MOD : N77/R316G-9B

Production code : 8073106HCDIA

10 /2023

Need help?

Do you have a question about the 600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Diamond 600

Page 1 MOD : N77/R316G-9B Production code : 8073106HCDIA 10 /2023...
Page 2 MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE: BASI REFRIGERATE INSTALLATION, OPERATING AND MAINTENANCE MANUAL: REFRIGERATED COUNTERS INSTALLATIONS-, BEDIENUNGS- UND WARTUNGSANLEITUNG: KÜHLUNTERSCHRANK NOTICE D’INSTALLATION, UTILISATION ET ENTRETIEN: SOUBASSEMENT RÉFRIGÉRÉES Manuale di installazione, uso e manutenzione * …………………………………………………………………………………………....………3 Installation, operating and maintenance manual ...............................…15 Installations-, Bedienungs- und Wartungsanleitung ……………………………………………...………………………………....…..…………27 Notice d’installation, utilisation et entretien ……………………………………………………………………………………..………....…...…39...
Page 3 INFORMAZIONI PER LE APPARECCHIATURE CON REFRIGERANTE R290 (PROPANO) INFORMATION FOR BUILT-IN REFRIGERATED UNITS WITH REFRIGERANT R290 (PROPANE) INFORMATIONS POUR LES VITRINES REFRIGEREES AVEC REFRIGERANT R290 (PROPANE) INFORMATIONEN FÜR DROP-IN GEKÜHLTE ELEMENTE MIT KÜHLMITTEL R290 (PROPAN) Prima di eseguire qualsiasi intervento è necessario leggere e seguire attentamente le istruzioni contenute all’interno del manuale d’uso.
Page 4 Table of contents WARNINGS ..........................16 Appliance description ......................16 Transportation and handling ....................17 Operating conditions and technical specifications .............. 17 Installation .......................... 18 Electrical connections ......................18 Reasonably foreseeable misuse ..................19 Operation/use ........................19 Total shutdown........................19 Routine cleaning and maintnance ..................
Page 5 INSTALLATION, OPERATING AND MAINTENANCE MANUAL: REFRIGERATED BASE UNITS 1. WARNINGS Read this manual carefully before commencing installation. The manual has been designed to provide the user with all the information required to use the appliance safely, from its transportation right through to its disposal. In order to properly understand the document, you must be familiar with the terms and symbols used;...
Page 6 Warning: R290 gas is a potentially flammable and explosive type of gas. Therefore, it is absolutely necessary to take every precaution to avoid any danger related to the nature of this gas during routine and unplanned operations. Only specialised personnel are authorised to work on the appliance; these personnel must avoid using open flames and electric tools.
Page 7 1.4 Installation Before unpacking the appliance, check that the outer protective casing is fully intact. Any damage must be promptly reported to the courier. In any case, no damaged appliance can be returned to the manufacturer without prior notice and without prior written authorisation. The described operations must be carried out by qualified personnel.
Page 8 1.6 Reasonably foreseeable misuse Any use other than what is specified in this manual is considered improper. When using the machine, work or activities that may pose risks to the safety of the workers or cause damage to the appliance are not permitted.
Page 9 1.9 Routine cleaning and maintnance The appliance must only be cleaned after the power supply upstream from the appliance has been disconnected. During the maintenance operations, the cable and the plug must be always visible and accessible for the operator who is performing the operations. The routine and preventive maintenance essentially entails cleaning the stainless steel parts with warm water and mild soap on a weekly basis, and then rinsing and drying these thoroughly.
Page 10 2. INTRODUCTION Read this manual carefully before commencing installation. The manual has been designed to provide the user with all the information required to use the appliance safely, from its transportation right through to its disposal. In order to properly understand the document, you must be familiar with the terms and symbols used; these are summarised below: WARNING –...
Page 11 RESISTENZA SCARICO RESISTENZA SBRINAMENTO ITALY 155,0 DISCHARGE RESISTANCE DEFROSTING RESISTANCE 1 - Depth 4 - Details 6 - Supply frequency 600 mm 2 drawers 60 Hz 700 mm 3 drawers 50 Hz 900 mm 4 drawers 7 - Refrigeration 6 drawers...
Page 12 6. INSTALLATION 6.1 Controlling the appliance upon receipt Before unpacking the appliance, check that the outer protective casing is fully intact. Any damage must be promptly reported to the courier. In any case, no damaged appliance can be returned to the manufacturer without prior notice and without prior written authorisation.
Page 13 7.3 Digital thermostat 1 – Display 2 – “Increase value” push button and manual defrost activator 3 – “Decrease value” push button 4 – It activates the standby function when pressed for at least 5 seconds and is also the “exit function”...
Page 14 8.2 Unplanned maintenance Before carrying out any maintenance work, put the appliance in a safe condition. Unplanned maintenance is carried out in the event of a fault or malfunction. It must only be performed by qualified personnel and with the appliance disconnected from the power mains. In this case, repairs or replacements might be required.
Page 15 11. SCHEMI DI MONTAGGIO E SPECIFICHE TECNICHE – DIAGRAMS AND TECHNICAL FEATURES - MONTAGEPLÄNE UND TECHNISCHE SPEZIFIKATIONEN - SCHÉMAS DE MONTAGE ET SPÉCIFICATIONS TECHNIQUES Fig. 1: PANNELLO COMANDI – CONTROL PANEL – SCHALTFELD - PANNEAU DE COMMANDES A = TERMOSTATO DIGITALE - DIGITAL THERMOSTAT - DIGITALER THERMOSTAT - THERMOSTAT DIGITAL B = INTERRUTTORE GENERALE - MASTER SWITCH - HAUPTSCHALTER - ITERRUPTEUR GENERAL...
Page 16 11.1 ELEMENTI BASI REFRIGERATE - REFRIGERATED COUNTERS - KÜHLUNTERS- CHRANK - SOUBASSEMENT RÉFRIGÉRÉS Caratteristiche tecniche elementi basi refrigerate – Technical features of refrigerated counters – Technische mer- kmale Kühlunterschrank – Caracteristiques techniques soubassement réfrigérés Tab. 1 MODELLO 600 MODELLO 700 MODELLO 700 FREEZER MODELLO 900 MODEL 600...
Page 17 NOTE - NOTES - BEMERKUNGEN - NOTES A010046R290 Rev.1 Page 54 of 56...
Page 18 NOTE - NOTES - BEMERKUNGEN - NOTES Page 55 of 56 A010046R290 Rev.1...
Page 19 TARGHETTA CARATTERISTICHE – DATAPLATE – TYPENSCHILD – PLAQUE SIGNALETIQUE Incollare targhetta caratteristiche apparecchiatura L’Azienda si riserva di introdurre senza preavviso eventuali modifiche tecnico-costruttive sul prodotto e sulle composizioni presentate. The company reserves the right to introduce without notice any technical or construction changes of the product or presented compositions. Der Hersteller behaltet sich vor Aenderungen an den Produkten zu vornehmen ohne Vorabhinweis.
