Roland PowerStack ST-2 Service Notes page 3

Sep . 2 0 1 0
Lo ca tio n o f Co n tr o ls
fig.panel.eps
Lo ca tio n o f Co n tr o ls Pa r ts List
No. Part Code Part Name
1 5100014487 COMPACT PSA LABEL
2 5100015359 PAN EL
3 5100015357 CASE
4 04567601 P R-KN OB
5100017231 ROTARY POTEN TIOMETER
40128923 H EX N UT M7
5 01903234 6.5MM JACK
5100003926 PLAIN WASH ER 9X13.5X0.5T
5100008086 IN T TOOTH WASH ER 9.5X12.5X0.5
5100003918 JACK N UT M9X12X2
6 5100008294 PEDAL PLATE
7 5100006632 BOTTOM COVER
8 5100006633 BOTTOM FOOT
9 5100006631 CAUTION SEAL
10 F3439875R0 ADAPTOR JACK
11 03349978 LED(RED)
12 04567601 P R-KN OB
F3279852R0 POTEN TIOMETER
40128923 H EX N UT M7
13 5100015358 PEDAL
14 5100007512 TH UMB SCREW
Description
(22537538R0)
(G2217815R0)
(75D173C0R0)
MF BLK/ LCG(RTC) (22480260)
RD901F-20-15FW-A10K-006
H TJ-064-13D
N I(H 5039158R0)
N I RTC(H 5039205R0)
N I RTC(H 5039510R0)
(22357304R0)
(22027851R0)
(22357305R0)
PSA (FCC/ EMI)(G2537516R2)
KM02018ABM1P
L-34H DSL-FPB
MF BLK/ LCG(RTC) (22480260)
RD901-20-15FW-B54-006
(75D172T0R0)
(H 5029820R0)
Q'ty
1
1
1
1
1
1
2
2
2
2
1
1
1
1
1
1
3
3
1
1
1
ST-2
3
