Flare Fireplaces SIT ProFlame II CS7 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
WARNING: If the information in these
instructions is not followed exactly, a
fire or explosion may result in causing
property damage, personal injury, or
loss of life.
Do not store or use gasoline or other
flammable vapors or liquids in the
vicinity of this or any other appliance.
If you smell gas, please:
- Do not try to light any appliance
- Do not touch any electrical switch;
do not use any phone in your
building.
- Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
- If you cannot reach your gas
supplier, call the fire department.
A qualified installer, service agency, or
local gas supplier must perform
installation and service.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Installation and service of this appliance must be performed by qualified NFI certified technician, or a
certified and trained Flare Fireplaces dealer.
Massachusetts: The piping and final gas connection must be performed by a licensed plumber or gas
fitter in the state of Massachusetts. Also, see local code for carbon monoxide requirements.
Flare Fireplaces SIT ProFlame II – CS7
[Flare Front Facing, See-Through, Left Corner, Right Corner, Double Corner, Room Definer, Passage]
Version 20.4
DANGER
Flare requires installation be performed
by an NFI certified installer, or an
authorized Flare Dealer Tech who has
been trained to professionally install the
fireplace. Installations that do not
follow this instruction will not be
covered by warranty or service.
NOTICE
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED
NEVER ALLOW CHILDREN
TO TOUCH GLASS

Advertisement

loading
Need help?

Need help?

Do you have a question about the SIT ProFlame II CS7 and is the answer not in the manual?

Questions and answers

Related Manuals for Flare Fireplaces SIT ProFlame II CS7

Summary of Contents for Flare Fireplaces SIT ProFlame II CS7

  • Page 1 Massachusetts: The piping and final gas connection must be performed by a licensed plumber or gas fitter in the state of Massachusetts. Also, see local code for carbon monoxide requirements. Flare Fireplaces SIT ProFlame II – CS7 [Flare Front Facing, See-Through, Left Corner, Right Corner, Double Corner, Room Definer, Passage]...
  • Page 2 CONTENTS SAFETY INFO AND WARNINGS .............................. 7 FLARE FIREPLACES – FRAMELESS IN EVERY WAY ........................ 9 CSA CERTIFICATION................................9 MANUAL MODEL LIST AND INFORMATION ........................10 ELECTRICAL AND POWER REQUIREMENTS ........................12 FIREPLACE OPRATION ................................. 12 REMOTE CONTROL – INSTRUCTIONS ..........................12 TEMPERATURE INDICATION DISPLAY ........................
  • Page 3 TELESCOPIC LEG SETUP............................... 41 FRONT FACING AND SEE-THROUGH FIREPLACE LEG SETUP ..................42 LEFT, RIGHT, AND DOUBLE CORNER FIREPLACE LEG SETUP ..................43 UNPACKING CONTROL UNIT AND ACCESSORIES ......................44 POSITIONING AND SECURING YOUR FIREPLACE ....................... 45 RGB LED LIGHTING ................................46 PAIRING YOUR RGB LED REMOTE - GEN 1 AND GEN 2 ....................
  • Page 4 GAS REQUIREMENTS ................................75 SIT PROFLAME II GAS VALVE LAYOUT ..........................76 USING A REDUCER TO DE-RATE YOUR FLARE FIREPLACE ....................77 ADDING THE FLARE FIREPLACES DE-RATING REDUCER ....................78 ORIFICE SIZE ..................................79 GAS VALVE ACCESS DOOR .............................. 79 LIQUID PROPANE USAGE IN A FLARE FIREPLACE ......................
  • Page 5 LEFT AND RIGHT-SIDE VENTS ........................... 108 LINEAR SLOT ................................109 FLARE FRONT, SEE THROUGH, AND CORNER FIREPLACE CLEARANCE ..............110 FLAT – SIDE AND ISOMETRIC VIEW & CLEARANCES ....................110 L SHAPE – SIDE AND ISOMETRIC VIEW ........................113 SIDE OVERHANG FOR LEFT, RIGHT, AND DOUBLE CORNER FIREPLACES ............... 116 INDOOR/ OUTDOOR KIT..............................
  • Page 6 EXCLUSIONS .................................. 135 WARRANTY VOID WHEN............................... 135...
  • Page 7 SAFETY INFO AND WARNINGS WARNING! If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life. A qualified installer, service agency or the supplier must perform installation and services. The direct vent system appliance must be installed as an OEM installation in manufactured homes (USA only), or an aftermarket permanently located, or a mobile home, where not prohibited by local codes, and must be installed in accordance with Manufacturer’s instructions and the Manufactured...
  • Page 8 This appliance must be electrically wired and grounded in accordance with local codes, or in the absence of local codes, with National Electric Code ANSI/NFPA 70 – latest edition or the Canadian Electric Code CSA C22.1 A 110-120V AC Circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as bathrooms or near sinks.
  • Page 9 FLARE FIREPLACES – FRAMELESS IN EVERY WAY Flare Fireplaces are where innovation, quality and luxury come together to form innovative ideas. By combining superior raw materials, contemporary design, creative technology, and a frameless way of thinking, we have created a full line of direct-vent fireplaces that are luxurious, simple to operate, and efficient.
  • Page 10 ● Flare Room Definer 45 - 100”: 16” (R), 24” (H), 30” (EH) Flare Fireplaces should only be connected to M&G DuraVent or ICC 4x6 or 5x8 venting system. Refer to the specific appliance model and size to determine vent size and chimney pathway requirements. For...
  • Page 11 For assistance or additional information, consult a qualified service technician, service agency or your local fireplace dealer. Flare Fireplaces requires installation be performed by an NFI certified installer, or certified Flare dealer. Installations that do not follow this instruction will not be covered or serviceable under warranty.
  • Page 12 Flare Fireplaces does not recommend the use of home automation with our fireplaces. Only operate the fireplace when you can be in the same room as the high-powered gas appliance.
  • Page 13 TEMPERATURE INDICATION DISPLAY When the system is turned off the LCD screen will display the current room temperature in Fahrenheit (°F) or in Celsius (°C.). To change from in Fahrenheit (°F) to Celsius (°C.), or vice versa, press the “Thermostat” key and the “Mode”...
  • Page 14 TURNING THE SYSTEM ON When in “On” mode the remote LCD will show the room temperature icon, and any other modes currently turned on by default. To turn “On” press the On/Off remote button. The remote LCD will then show other icons. At that time, the module will activate the appliance and a single beep from the receiver will confirm command from the remote.
  • Page 15 FLAME HEIGHT CONTROL ProFlame II has 6 levels of modulation. When the system is On the flame level will be at the maximum level. Once adjusted the remote LCD will show a series of 6 steps going down, or up, depending on adjustments being made.
  • Page 16 SMART THERMOSTAT MODE The smart thermostat mode will adjust the flame height depending on the set temperature that has been set by the user. When the room temperature gets close to the set temperature the smart thermostat function will modulate the flame down. To activate the smart thermostat function, press the “Thermostat”...
  • Page 17 MANUAL THERMOSTAT MODE The Remote control can operate as a room thermostat. The thermostat can be set to a desired temperature to control the room temperature. The thermostat icon on the LCD screen will display the thermostat status is ON. The user can then set a suitable temperature for the space. To activate this option, press the “Thermostat”...
  • Page 18 CONTINUOUS PILOT AND INTERMITTENT PILOT IGNITION (IPI AND CPI) By default, the Flare Fireplace is setup for IPI operation, but this can be changed to CPI on screen units only. When the system is Off pressing the “Mode” key to index to CPI mode icon. Pressing the “Up” arrow will select the CPI mode (but it is still not activated.
  • Page 19 KEY LOCK – CHILD SAFETY MODE To avoid unsupervised operation of the remote control this feature has been created. A lock icon will appear on the LCD screen. To activate this feature, press the “Mode” and “Up” at the same time. A lock icon will appear in the LCD screen.
  • Page 20 LOW BATTERY DETECTION The lifespan of your remotes three AAA batteries varies based on remote and fireplace operation. When the remote battery is low an empty battery icon will appear on the LCD Screen WARNING Do not use a screwdriver or other metallic object to remove the batteries from the battery box! This could cause a short circuit to the system.
  • Page 21 PAIRING YOUR REMOTE TO THE SIT RECEIVER Your remote will come paired with the fireplace receiver to allow for operation out of the box. In the event of a remote or receiver replacement, or power failure, use the following procedure to pair the remote with the receiver.
  • Page 22 IGNITION SEQUENCE Starting from Off, press the remote power button. Four seconds after it is pushed the SIT module will send a spark to the pilot hood, and spark for 60 seconds. If there is no flame ignition during the first ignition sequence, the SIT module will stop sparking for approximately 35 seconds and then begin sparking again.
  • Page 23 WALL SWITCH CONTROL The SIT ProFlame II system ships with an easy-to-use wall switch which operates the On/Off functionality only. It can be used in the event the remote control isn’t nearby or has no battery charge. The wall switch comes connected to the X8 port on the SIT receiver. NOTICE When used with double glass, power vented, and summer kit systems, the wall switch must be connected to operate the relay necessary to turn the secondary fan system on, verify power, and allow...
  • Page 24 MEDIA PLACEMENT GUIDE AND CALCULATION GUIDE Every Flare fireplace can be set up with approved glass, stone, or wood media. Quantities are determined by the size of the fireplace and type of media chosen within that fireplace. Mixing of media types (i.e., glass and stones together) is acceptable if the quantities are adjusted to prevent overwhelming the burner and gas flow.
  • Page 25 REFLECTIVE BACK, DOUBLE GLASS, AND SAFETY SCREEN INSTALLATION The following outlines how to install your Reflective Back, Double Glass, and Safety Screen, which can ship with a Flare fireplace. To see a step-by-step video on this installation, please click here. LOCATING GLASS PACK A Flare fireplace will come with its glass pre-packaged safely, inside the fireplace crate, attached to the interior frame using 4 screws.
  • Page 26 REFLECTIVE BACK – INSTALLATION Your black reflective back panel will be installed against the back wall of the fireplace using two suction cups, secured by the included reflective back brackets, and behind the outside lip of the burner tray along the base of the fireplace. See examples outlined in the steps and images below. Using suction cups, lift your reflective back into position against the back wall of your fireplace, making sure to set behind the lower lip of the burner tray.
  • Page 27 INNER CERAMIC GLASS – INSTALLATION Your inner ceramic glass panel can be installed after removing the left, right, and bottom fillers. Then remove the left, right, and bottom trim brackets. Followed by opening the top butterfly trim to allow the installer to insert the glass into position. See examples outlined in the steps and images below. Remove the left and right magnetic fillers by gently lifting and pulling them out.
  • Page 28 Remove the left, right, and bottom inner trim brackets by loosening the bolts or hand screws, releasing the trim brackets from the fireplace frame. Set aside to protect from damage. Locate and loosen all hand screws across the top frame of the fireplace. This will open your inner butterfly trim.
  • Page 29 Using suction cups insert the inner ceramic glass behind the upper butterfly trim, push in gently, then set panel along the small holders, lining the bottom frame of the fireplace. Once the inner ceramic glass panel is in position press in and hold the upper butterfly trim while tightening the hand screws, sealing the glass against the non-combustible gasket.
  • Page 30 Locate and reinstall your lower trim bracket. Once in position tighten all the hand screws securing your lower trim bracket against the glass, sealing it against the non-combustible gasket. Locate and reinstall your lower louvered filler by placing it on its holder across the bottom frame of the fireplace.
  • Page 31 Locate and reinstall your left and right-side magnetic fillers to complete your inner ceramic glass installation. OUTER TEMPERED GLASS – INSTALLATION Your outer tempered glass panel can be installed only after the inner ceramic glass has been properly placed into position. See examples outlined in the steps and images below. Using suction cups lift your tempered layer of glass safely into position, gently placing the top of the glass against the outside of the top butterfly trim tabs...
  • Page 32 Using the top of your glass panel, gently push in on the tabs, sliding your glass up and into the channel built into the top of the fireplace frame. Once lifted into the top of the fireplace frame, make sure the bottom of your glass has clearance to the bottom fireplace frame and slowly lean glass inward to insert into bottom glass channel.
  • Page 33 SAFETY SCREEN – INSTALLATION The Instructions outlined below show how to install the invisible mesh safety screen on all Flare fireplaces. This safety barrier can be installed and removed with no tools. NOTICE The screen safety barrier is designed to reduce the risk of burns from the hot viewing glass and is provided with this appliance unless the unit has been upgraded to include the Double Glass.
  • Page 34 INSTALLATION STEPS Prior to starting the installation, make sure you read and understand all the WARNING information in the manual. Do not start the installation if you are unclear about any of the installation related subjects. Determine the following: • The vent system configuration to be used based on the fireplace location. Follow the manual venting section to determine the venting requirements and setting.
  • Page 35 ACCESS - COMPONENT WHIP All Flare fireplaces ship with the components attached to a 50” whip, centered, at the underside of the fireplace. This allows an installer to drag the components to the far left, far right, behind, below, or directly underneath the fireplace.
  • Page 36 ACCESS PANEL SIZING RECOMENDATIONS Access panels will come in all different shapes and sizes, below is minimum sizing for multiple styles outlining what is important for creating meaningful access. Keep in mind the access can be on the front, sides, back , or even under the unit. These are recommendations, not requirements. Use best judgement for sizing based on the unique design parameters of the project.
  • Page 37 INSTALLATION PREPARATION FIREPLACE UNPACKING The following outlines best practices for uncrating and checking in your Flare Fireplace. Upon delivery verify the fireplace serial number matches your packing slip by locating the fireplace nameplate on the face of your crate. Next, examine the shipment for any damage, making sure to mark any damage found on the Bill of Lading before your driver leaves.
  • Page 38 Using your power drill begin removing the screws on the top and face of the crate to expose the wrapped and protected fireplace inside.
  • Page 39 Mark any missing or damaged components on the Bill of Lading before your driver leaves. NOTICE If any items from the packing slip are missing from inside the fireplace crate, please call Flare Fireplaces immediately to verify the shipment, as well as any potential resolution.
  • Page 40 Remove and relocate the glass packet, media, spare parts, and any other immediately unnecessary components to a safe location to not only lighten the load for transit to the jobsite, but to protect these elements from being lost or broken onsite. Please make sure to leave the fireplace, and its electronic components, wrapped until you are ready to install.
  • Page 41 TELESCOPIC LEG SETUP The fireplace legs will need to be set once the crate has been removed. The legs can be configured so the bottom of the glass will be between 10”-19” above the floor. This means the bottom of the fireplace will be 4”-13”...
  • Page 42 FRONT FACING AND SEE-THROUGH FIREPLACE LEG SETUP The following outlines how to adjust your telescopic legs on front facing and see-through fireplaces. Release the safety pin and two bolts from the leg you are adjusting. Extend your leg to the desired height, increasing in one-inch increments. Then lock-in your height by reinstalling the two bolts and safety pin.
  • Page 43 LEFT, RIGHT, AND DOUBLE CORNER FIREPLACE LEG SETUP Step 1 - First, unpack you corner telescopic legs to verify the four legs and eights screws are present. Step 2 - Next, determine which holes to insert the screws so the fireplace will stand at the desired height Step 3 –...
  • Page 44 UNPACKING CONTROL UNIT AND ACCESSORIES Unpack the accessories (remote, power adapter & wall switch). The gas valve, receiver, control module (for double glass units) must remain wrapped until the first test of unit. • Place accessories (white bag) in a secure location. •...
  • Page 45 POSITIONING AND SECURING YOUR FIREPLACE Once the telescopic legs have been properly attached and/or adjusted the fireplace can be safely moved, on its delivery pallet, and secured in its final installation location to the back wall or framing using the fireplaces top brackets. NOTICE Make sure to never drag the fireplace during installation.
  • Page 46 RGB LED LIGHTING The Flare Fireplaces RGB LED light kits are the perfect way to showcase your unique style and make a statement inside your Flare Fireplace. The RGB LED light kit open up the possibility of not only designing the space around your fireplace, but the inside your fireplace too.
  • Page 47 NUMBER MODE BRIGHTNESS STATE SPEED STATE STATIC WHITE ADJUSTABLE UNADJUSTABLE WHITE COLOR GRADUAL CHANGES ADJUSTABLE ADJUSTABLE ALL COLORS GRADUAL CHANGES ADJUSTABLE ADJUSTABLE RED/GREEN/BLUE 3 COLORS GRADUAL CHANGE ADJUSTABLE ADJUSTABLE 7 COLORS JUMP TO CHANGE ADJUSTABLE ADJUSTABLE 3 COLORS JUMP TO CHANGE ADJUSTABLE ADJUSTABLE RED/GREEN JUMPS TO CHANGE...
  • Page 48 PAIRING YOUR RGB LED REMOTE - GEN 1 AND GEN 2 Use the following instructions to pair your RGB LED remote to your RGB LED Controller in the event the communication between these two items is not functioning GEN 1 – No arrow on remote back GEN 2 –...
  • Page 49 RGB LED REMOTE PAIRING GEN 1 REMOTE PAIRING Confirm your components are correctly connected. Remove power to the LED system, then after a short 5 second wait, reconnect power and press the #5 button the moment you see your LED lights in the firebox illuminate.
  • Page 50 CONNECTING LIGHTS DIRECTLY TO FIREPLACE The RGB LED light kit can be directly connected to the SIT Proflame II receiver module, allowing for your lights to be on only when the fireplace is powered on and to control turning the lights On and Off using the SIT Proflame II remote.
  • Page 51 RGB LIGHT VERIFICATION – PRE-INSTALL It is best if LED lights are connected and evaluated during the initial stages of installation to allow easy access to the components (before the wall finishing material is done). Evaluating the LED light requires a 110V power source.
  • Page 52 OPTIONAL BLOWER KIT – SCREEN UNITS ONLY The Flare silent blower kit can be added to a safety screened unit to help circulate more heat from the front of the fireplace into the room. The blowers will be powered using a 110V plug. A switch controlling power to the outlet the plug is connected to will be needed in order to turn the fans On and Off, otherwise they will run at all times.
  • Page 53 VENTING PIPE This appliance is approved for use with M&G DuraVent venting and ICC. DO NOT mix pipe, fittings or joining methods from different manufacturers. DuraVent: For detailed DuraVent chimney installation information please use the M&G DuraVent direct vent installation manual: http://www.duravent.com ICC: For detailed ICC chimney installation information please use the ICC direct vent installation manual: http://icc-chimney.com/en/exceldirect...
  • Page 54 VENT PIPE SIZE USED ON EACH FIREPLACE The vent pipe size used differs based on the size of the fireplace being installed. Also note any fireplace that is being power vented automatically uses the 3x5 CVS pipe, and all Room Definer fireplaces use the 5x8 DVA pipe.
  • Page 55 DIRECT VENT PIPE CUT-OUT DIMENSIONS...
  • Page 56 VERTICAL TERMINATIONS Minimum 24” horizontal clearance to any surface, such as exterior walls, for vertical terminations.
  • Page 57 MULTIPLE VERTICAL TERMINATIONS 6” Minimum up to 20” 18” minimum 20” and over 0” minimum...
  • Page 58 HORIZONTAL TERMINATIONS MULTIPLE HORIZONTAL TERMINATIONS A minimum distance of 18” should be kept between multiple horizontal terminations...
  • Page 59 VENT TERMINATION CLEARANCES ^12" Minimum Clearance above grade veranda, porch, deck, or balcony. **12" Minimum Clearance to operational window or door. 12" Minimum Clearance to inoperable window or door. Vertical clearance to ventilated soffit located above the terminal within a 24"...
  • Page 60 VENT RESTRICTOR SETUP The Flare Fireplace direct vent system is equipped with a vent restrictor. Use Chimney Path Installation and Planning to determine the right vent restrictor setup for your installation. The unit leaves the factory with the restrictor open. Once the vent run is determined the restrictor can be adjusted using a 10mm wrench.
  • Page 61 + and – sign located on it. In between that + and – sign is a Philips head screw or bolt that can be turned to either open or close the air shutter. See Ex. 1 above for visual. Example 2: The second option allows you to adjust your Flare Fireplaces air shutter by accessing it ●...
  • Page 62 • A maximum of four 90º vent elbows are allowed in the vent run. Any configuration with more than 4 elbows requires vent review and approval from Flare Fireplaces. • Two 45º elbows may be used in place of one 90º elbow.
  • Page 63 FLARE 30R/30H/PASSAGE Suitable for all 30R/30H/30EH Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 64 FLARE 45R/45H/45EH Suitable for all 45R/45H/45EH Fireplaces Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 65 FLARE 50R/50H/50EH Suitable for all 50R/50H/50EH Fireplaces Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 66 FLARE 60R/60H/60EH Suitable for all 60R/60H/60EH Fireplaces Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 67 FLARE 70R/70H/70EH Suitable for all Flare 70R/70H/70EH Fireplaces Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 68 FLARE 80R/80H/80EH Suitable for all Flare 80R/80H/80EH Fireplaces (6ft. Minimum Rise) Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 69 FLARE 100/100H/100EH Suitable for all Flare 100/100H/100EH Fireplaces (6ft. Minimum Rise) Vent Restrictor Setting: Determined by calculation of the unique run. Set to 1, 2, 3, 4, 5, 6 using chart below. An X requires the run to be power vented.
  • Page 70 For unsupported vent routes (based on the gravity vent tables above) a power venting solution is required. The power venting solutions allow Flare Fireplaces to operate in vent conditions that would not be possible without the motor unit. See the...
  • Page 71 NOTICE A minimum length of 12ft venting is required between the Fireplace and the SK, Flare Fireplaces sizes 30”-70”. A minimum length of 15ft, Flare sizes 80”-100”, is required between the fireplace and the SK.
  • Page 72 ● Connect 4 wire high voltage cable from the Power Vent to matching colors - white to white, black to black & green to green and red to red on the PV system. ● The Flare Fireplaces Fan board is a must for operating a Flare Fireplace with a PV system.
  • Page 73 POWER VENT BOARD ELECTRICAL WIRING DRAWING...
  • Page 75 GAS REQUIREMENTS WARNING! RISK OF FIRE OR EXPLOSION! All gas handling and installation should be performed by qualified service technician or installer. Gas build-up during line purge could ignite. Ensure adequate ventilation. Make sure there are no ignition sources/sparks or open flames. Do not change the gas valve setting! The fireplace gas valve has been preset at the factory.
  • Page 76 SIT PROFLAME II GAS VALVE LAYOUT NOTICE Have the gas supply line installed in accordance with local codes, if any. If not available, follow ANSI 223.1.Installation should be done by a qualified installer approved and/or licensed as required by the locality (in the Commonwealth of Massachusetts installation must be performed by a licensed plumber or gas fitter).
  • Page 77 4500 feet. Contact your local gas supplier for the de-ration requirements in your area. Only use the Flare Fireplaces de-rating reducer on installations above 4500 If the installer must convert the unit to adjust for varying altitudes, the information sticker must be filled out by the installer and adhered to the appliance at the time of conversion.
  • Page 78 ADDING THE FLARE FIREPLACES DE-RATING REDUCER Add the de-rating reducer when your fireplace is being installed at elevations over 4500 ft above sea level. Please contact your local gas supplier for de-ration requirements in your area. 1. Shut off gas, remove power, and locate your gas valve.
  • Page 79 Off. Confirm requirements of location and shut off type with your local codes. NOTE: The Electronic Ignition of Flare Fireplaces DOES NOT satisfy the requirement for a Manual Gas Shut Off. See below for example of Manual Gas Shut Off...
  • Page 80 NOTICE Flare Fireplaces does offer the ability to run your fireplace with a liquid propane tank though there are certain limitations this fuel type presents when compared to the usage of natural gas. Liquid propane burns...
  • Page 81 COMMONWEALTH OF MASSACHUSETTS State of Massachusetts Carbon Monoxide Detector/Vent Terminal Signage Requirements for all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade around the venting, including but not limited to decks and porches, the following requirements shall be satisfied: 1.
  • Page 82 5. The equipment listed in Chapter 10 entitled “Equipment Not Required to Be Vented” in the most current edition of NFPA 54 as adopted by the Board; and 6. Product Approved side wall horizontal vented gas fueled equipment installed in a room or structure separate from the dwelling, building or structure used in whole or in part for residential purposes.
  • Page 83 TELEVISION MOUNTING ABOVE THE FIREPLACE The Flare Fireplace frameless design directs the heat from the fireplace into the fireplace chase to be released from the top vent opening. The design allows for a relatively low temperature on the external wall above the fireplace which allows you to mount a TV or art piece as close as 12” from the glass opening, regardless of size, style, or safety barrier selected.
  • Page 84 TV INSTALL – FLAT EXAMPLE *The example above is not an exact rendering of every fireplace style and vent placement offered by flare but is meant to convey clearances for use on all unit installations. For exact drawings of the fireplaces and their vent placement download dimension or framing guides here.
  • Page 85 TV INSTALL – RECESSED WITH FIREPLACE OVERHANG A. Directly over the fireplace the television recess should be no deeper than 6” inches. B. A minimum of 12” above the top of the fireplace glass opening to the underside of the recess. C.
  • Page 86 *The example above is not an exact rendering of every fireplace style and vent placement offered by flare but is meant to convey clearances for use on all unit installations. For exact drawings of the fireplaces and their vent placement download dimension or framing guides here. WARNING! Maintain Open Air flow between the fireplace and drywall.
  • Page 87 Offset Rise Offset Rise 5” 13 1⁄2” 5 5⁄8” 15 3⁄8”...
  • Page 88 TV INSTALL – NO RECESS WITH MANTEL Minimum Requirements for Installing a Television without a Recess: ● The TV must be at least 11 Inches total above the glass of the fireplace. ● The mantel must be at least 1 inch thick, 6 inches deep, and be installed a minimum of 8 inches above the glass.
  • Page 89 FRAMING SPECIFICATIONS METAL FRAMING NOTICE For more detailed framing information please refer to your unit specific framing guide...
  • Page 90 WOOD FRAMING NOTICE For more detailed framing information please refer to your unit specific framing guide...
  • Page 91 WARNING! Flare fireplaces are not designed to be load baring or support weight of any architectural framing. All framings should be self-supported, supported by back wall, side wall, or ceiling. Mounting the framing to a fireplace subjects’ glass to unsupported weight and could result in damage to fireplace.
  • Page 92 5. Combustible Mantel Clearance – Combustible mantel clearance can vary per mantel size and location. Use chart and provided table for information on mantel installation. Do not anchor any mantel or shelf to the fireplace. Only use metal studs above the fireplace as anchor points. Height Mantel Depth 2"...
  • Page 93 B. 12” minimum from glass opening to underside of non-combustible board within shelf enclosure. WARNING! *Room Definer fireplaces, depending on the surround configuration, may require an additional heat release to alleviate heat build-up caused by the vent pipe. Please contact Flare Fireplaces at 1 (866) 639-1590 to verify your application is safe.
  • Page 94 7. Ceiling Clearance- The minimum ceiling height for a Flare Fireplace is 40” above the top of the fireplace. WARNING! The heat released above the fireplace is critical for keeping the chase and surrounding walls at a relatively low temperature. 8.
  • Page 95 12. Minimum Clearance Above the Fireplace Non-Combustible Zone, Inside the Chase – Zone A: First 18” directly above the fireplace MUST be framed using metal studs if adding a header. Zone B: All combustibles above the 18” must be covered with non-combustible board. There should be no combustible materials left uncovered above the fireplace inside the chase.
  • Page 96 14. Hearth Clearances – Clearance to an uncovered combustible hearth below the glass is 2 inches as seen in EXAMPLE 1 When bringing your hearth to glass height it must be non-combustible for the first 7” extending from the glass before any combustible material can be used to finish the hearth. As seen in EXAMPLE 2 15.
  • Page 97 Finishing Around Front of Fireplace – Non-combustible finishing material (i.e., cement board, brick, stone, and tile) MUST be used to finish around the front of the appliance. Covered combustible material can also be used to finish around the front of the fireplace, but only if the proper distance from the fireplace is maintained.
  • Page 98 Example 2: NOTICE Do not connect materials to or drill into the metal fireplace frame. This can result in excessive heat transfer and/or damage to the fireplace and surrounding materials.
  • Page 99 Example 3: NOTICE Do not connect materials to or drill into the metal fireplace frame. This can result in excessive heat transfer and/or damage to the fireplace and surrounding materials.
  • Page 100 NON-COMBUSTIBLE MATERIALS SPECIFICATIONS Non-Combustible Materials Specification Material which will not ignite and burn. Such materials are those consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination thereof. Materials that are reported as passing ASTM E 136, Standard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750 ºC shall be considered non-combustible materials.
  • Page 101 CLEARANCE TO A SPRINKLER In a situation where a sprinkler head is installed within proximity to a Heat Release, the diagram below MUST be followed. The distance between the sprinkler head & Heat Release opening cannot be less than 60” in length at every point from the origin of the Heat Release. You must also verify the sprinkler head sensor is set to the proper heat setting so it does not activate when the room heats up from the fireplace being operated normally.
  • Page 102 HEAT RELEASE AND AIR INTAKE SPECIFICATION For more specific information related to understanding the Heat Release and Air Intake please use the following links, and read information outlined below. Heat Release Manual Air Intake Manual HEAT RELEASES The heat release opening is required for all fireplaces and allows warm air to passively flow back into the room.
  • Page 103 HEAT RELEASE EXAMPLES DROP WALL The drop-wall heat release is implemented by creating a surround that reaches the minimum ceiling level of 40” above the top of the fireplace, and instead of bringing the surround all the way to the ceiling you hold your entire surround from the ceiling, opening the top of the surround to allow heat to rise out of the top and into the room.
  • Page 104 LINEAR SLOT OR LOUVERED GRATE The linear slot or louvered grate heat release is implemented by creating an opening in your fireplace surround within 1” – 3” of the non-combustible firestop which meets the open air-flow requirements and allows the heat to enter the room through the opening provided.
  • Page 105 AIR INTAKE The air intake opening is required for all fireplaces equipped with the upgraded double/triple glass safety barrier. The air intake allows for fresh air from a conditioned space to cool the outer glass safety barrier, preventing it from reaching temperatures that require a screen. This also contributes to the temperature of the surrounding walls, so it’s implementation is key to a safe and long-lasting fireplace.
  • Page 106 DOUBLE GLASS REQUIRED AIR INTAKE EXAMPLES FLOATING HEARTH The floating hearth intake uses the depth of an existing hearth to mask an opening tucked underneath. This masking allows you to create an opening that is both large enough to exceed the minimum sizing requirements and allow a technician a large space for accessing the components.
  • Page 107 TOE-KICK REVEAL To implement a toe-kick reveal, construct your build so that it stops 2” – 4” above the floor and is recessed 2” – 3” from the front edge. Then, extend the finishing to the floor. This creates an upside- down L-shape, where the segment of the L parallel to the floor remains open along the entire length.
  • Page 108 LEFT AND RIGHT-SIDE VENTS Vents may be cut into the finishing material or placed over an opening in the surround to finish out the air intake. It’s critical that if putting an air intake on the side of your surround it’s on both sides and sized evenly to allow enough fresh air to reach the fireplace in a balanced manner.
  • Page 109 LINEAR SLOT The linear slot is an effective and straightforward method for implementing an air intake. Simply cut a slot in the face or backside of the fireplace surround to meet the necessary airflow requirements. If you are adding a custom finishing piece, consider any restrictions this piece creates, and ensure it does not obstruct the opening and maintains proper airflow.
  • Page 110 FLARE FRONT, SEE THROUGH, AND CORNER FIREPLACE CLEARANCE FLAT – SIDE AND ISOMETRIC VIEW & CLEARANCES Warning! – Maintain open Air flow between the fireplace and drywall. Make sure cables or any other materials are not blocking.
  • Page 111 Top Vent system - Hot Airflow outlet from the wall enclosure MUST remain open. The outlet must be at the top part of the enclosure, but not necessarily at the front, if the measurements below are maintained. Fireplaces sized 30” – 50” the vent area must be at least 100 square inches of open-air flow. (*130 square inches of open-air flow if vertically oriented) Fireplaces sized 60”...
  • Page 112 Heat exchange blowers are optional when a fireplace is installed with safety screens. Heat exchange blowers must be included when installing a double glass fireplace. The blowers are designed to move cold air from the room using the lower vent opening (G) up against the fireplace glass. As the air flows on the glass, it is heated and released back to the room from the glass front and from the top (A) vent opening.
  • Page 113 L SHAPE – SIDE AND ISOMETRIC VIEW Warning! – Maintain open Air flow between the fireplace and drywall. Make sure cables or any other materials are not blocking.
  • Page 114 Top Vent system - Hot Airflow outlet from the wall enclosure MUST remain open. The outlet must be at the top part of the enclosure, but not necessarily at the front, if the measurements below are maintained. Fireplaces sized 30” – 50” the vent area must be at least 100 square inches of open-air flow. (*130 square inches of open-air flow if vertically oriented) Fireplaces sized 60”...
  • Page 115 Heat exchange blowers are optional when a fireplace is installed with safety screens. Heat exchange blowers must be included when installing a double glass fireplace. The blowers are designed to move cold air from the room using the lower vent opening (G) up against the fireplace glass. As the air flows on the glass, it is heated and released back to the room from the glass front and from the top (A) vent opening.
  • Page 116 SIDE OVERHANG FOR LEFT, RIGHT, AND DOUBLE CORNER FIREPLACES When installing a Left, Right, or Double Corner fireplace with left and right non-combustible overhangs, please follow the specification outlined below to maintain a safely operating fireplace and surround. - First 18” of framing above the fireplace must be metal studs. - All finishing materials within and above this glass recess must be non-combustible - At no point can your overhang reach down into the viewing area.
  • Page 117 INDOOR/ OUTDOOR KIT The following installation information is used for the Flare Fireplace outdoor kit. The outdoor window kit can only be used with Flare Front, Flare See Through, and the Flare See Through Passage fireplaces. The Flare outdoor kit is installed like a window and must be weatherproofed on all sides. It must include an overhang or cover to protect the face from exterior elements.
  • Page 118 OUTDOOR KIT OVERHANG REQUIREMENTS A weatherproof overhang in front of the fireplace is 1/2 the height of the fireplace face-wall, measured from the base of the unit to the ceiling.
  • Page 119 OUTDOOR KIT FRAMING AND FINISH All studs and surrounding material should follow the fireplace clearances and non-combustible requirements OUTDOOR KIT CLEARANCE TO NON-COMBUSTIBLE WALL...
  • Page 120 OUTDOOR KIT OPENING DIMENSIONS Use the Flare architectural guide for information on the window size and opening: http://flarefireplaces.com/portfolio-items/flare-outdoor/...
  • Page 121 WEATHER-PROOF YOUR OUTDOOR KIT CAVITY The outdoor window kit should be sealed with non-combustible tape, around the inner most flange, prior to covering it with brick or stucco. All non-combustible finishing material can come directly to the outer-most flange around the face of the fireplace. Creating that frameless appearance around your opening.
  • Page 122 The existing Flare Fireplace wall switch cable can be located by removing the included Flare Fireplaces wall switch, exposing the wire provided, and replacing it with a dry contact On/Off relay controlled by the home automation system. The existing Flare Fireplace wall switch cable can be extended up to 100 FT for integration into a new or existing Home Automation System.
  • Page 123 ELECTRIC AND CONTROL ELECTRIC DIAGRAM - SCREEN X8: Wall Switch / Home Automation X4: Closed Circuit (Jumper Present) X3 and X2: Spark Ignitor and Sensor X1: Power (Green : Ground, White : Common, Black : Line)
  • Page 124 SIT PROFLAME II DIAGRAM – DOUBLE GLASS AND POWER VENT X13: Auxiliary used to open and close relay port on double glass board X8: Wall Switch / Home Automation X4: On/Off, controlled via Flare Control Board verification X3 and X2: Spark Ignitor and Sensor X1: Power (Green : Ground, White : Common, Black : Line) Optional 110V to Power to LED System...
  • Page 125 DOUBLE GLASS BOARD & LED LIGHT GUIDE A. Double Glass Fan LEDs: When fans are operating properly these LEDs will be green for each fan being monitored on the fireplace. When fans are failing to operate properly the LEDs will be amber. B.
  • Page 126 ELECTRICAL DIAGRAM - POWER VENT SYSTEM 4 wire cable 110V from Fireplaces...
  • Page 127 REPLACEMENT PARTS See below for SIT ProFlame II replacement parts list. These are the most commonly used components a technician may need when working on the fireplace system. Please contact your local fireplace dealer to purchase replacement parts. Please provide description, part number, Part SKU, and Fireplace serial number. Please use a trained and certified technician for any fireplace related service.
  • Page 128 MAINTENANCE WARNING! ● It’s recommended that a qualified service technician perform a routine inspection at the beginning of each heating season. ● Disconnect power before attempting maintenance or repair of the fireplace. ● Installation and maintenance must be performed by an authorized qualified installer, service agency or gas supplier.
  • Page 129 ● Failure to inspect and maintain the fireplace may lead to improper combustion and a potentially dangerous situation. We recommend the following procedures be done by a qualified technician. GLASS MAINTENANCE ● Always use suction cups to remove the fireplace glass. ●...
  • Page 130 BURNER MAINTENANCE ● The flames from the burner should be visually checked. The flame should have a blue base and yellow tops and be candle-like in appearance. ● If excessive soot is found inside the firebox area, the fireplace will require adjustment. Verify the air shutter and vent restrictor setting and document any changes.
  • Page 131 DOUBLE GLASS FANS MAINTENANCE ● Disconnect power to the Flare control system. ● Remove the external glass and the covering trim. ● Inspect the fans around the Flare firebox and make sure they are all turning. ● Clean all fans with a brush and vacuum to remove any dust or debris. ●...
  • Page 132 MAINTENANCE LOG The service technician should use the following document. A copy should be kept with the technician and owner for future reference. Flare Fireplaces – Maintenance Log Service Date: ___________________ Unit Information Model Type and Size: _____________________ Serial #: _______________________...
  • Page 133 WARRANTY POLICY Flare Fireplaces subjects every fireplace and component to rigorous testing to verify it is free from any defects before it leaves our warehouse. Flare Fireplaces photographs and documents the fireplace and all components’ moments before shipping them to our nationwide network of authorized dealers for installation, verifying full operation of the fireplace and all components.
  • Page 134 The warranty is only valid while the appliance remains at the site of original installation. • Flare Fireplaces does not install or provide installation services. The installation of the fireplaces must be done by an authorized installer. The fireplace limited warranty does not cover the installation service, or any part related to the installation of the fireplace or surrounding of the fireplace and venting.
  • Page 135 Flare Fireplaces is not responsible for installation, operational or environmental conditions beyond our control. • Flare Fireplaces shall in no event be liable for any special, indirect, or consequential damages of any nature which are more than the original purchase price of the product. •...
