material: glass Number of hobs: Glass hob dimensions (W x D), in mm: 285 x 285 Hob diameter, in mm: Power output per hob: 3,5 kW Number of power output levels: Temperature range, min.–max., in °C:...
Page 14
Technical Data Name: Induction cooker IK 35TCS 105843S Art. No.: Material: stainless steel Heating plate material: SCHOTT CERAN® Number of hobs: Glass hob dimensions (W x D), in mm: 285 x 285 Hob diameter, in mm: Power output per hob: 3,5 kW Number of power output levels: Temperature range, min.–max., in °C:...
Page 15
Technical Data List of Components of the Appliance Fig. 1 1. Housing 2. Control elements 3. Feet (4 pcs) 4. Dust/grease filter 5. Glass hob Dust and Grease Filter The induction cooker is provided with a dust and grease filter. It is located at the bottom of the appliance.
Page 16
Installation and operation Functions of the Appliance The induction cooker is intended for preparation and heating up of foods using appropriate cookware. Installation and operation Installation Unpacking / Positioning • Unpack the appliance, remove all external and internal packaging elements and shipment safeguards.
Page 17
Installation and operation • Do not place the appliance in the vicinity of devices or objects that are sensitive to magnetic fields (e.g. radio, television, etc.). • Leave at least 5 -10 cm clearance from flammable walls and other objects. Power supply connection •...
Page 18
To obtain better results, use only pans/pots with a diameter of 12–24 cm. Example: Induction cooker cookware, Bartscher 9-piece set of cookware Chrome-nickel steel, anti-drip edges, non-heating handles 4 pots with lids 2.0 litre, 16 cm diameter, H 10.0 cm 2.7 litre, 18 cm diameter, H 11.0 cm...
Page 19
Installation and operation Not Suitable Cookware • Containers with bulged bottoms • Aluminium, brass, copper cookware unless they are clearly indicated as suitable for induction • Pots/pans with a diameter below 12 cm • Cookware with feet • Ceramic cookware •...
Page 20
Installation and operation Control Elements / Displayed Messages Fig. 3 1. Time setting key 2. Digital display 3. Indicator lights: power output, 4. Selection function key: temperature, time temperature and power output 5. ON/OFF indicator light 6. ON/OFF switch 7. Time, temperature or power output 8.
Page 21
Installation and operation Temperature Levels 1. If you do not wish to work with the power output levels, press the selection key for temperature or power output mode to switch to the temperature mode. The appliance switches to the default temperature of 120°C. 2.
Page 22
Installation and operation Switching Appliance OFF 1. When the process of cooking or keeping food warm is finished, switch the appliance off with the ON/OFF key NOTE! The induction cooker switches off automatically if no setting is selected within 2 hours or if time setting is set for over 120 minutes. 2.
Page 23
Cleaning Cleaning Safety Instructions for Cleaning • Before cleaning, disconnect the appliance from the power supply. • Leave the appliance to cool down completely. • Make sure water does not enter the appliance. Do not immerse the appliance in water or other liquids during cleaning. Do not clean the appliance with a pressurized water jet.
Page 24
Possible Malfunctions Possible Malfunctions Mögliche The table below contains descriptions of possible causes and solutions to malfunctions or errors during operation of the appliance. The works may only be performed by suitably qualified technical personnel. Error Code Cause Solution No cookware on the hob Use only suitable cookware or inappropriate cookware Appliance is getting too...
Page 25
Disposal Disposal Electrical Appliance Electric appliances are marked with this symbol. Electrical appliances must be disposed of and recycled in a correct and environmentally friendly manner. You must not dispose of electric appliances with household waste. Disconnect the appliance from the power supply and remove power cord from the appliance.
