Test and Diagnosis System

TDS40 / TDS60

(Stand-alone test operation)

Operating Manual

Issue:

01 (01/2014) - EN

Item-Nr.:

83549

All manuals and user guides at all-guides.com

Need help?

Do you have a question about the TDS40 and is the answer not in the manual?

Questions and answers

Summary of Contents for Megger TDS40

Page 1 All manuals and user guides at all-guides.com Test and Diagnosis System TDS40 / TDS60 (Stand-alone test operation) Operating Manual Issue: 01 (01/2014) - EN Item-Nr.: 83549...
Page 2 All manuals and user guides at all-guides.com...
Page 3 All rights reserved. No part of this handbook may be copied by photographic or other means unless Megger have before-hand declared their consent in writing. The content of this handbook is subject to change without notice. Megger cannot be made liable for technical or printing errors or shortcomings of this handbook.
Page 4 Each component and product replaced in accordance with this warranty becomes the property of Megger. All warranty claims versus Megger are hereby limited to a period of 12 months from the date of delivery. Each component supplied by Megger within the context of warranty will also be covered by this warranty for the remaining period of time but for 90 days at least.
Page 5 All manuals and user guides at all-guides.com INHALTSVERZEICHNIS GENERAL INTRODUCTION ..........1-9 General Instructions ................1-10 General Safety Instructions and Warnings ........1-11 TECHNICAL DESCRIPTION ..........2-13 Description of the Functions .............. 2-13 Model Options ..................2-13 Technical Specifications ..............2-14 Scope of Delivery and Options ............
Page 6 All manuals and user guides at all-guides.com Viewing / Setting the System Parameters .......... 5-40 Entering / Changing the Administrator Password......5-41 Returning to the Start Menu ..............5-42 Optional Features ............... 6-43 Detection of Breakdown and Short Circuit ........6-43 Measurement of Leakage Current............
Page 7 All manuals and user guides at all-guides.com Abbildungsverzeichnis Fig. 1: Time frame of polarity reversal (type Plus) ..........2-16 Fig. 2: Shape of 0.1 Hz cosine-rectangular VLF voltage (type Plus) ....2-17 Fig. 3 Operating module - Front View .............. 2-21 Fig.
Page 8 All manuals and user guides at all-guides.com Fig. 39: Setup Date / Time: Adjusting the day of the week ........6-54 Fig. 40: Setup Date / Time: Adjusting the minutes ..........6-54 Fig. 41: Setup Date / Time: Saving by F1 ............6-54 Fig.
Page 9 All manuals and user guides at all-guides.com GENERAL INTRODUCTION The test and diagnosis system TDS40/60 shall be used for the stated field of application in cable diagnosis and cable testing only. Any other application is strictly forbidden! Megger cannot be made liable for any damage to persons or matter caused by using the system for some other application.
Page 10 Failure to observe them can render the measurement results useless. Working with products from Megger It is important to observe the generally applicable electrical regulations of the country in which the device will be installed and operated, as well as the current national accident prevention regulations and internal company directives (work, operating and safety regulations).
Page 11 In this case inform the person in charge who should inform the Megger-service to resolve the problem. The instrument may only be operated when the malfunction is resolved.
Page 12 A CO2 fire extinguisher must be always available within electrical installations. • If, contrary to the regulations, any other extinguishing agent is used for fire fighting, this may lead to damage at the electrical installation. Megger disclaims liability consequential damage.
Page 13 Due to the integrated breakdown detection, this test process takes place without damage to the fault-free cable insulation. In combination with the partial discharge measurement system PDS 60, the TDS40/60 forms a fully adequate diagnosis system (TDS NT) which is suitable for the partial discharge diagnosis on medium voltage cables according to the standards.
Page 14 All manuals and user guides at all-guides.com Technical Specifications Parameter TDS40 TDS60 Output voltage DC 3 … 40 kV 3 … 60 kV Output current source 7 mA 5 mA Leakage current measurement (optional) Range of indication 0 - 7 mA...
Page 15 All manuals and user guides at all-guides.com Parameter TDS40 TDS60 Protection class (in accordance with IEC 61140 (DIN VDE 0140-1)) Ingress protection rating (in IP21 accordance with IEC 60529 (DIN VDE 0470 1)) Dimensions (W x H x D) 56 x 113 x 41.5 cm 62.5 x 118 x 62 cm...
Page 16 All manuals and user guides at all-guides.com Description of the Test Procedure with VLF-Voltage Because of the space charges formed in the dielectric of the cable, DC test methods prove to be dangerous when applied to PE and VPE cables and should therefore never be used on such types of cables.
Page 17 All manuals and user guides at all-guides.com Another vital characteristic to be considered when designing this system was to ensure simple on-site testing by small dimensions, light weight and low power consumption. Every cycle starts with a charging phase in which the test object as well as the back-up capacitor switched in parallel are charged from a DC source until the desired test voltage is reached.
Page 18 All manuals and user guides at all-guides.com The loss of voltage caused by twice changing the polarity (device option Basis) will now be compensated for by recharging with the negative DC source. In contrast to this at the device option Plus the losses of a polarity reversal are immediately compensated. The back-up capacitor has the following tasks: - It slows the ring-around event down to the ms range even for short cables, - It compensates a part of the losses during the polarity reversal.
Page 19 All manuals and user guides at all-guides.com Testable Cable Capacitance in VLF Mode 2-19...
Page 20 All manuals and user guides at all-guides.com Cable Capacitance that Can be Diagnosed in DAC Mode TDS60  TDS40  2-20...
Page 21 All manuals and user guides at all-guides.com Description of Components 2.8.1 Operating Module 11 10 9 Fig. 3 Operating module - Front View Key "Emergency Off" Analogue indication instrument test voltage (kV) Display Menu key F1 Menu key F2 Knob / push-button Intake slot for the System Card Protocol printer Key "HVOff"...
Page 22 All manuals and user guides at all-guides.com 2.8.2 Display of the Operating Module VLF mode 10kV 0.0kV 5min 0.00mA Prepared HVOn? Fig. 4: Display of the Operating module (View of the standard operating mode) Representation of parameters with value and content resp. Representation of residual time and/or measuring values Representation of operator guidance / status display Following signals are indicated in the line of operator guidance / status display (Fig.
Page 23 All manuals and user guides at all-guides.com 2.8.3 Connections Fig. 5: Connections (in the example of the TDS60) Power supply socket with F1, F2 Terminal clip for earth connection of the Operating module Terminal clip for earth connection HV module RJ45 network socket for the connection with the notebook (required for remote control) Connector socket for connection line to PDS 60...
Page 24 All manuals and user guides at all-guides.com 2.8.4 Protection Covers of the Module Test System Fig. 6: Protection cover of the Operating module Fig. 7: Shorting device / Protection cover of the HV module 2-24...
Page 25 All manuals and user guides at all-guides.com 2.8.5 Transportation Protection Bottom from the Operating Module Pull out in order to remove Pull out in order to remove the transportation protection the transportation protection bottom bottom Push in in order to fix Push in in order to fix the transportation the transportation...
Page 26 All manuals and user guides at all-guides.com...
Page 27 All manuals and user guides at all-guides.com SETTING UP OPERATION Safety Precautions Before starting any operation, always observe the 5 rules of safety: • Disconnect the test object • Protect it against reclosure • Check for absence of voltage • Connect it to earth and short-circuit it •...
Page 28 This applies in particular to all changes made on an existing safety device. The test and diagnosis system TDS40 generates during the test process a dangerous test voltage up to 40 kV or the test and diagnosis system TDS60 a test voltage up to 60 kV resp.
Page 29 All manuals and user guides at all-guides.com Attention! The HV module of the test and diagnosis system contains electrical energy storage devices also. These devices are discharged in the same way like the test object by the internal discharging unit of the test device. To avoid the re-charging by space charges the HV module has to be immediately equipped by means of the provided shorting device (Fig.
Page 30 All manuals and user guides at all-guides.com 3.2.2 Procedure The descriptions in this section solely apply to the stand-alone operation. The features regarding the electrical connection in order to diagnose partial discharge are described in the manual of the discharge measurement system PDS 60.
Page 31 All manuals and user guides at all-guides.com 3.2.3 Connection of the External Safety Device (Optional) The optional external safety device can be connected in between the power outlet and the power inlet in order to ensure norm-compliant signalling and Emergency Stop according to DIN EN 50191 / VDE 0104.
Page 32 All manuals and user guides at all-guides.com...
Page 33 Operating in Stand-alone Test Mode This manual solely describes the operating of the test and diagnosis system TDS40/60 in the stand-alone mode. For information on operating the system by remote control in order to diagnose partial discharge please read the manual of the operating system TDS NT.
Page 34 All manuals and user guides at all-guides.com VLF mode *20kV 15min Set Voltage ? Fig. 13: Selection of the test voltage The test voltage level can be adjusted in steps of 1 kV up to the maximum test voltage of the system by turning the knob / push-button (Fig.
Page 35 All manuals and user guides at all-guides.com Sheath Fault Location Following a failed sheath test with DC voltage fault location based on the step voltage method can be immediately performed at the cable under test with the test and diagnosis system serving as voltage source.
Page 36 All manuals and user guides at all-guides.com Starting the Test / Location After the system has carried out all necessary settings which takes a short period of time, the high voltage can be enabled. VLF mode 20kV 0.0kV 15min 0.00mA Prepared HVOn? Fig.
Page 37 All manuals and user guides at all-guides.com By using the menu button F2 (Fig. 3, item 5) the user can switch at any time to the display with the instantaneous data. The instantaneous data are displayed without square brackets and updated every 100 ms. VLF mode 11:32 20kV...
Page 38 All manuals and user guides at all-guides.com During normal operation, the voltage source is / can be switched off by pressing the "HVOff" key (red) (Fig. 3, item 9) automatically after the lapse of the test time automatically after a voltage breakdown in the cable under test or a short circuit has been detected In these cases the predefined discharging of the voltage source, back-up capacitor and test object follows.
Page 39 All manuals and user guides at all-guides.com Additional Functions Adjustment of Language By pressing the F2 key (Fig. 3, item 5) and turning the knob / push-button (Fig. 3, item 6) the "User setup" menu can be accessed. Here the language on the display and in the protocol printing of the test and diagnosis system can be adjusted.
Page 40 All manuals and user guides at all-guides.com Viewing / Setting the System Parameters Certain test parameters in the test and diagnosis system are permanently stored as system parameters and secured against unauthorized changes. As a standard user you can only view these parameters. In order to adjust these parameters you have to gain administrator rights by entering the administrator password first (see section 5.4).
Page 41 All manuals and user guides at all-guides.com Entering / Changing the Administrator Password By pressing the F2 key “setup” (Fig. 3, item 5) and turning the knob / push-button (Fig. 3, item 6) the "Password" menu can be accessed. When entering this menu, you have to enter the administrator password in order to gain the administrator rights enabling you to adjust the test parameters accessible via the “Parameters”...
Page 42 All manuals and user guides at all-guides.com After the password has been entered and accepted, it can be changed. In order to change the password, you have to access the “Passw. Set” menu right after you gained administrator rights. The new password has to be entered the same way as the current password has been entered (see previous page).
Page 43 All manuals and user guides at all-guides.com Optional Features Detection of Breakdown and Short Circuit Systems with the optional breakdown and short circuit detection offers the following additional functions: The test voltage will be immediately switched off in any case of a breakdown in the cable under test.
Page 44 All manuals and user guides at all-guides.com Internal Protocol Printout Systems, that are equipped with a protocol printer (Fig. 3, item 8), offer the opportunity to print those data that have been logged during the cable test. By pressing the F2 key (Fig. 3, item 5) and turning the knob / push-button (Fig. 3, item 6) the "Protocol"...
Page 45 All manuals and user guides at all-guides.com • Printout „Extended“: All information listed under “Standard” Maximum test voltage, test voltage increase, step increment, rest period of the ramp (ramp pause) Settings for logging and printing User profile, service / administrator mode (if applicable) Measured data (time, test voltage, current) of the charging period •...
Page 46 All manuals and user guides at all-guides.com Attention: When initiating a test printout ("Text" or “System”), any set of measuring data that may have been logged during a previous cable test will be deleted. Attention: Immediately change the print settings back to your normal protocol printout mode after you performed a test printout.
Page 47 All manuals and user guides at all-guides.com Cable Tests using a SystemCard 6.4.1 SystemCard and „WinkisVLF“ If the test and diagnosis system has been equipped with the logging option, the measured data can be saved to a so-called SystemCard which has the dimensions of a conventional credit card.
Page 48 All manuals and user guides at all-guides.com 6.4.2 Parametrising the SystemCard Using a SystemCard appropriately parametrized under WinkisVLF will enable you to make volatile (only for the cable test under way) or permanent changes to your device settings. Depending on how the card has been parametrized, either all or only certain test parameters are affected.
Page 49 All manuals and user guides at all-guides.com 6.4.3 Logging to SystemCard By activating the logging function, measuring data logged during a cable test can be written to a SystemCard. These data may consist of system information, system / test settings, information about the course of the cable test, the measured data (test voltage, leakage current) and the test result.
Page 50 All manuals and user guides at all-guides.com Depending on the logging mode, the following data are saved to the SystemCard: • Protocol „Off“: If the protocol mode is set to “Off”, no measured data is written to the SystemCard. • Protocol „Standard“: System type and version Test settings relevant for analysis Date / time of test start...
Page 51 All manuals and user guides at all-guides.com From now on, only the test parameters which have been specified as [set on device] under WinkisVLF can be manually changed. This does also apply for the parameters accessible via the setup menu (F2 key). If the card is removed from the slot, the settings are undone and the standard start menu appears on the display.
Page 52 All manuals and user guides at all-guides.com Function User Setup / User Level By pressing the F2 key (Fig. 3, item 5) and turning the knob / push-button (Fig. 3, item 6) the menu "User Setup" can be accessed. After administrator rights have been gained as described in section 5.4, the “User Setup” menu can be used to change the user level.
Page 53 All manuals and user guides at all-guides.com Re-Setting the System Settings / Deleting the Print Templates The user interface of the test and diagnosis system allows you to reset the non-volatile system settings back to the default factory settings and to delete permanently stored print templates.
Page 54 All manuals and user guides at all-guides.com Adjustment of the System Time If the test and diagnosis system is equipped with at least one of the system options “Logging” or “Protocol printout”, the system contains a battery-operated and crystal- controlled clock (see section 7.3). After activating of the Menu key F2 (Fig.
Page 55 If the fuses are defective, they must be replaced with suitable microfuses (5 x 20 mm) of the type T2.5A. Disconnet from the mains before changing a fuse. If the fuses continue to trip, please get in touch with the Megger service department in order to have the problem resolved.
Page 56 All manuals and user guides at all-guides.com Exchanging the Paper Roll or Ink Ribbon of the Printer The optional built-in printer is housed in a robust metal case with removable front cover. To exchange the paper roll or the ink-ribbon cartridge, first remove the front cover from the printer.
Page 57 All manuals and user guides at all-guides.com Exchanging the paper roll The container can hold paper rolls with up to 50 mm diameter. First follow step b and remove the ribbon cartridge. Remove the spindle from the core of the empty roll and insert it into the core of the new paper roll. If necessary, cut the front edge of the paper strip in a straight line.
Page 58 All manuals and user guides at all-guides.com Connecting Cables, HV Couplings Maintenance and troubleshooting include regularly checking the connecting cables such as earth cables, mains cables and test cables for being in good repair. In addition to that we recommend that the HV couplings at the Operating module and HV module should be checked with regard to mechanical integrity and cleanness.
Page 59 All manuals and user guides at all-guides.com 7.5.2 Operational Messages about State of System The following operational messages inform the operator about the current state of the system. You don´t need to confirm any of them. The system, however, expects the operator to make one of the entries listed in the table.
Page 60 All manuals and user guides at all-guides.com Operational message Description Input Code Card is faulty ! Content of system card none pull out is faulty. card ! Really this card ? System is waiting for confirmation of card. Reading card... System is reading data none from the system card.
Page 61 All manuals and user guides at all-guides.com Operational message Description Input Code Set user level In Setup: Prompting to rotary knob + OK make entry F1= set! else OK In Setup: query for F1: set or OK setting the clock (abortion) Set date &...
Page 62 All manuals and user guides at all-guides.com 7.5.3 Operational Messages about Switching Conditions The following operational messages inform the user about the switching conditions prior to "HVOn" and about the cause of shut-down after "HVOff". These messages need to be confirmed by the operator with "OK"...
Page 63 All manuals and user guides at all-guides.com Operational Description Input Code message Breakdown in cable High voltage has been Possible result of a switched off by system cable test after breakdown in cable. Cannot be charged High voltage has been Possible result of a switched off by system cable test...
Page 64 All manuals and user guides at all-guides.com 7.5.4 Error Messages and Warnings With the exception of operating errors, every error, once it has occurred, is reported by way of a two-digit error code. Each of these messages needs to be confirmed by the operator with "OK", further procedures are determined by the system.
Page 65 All manuals and user guides at all-guides.com Operational Description Input Code message Unknown The software version of Insert Master Flash with master the master is not appropriate software compatible with the version software version of the slave. Slave timeout Communication between LON Bus / wiring / power master and slave is supply...
Page 66 All manuals and user guides at all-guides.com Operational Description Input Code message Jumper Jumper coding of module Undo changes or make changed "Control node VLF…" changes only when has been changed during system is switched off operation. Module coupling The connection between Restore connection, the modules of the sys- check hardware signal...
Page 67 All manuals and user guides at all-guides.com Operational Description Input Code message VOLTAGE Danger! Voltage monitor Eliminate possible FOUND in reports residual voltage residual voltage at HV measuring divider. manually. Check discharge switches and voltage monitoring. Overvoltage Voltage monitor in slave Check voltage control of reports overvoltage at HV HV sources, check...
Page 68 All manuals and user guides at all-guides.com Operational Description Input Code message Setup is faulty System of conditions on Software trouble - must master inhibits start of HV not occur during opera- operation if user level is tion inappropriate. Access denied Entered password is To administrator, wrong and will be...
Page 69 All manuals and user guides at all-guides.com Operational Description Input Code message Check sum error Some check-sum error Data are stored on card has occurred when in an EEPROM. Life time reading from the system expired? card. Unlocked Only in test lab: Only in test lab: system Automatic configuration...
Page 70 State mismatch Unknown request Parameter error Lost connection Communication between Potential interruption of the TDS40/60 and the PD the cable connection or measurement system has crash of the PD software. been interrupted. Solve the problem and restart the system. 7-70...
Page 71 All manuals and user guides at all-guides.com Tento symbol indikuje, že výrobek nesoucí takovéto označení nelze likvidovat společně s běžným domovním odpadem. Jelikož se jedná o produkt obchodovaný mezi podnikatelskými subjekty (B2B), nelze jej likvidovat ani ve veřejných sběrných dvorech. Pokud se potřebujete tohoto výrobku zbavit, obraťte se na organizaci specializující se na likvidaci starých elektrických spotřebičů...
