- Page 1 COLOR BAR CB-48 User Guide Professional Entertainment Technology...
- Page 2 1. Safety Instruction Please read carefully the instruction, which includes important information about the installation, usage and maintenance. WARNING Ÿ Please keep this User Guide for future consultation. If you sell the unit to another user, be TABLE OF CONTENTS sure that they also receive this instruction booklet.
- Page 3 3. How To Set The Unit Ÿ The housing, the lenses must be replaced if they are visibly damaged. 3.1 Control Panel Caution There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer.
- Page 4 3.2 Main Function To select any of the given functions, press the MENU button up to when the required one is showing on the display. Select the function by ENTER button and the display will blink. Use DOWN and UP button to change the mode. Once the required mode has been selected, Press ENTER button to store.
- Page 5 DMX Address ENTER button and the display will blink. Use DOWN and UP button to select the on (sound Press the MENU button up to when the DMX Address is showing on the display. Press control on) or off (sound control off) mode. Once selected, press the ENTER button to store. ENTER button and the display will blink.
- Page 6 press ENTER button to store and g 255 will blink on the display, press DOWN and UP 2-light show button to adjust the value, press ENTER button to store and b 255 will blink on the display, In slave mode, slave 1 means the unit run as the master unit and slave 2 means 2-light press DOWN and UP button to adjust the value, and press ENTER button to store.
- Page 7 19 channels 4.4 DMX 512 Configuration...
- Page 9 4.5 DMX512 Connection 5. Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
- Page 10 6. Fixture Cleaning The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics. Ÿ...
- Page 11 Innovation, Quality, Performance...
