Diamond CEG 110 Manual

Hide thumbs Also See for CEG 110:

Advertisement

Quick Links

Download this manual
02/2009
Mod: G65/6BP11-EC
Production code: CEG 110

Advertisement

loading
Need help?

Need help?

Do you have a question about the CEG 110 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Diamond CEG 110

Summary of Contents for Diamond CEG 110

  • Page 1 02/2009 Mod: G65/6BP11-EC Production code: CEG 110...
  • Page 2 INDEX Warnings Compliance with EEC directives Compliance with EEC Directives for electric, fan and conventional ovens Compliance with EEC Directives for gas appliances Installation diagrams Technical data table Gas characteristics Instructions for the qualified installer Installing the appliance Laws, technical regulations and general rules Discharge of fumes for type A appliances Discharge of fumes for type B appliances Checking for gas leaks...
  • Page 3 This appliance has b een made for cooking food and must only be used by professionally skilled personnel in the way described in this instruction manual. 1. WARNINGS · Read this handbook through carefully as it provides important information for safe installation, use and mai ntenance.
  • Page 4 TECHNICAL DATA TABLE HOB COOKERS COOKERS WITH OVEN - ALLPLATE TOTAL GAS NOZZLE DIAMETER HOB COOKER OVEN CONSUMPTION 1/100 of a mm BURNERS TOTAL BURNERS POWER NATURAL MODELS NATURAL G30-31 No. x kW No. x kW G30-31 30/37mbar 20mbar kg/h m³/h 30/37mbar 20mbar...
  • Page 5 PILOT FOR THE ALLPLATE BURNER PASS BURNER "C" 3,6 kW REGUL. " "D" = 5 kW REGUL. " ALLPLATE REGUL. " OVEN REGUL. PRIMARY AIR POSITION FOR BURNER 3.6 kW OPEN " " 5.0 kW A mm " FOR OVEN PILOT FOR THE ALLPLATE BURNER THESE VALU ES ARE APPRO XIMATE - ALW AYS MAKE...
  • Page 6 INSTRUCTIONS FOR THE QUALIFIED INSTALLER INSTALLING THE APPLIANCE · Take the uni t out of the packaging. Check that it is in good condi tion. If in doubt, do not use it and contact pr ofessionally qualified personnel. Always place the unit under an aspiration hood. After installation, it will need to be levelled by using the feet.
  • Page 7 DISCHARGE OF FUMES FOR TYPE A APPLIANCES The appliances must be i nstalled on premises that are sui table for the discharge of the combustion products and must co mply with the installation rules. Our appliances are considered type A gas appliances (see the Techni cal Data Tables) and are not for connecting to a natural discharge duct for combustion products.
  • Page 8 CHECKING FOR GAS LEAKS Once installed, check ther e are no gas leaks from the pipe joints by using a soapy water solution. You will know if there are leaks by the foamy bubbl es that form. Never use bare flames to check for leaks. When the appliance is ready to use, check ther e are no gas leaks, by checki ng on the gauge, if used (for a period of 30 minutes), that there is no passage or consumption of gas.
  • Page 9 7.1.1 Changing top burner parts Safety cock (6): remove the grill s (1), burners (3), trays (2), panel (12), unscrew the connecting pipes (13) and fittings (14) from the gas shaft , unscrew the ther mocouple (15) and change the cock. Thermocouple (15): unscrew the cock fitting (6), unscrew the nuts hol ding the thermocouple supporting square (16) in place and change the thermocouple.
  • Page 10 7.2.1 Allplate spare parts replacement Safety cock (6): remove the panel (12), unscrew the nut connect ing the cock to the supply shaft (9) and to the burner supply pipe, unscrew the thermocouple (15) and the pilot pipe (16) from the cock, change the cock. Thermocouple (15): remove the panel (12), unscrew the ther mocouple (15) from the cock (6) and from the pil ot support (23) and then change it.
  • Page 11 7.3.1 Changing oven parts (fig. 4) Thermostatic cock (6): remove the grills (1), burners (3), trays (2), panel (12), unscrew the inlet (14) and outlet (7) fittings, unscrew the thermocouple (15), pull the thermostatic cock bulb out which is inside the oven, on the support (23), change the cock and then put everything back in place.
  • Page 12 USER INSTRUCTIONS TURNING THE ALLPLATE BURNER ON AN D OFF (Fig. 9) Lighting the pilot flame: Push the knob (8) and turn it counter clockwise round to the pil ot position (spark symbol). Simultaneously press the piezoelectric lighter knob and button and the pilot burner will light.
  • Page 13 TURNING THE OVEN BURNER ON AND OFF Turning the Oven bur ner on and off: The oven burner is fed by a ther mostatic cock with a safety val ve. To light the burner , push the knob (8) and turn it counter clockwise round to the r equired oven temper ature (from 150°C to 300°C shown on the knob) (Fig.
  • Page 14 MIXED GAS ELECTRIC COOKERS PREPARING FOR INSTALLATION The appliance must be posi tioned in a well aerated place, if possible under a suction hood to ensure compl ete evacuation of the fumes created when cooki ng. Before using the appliance for the first time, remove all the protection sheets, cl ean all the surfaces with a soft cloth, warm water and soap to r emove all traces of the antirust products applied duri ng production.
  • Page 15 9.1.3 Electrical connection 1) The cookers are delivered for working with a VAC voltage of 400+3N. 2) Connect to the electricity line, interposing a suitably rated automatic circuit breaker, where the opening distance between the contacts must be at least 3 mm. Furthermore, supply voltage must not deviate from the voltage value by ±...
  • Page 16 USER INSTRUCTIONS 10.1 STARTING THE ELECTRIC CONVECT ION OVEN Cookers are appliances for cooking food and must only be used by professionally qualified personnel in the way indicated in this instruction manual. Any other improper use can be dangerous. Turn the main switch on. Turn the thermostat knob round from "0"...
  • Page 17 EXPLODED FUNCTIONAL PARTS TABLES 11.1 EXPLODED FUNCTIONAL PARTS TABLES FOR "C" AND "D" BURNERS WITH PIEZOELECTRIC IGNITION BRUCIATORI Mod. 65/40 PCG BRULEURS 65/70 PCG "C" = 3,6 kW BRENNERS 65/70 CFG "D" = 5 kW BURNERS 65/70 CFGE 65/110 CFG 65/110 CFGE FIG.
  • Page 18 11.2 EXPL ODED FUNCTIONAL PARTS TABLES FOR "C" AND "D" BURNERS WITH MANUAL IGNITION Mod. CEG/70 CEG/110 BRUCIATORI BRULEURS "C" = 3,6 kW FIG. 1 BRENNERS "D" = 5 kW BURNERS FIG. 2 FIG. 3 CHIUSO MASSIMO MINIMO FERME' MAXIMUM MINIMUM GESCHLOSSEM LAAG...
  • Page 19 11.3 EXPLODED FUNCTION PART S TABLES FOR OVEN BURNER FIG. 4 BRUCIATORE BRULEUR "F" = 5 kW BRENNER BURNER Mod. 65/70 CFG CFG/70A 65/110 CFG CFG/110A TPFG/70A 65/70 TPFG TPFG/110A 15 25 65/110 TPFG FIG. 6 FIG. 5 FIG. 7 CHIUSO MASSIMO MINIMO...
  • Page 20 11.4 EXPLODED FUNCTIONAL PARTS TABLES FOR ALLPLATE BURNER Mod. 65/70 TPG BRUCIATORE 65/70 TPFG BRULEUR 65/110 TPFG "P" = 8,2 kW BRENNER BURNER FIG. 8 7 6 8 FIG. 9 FIG. 10 CHIUSO PILOTA MASSIMO MINIMO FERME' VEILLEUSE MAXIMUM MINIMUM GESCHLOSSEM ZÜNDFLAMME LAAG...
  • Page 21 11.5 EXPLODED TABLES FOR ANTI-DRAUGHT FLUE ASSEMBLY FIG. 11 NATURAL DISCHARGE anti-draught device Note: the anti-draught device is supplied upon r equest...
