Roland PowerStack ST-2 Service Notes page 4

Sep . 2 0 1 0
Ex p lo d ed View
fig.bunkaizu.eps
Ex p lo d ed View Pa r ts List
No. Part Code Part Name
1 13129710R0 SWITCH (PUSH )
2 5100007503 BATTERY CUSH ION
3 5100007872 BATTERY CON N ECTOR
4 5100006631 CAUTION SEAL
5 5100006633 BOTTOM FOOT
6 5100006632 BOTTOM COVER
7 5100007509 IN SULATIN G SH EET
8 5100007505 PEDAL GUIDE BUSH
9 5100007504 COIL SPRIN G
10 5100008294 PEDAL PLATE
a 5100008092 PLAIN WASH ER 3X6X0.5
b 40010267 SCREW M3X10
c 5100007965 SCREW 3X6(H 5029325R0)
d 5100007512 TH UMB SCREW
4
Description
JM-0404
(22267333R0)
006P BATTERY SN AP (F3419102R0
PSA (FCC/ EMI)(G2537516R2)
(22357305R0)
(22027851R0)
(75D273W0R0)
(22157702R0)
(22177109R0)
(22357304R0)
RESIN RTC(H 5039708R0)
BIN DIN G MACH IN E FE BZC
PAN TAPPIN G B1 BZC
(H 5029820R0)
Q'ty
1
1
1
1
1
1
1
1
1
1
2
2
4
1
ST-2
