Icon Process Controls truflo TKP Series Quick Start Manual page 6

Truflo — TKP | TK3P Series (V1)
®
In-Line Paddle Wheel Flow Meter Sensor
Programming
STEPS
Home Screen
1
+
F
Password
2
Units of Flow
3
K Factor
4
Totalizer Reset
STEPS
Home Screen
1
+
Totalizer Reset
2
24-0597 © Icon Process Controls Ltd.
DISPLAY
▶
��
3 Sec .
▶
▶
▶
DISPLAY
▶
��
3 Sec .
▶
Select/Save/Continue
F
Home Screen
Factory Default: Lk = 10
Otherwise meter will enter Lockout Mode*
Press / to change
to save
Press
Range: 0 ~ 2
Ut.0 = Liter | Ut.1 = Gallon (Factory Default)
Enter K Factor Value
Refer to Page 9 for K-Factor Values
Home Screen
Totalizer Value will Reset to Zero
Move Selection Left
OPERATION
| Ut.2 = Kiloliters
OPERATION
Change Digit Value
6
