Translated from German to English - www.onlinedoctranslator.com
D
original operating instructions
Hydraulic firewood processor SSA-400GHPRO/S
Model: SSA-400GHPRO/S
Both the model number and serial number can be found on the rating plate on the
machine. You should keep both numbers in a safe place for future reference.
FOR YOUR SAFETY, READ THE ENTIRE INSTRUCTIONS BEFORE OPERATING
SSA-400GHPRO/S
Serial number:
OPERATING INSTRUCTIONS
Art. No.: SSA400GHPROS
www.lumag-maschinen.de
_____________________________
Advertisement
Related Manuals for Lumag SSA-400GHPRO/S
Summary of Contents for Lumag SSA-400GHPRO/S
- Page 1 Translated from German to English - www.onlinedoctranslator.com SSA-400GHPRO/S Art. No.: SSA400GHPROS www.lumag-maschinen.de original operating instructions Hydraulic firewood processor SSA-400GHPRO/S Model: SSA-400GHPRO/S Serial number: _____________________________ Both the model number and serial number can be found on the rating plate on the machine.
- Page 2 CONTENT / GENERAL TABLE OF CONTENTS GENERAL 1. General 2. Information on the operating instructions 3. Intended use 4. Scope of delivery 5. Environment DANGER! 6. Technical data Read all safety warnings and 7. Symbols instructions. 8. Security 9. Transport Use this manual to familiarize yourself with the 10.
- Page 3 GENERAL / INFO / INTENDED USE Designation machine replaced Trade name of the item to which this operating manual refers - see cover page. operating instructions beginning before Please read the instructions carefully before using the device for the first time! They are part of the product and must be kept in a known place that is accessible to all copyright protection All documents are protected by copyright.
- Page 4 SCOPE OF DELIVERY / ENVIRONMENT / TECHNICAL DATA TECHNICAL DATA SCOPE OF DELIVERY After unpacking, check the contents of the box/ Model SSA-400GHPRO/S transport box for completeness and possible transport damage. 10.0 kW / 459 cm³ Engine / Drive (petrol) max.
- Page 5 SYMBOLS SYMBOLS Check engine oil! Check the oil level before each use and after at least 8 operating hours (BTS). There are symbols on the machine. These represent important information about the product or instructions for use. Warning of hot surfaces. Danger of burns! DANGER! Do not touch hot engine parts.
- Page 6 SYMBOLS Do not use the machine in enclosed spaces. Danger moving tools Chainsaw! Danger of slipping and enough tripping! In the work area on Pay attention to free space. Clutter can For one person operation only lead to accidents. Warning, do not remove jammed logs with your hands.
- Page 7 SECURITY SECURITY Oil level in the hydraulic oil tank. Do not use your firewood processor if repairs are required or the machine is in poor condition. safety and warning instructions Familiarize yourself with the firewood processor Wear appropriate protective clothing Read and understand the operating instructions Do not wear loose clothing, loose gloves, scarves, and the labels on the machine.
- Page 8 SECURITY are cut as squarely as possible. This prevents the To split logs whose size exceeds the size specified in split material from slipping out under pressure. the specifications table. Use the firewood processor Branches must be cut flush with the tree trunk. only for the purpose of processing wood and not any other materials or objects.
- Page 9 TRANSPORT / PART NAME-ENGINE TRANSPORT 10. PART NAME-ENGINE Before each transport, the following steps must be completed: gasoline engine ■ Switch off the machine's motor and allow it to cool down to avoid burns and to eliminate the risk of fire. ■...
- Page 10 FUEL choke lever 11. REFUELLING The choke lever opens and closes the carburetor DANGER! choke valve. The choke lever is only used to start a You may only carry out the work described in this cold engine. chapter after you havesafety instructionsread and understood.
- Page 11 FUEL 11.2 GASOLINE DANGER petrol flammable extremely Health and explosion hazards from combustion explosive. You may suffer burns or other serious engines injuries when handling fuel. ■ The engine's exhaust contains When refilling fuel, please note: poisonous carbon monoxide. Staying in an environment containing carbon monoxide can lead to ■...
- Page 12 COMMISSIONING 12. COMMISSIONING DANGER Do not start the engine in enclosed spaces. The 12.1 PREPARATION FOR USE exhaust fumes contain carbon monoxide, which is very toxic if inhaled! ■ Lubricate the machine regularly depending on how often it is used. See ... FUEL / ENGINE OIL 12.2 EMERGENCY STOP SWITCH (FIG.
- Page 13 COMMISSIONING 5. Pull the recoil starter gently until you feel resistance, then pull the cable firmly and let it slowly roll back in or use the electric start function by pressing the engine switch to the "START / II" position and holding it until the engine has started.
- Page 14 OPERATION 13. OPERATION X4: Control lever “eg log lifter 1” Tilted up = runs forward Tilted down = runs backward Think carefully about where you will work. Work safely and save time by planning your work in advance. X5: Operating lever “eg log lifter 2” Tilted upwards = lift Tilted downwards = lower Store your logs where they are easy to reach.
- Page 15 OPERATION 13.3 OPERATION OF THE MACHINE conveyor belt (not fully shown) Hydraulic feed chain operating lever for wood splitter (h1) hydraulic system (h2) Hydraulic system 2 (only for optional accessories) operating hour meter splitting cross adjustment emergency stop switch feet support wheel Protective grille for chainsaw and splitter cable winch / conveyor belt...
- Page 16 OPERATION 1. Make sure that all components of the firewood 9. If the split material does not fall correctly into the processor are firmly screwed together and that splitting device, switch off the motor as no loose parts could cause dangerous injuries. described in point 10.4.
- Page 17 PROCEDURE FOR A BENT PIECE OF WOOD / MAINTENANCE 14. PROCEDURE FOR A BENT PIECE OF 15. MAINTENANCE WOOD 15.1 MAINTENANCE Turn off the engine and disconnect the spark plug connector from the engine. Constant maintenance of the firewood processor ensures a long service life of all components.
- Page 18 MAINTENANCE File each tooth very carefully. First remove the oil drain cap “B1”, which is located underneath the machine. To do this you have to Clean the chainsaw after filing. remove the 4 screws. Unscrew the filter cartridge on the hydraulic filter Check the chain very carefully after grinding.
- Page 19 MAINTENANCE 15.6 CLEANING / CHANGING THE AIR FILTER 15.3 SHARPENING THE SPLITTING CROSS The splitting machine is equipped with a Cleaning the air filter frequently will prevent reinforced splitting wedge that has been carburetor malfunctions. If the engine starts to specially treated.
- Page 20 MAINTENANCE 15.7 CHECKING / REPLACING THE 15.8 DRAINING OF OPERATING MATERIALS SPARK PLUG Change the engine oil while the engine is still warm. Check the spark plug and the gap between the Warm oil drains quickly and completely. electrodes regularly. ATTENTION! Environmental damage.
- Page 21 MAINTENANCE / STORAGE 16. STORAGE 15.10 CLEANING Store the machine in a horizontal position on level ground in a dry and well-ventilated building. Maintenance and cleaning work should only be carried out when the drive is switched off and at a standstill. The machine should always be cleaned.
- Page 22 TROUBLESHOOTING 17. TROUBLESHOOTING Observe safety instructions! Any faults in the machine or engine that require major intervention should always be repaired by your LUMAG specialist workshop or an authorized specialist workshop. Improper intervention will void the warranty. Caused remedy Disturbance...
- Page 23 Warranty work is carried out exclusively by our defects resulting from negligent assembly, faulty LUMAG service workshop. Defects that occur within connection, incorrect fuel/fuel mixture, installation, the warranty period due to material or operation, maintenance, lubrication or force.
- Page 24 Telephone: +49 / 8571/92556-0 Fax: +49 / 8571/92556-19 that the product Designation: Firewood processor Type designation: SSA-400GHPRO/S meets the essential protection requirements of the above-mentioned EC directives. Conformity is based on the following standards: EN ISO 12100:2010 Safety of machinery - General principles for design - Risk assessment and risk reduction...
- Page 25 HYDRAULIC DIAGRAM 20. HYDRAULIC DIAGRAM cylinder, chainsaw engine, chainsaw motor, conveyor belt motor, conveyor belt splitting cylinder cylinder, split cross adjustment cylinder, retaining claw additional cable for accessories...
- Page 26 NOTES 21. NOTES _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...
- Page 27 NOTES _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...
- Page 28 LUMAG GmbH Rudolf-Diesel-Str. 1a D-84375 Kirchdorf am Inn Telephone: +49 (0)85 71 / 92 556 - 0 Fax: +49 (0)85 71 / 92 556 - 19 www.lumag-maschinen.de Status: 11/2024 - SSA400GHPROS...
